冶金含钾除尘灰中钾资源提取现状综述

王会刚; 吴龙; 邱桂博; 郝以党; 张方彬; 杨增奎; 吉博文; 岳昌盛; 彭犇

doi:10.13205/j.hjgc.202401016

冶金含钾除尘灰中钾资源提取现状综述

doi: 10.13205/j.hjgc.202401016

王会刚^1,2,3,
吴龙^1,2,3, ,,
邱桂博^3,4,
郝以党^1,2,3,
张方彬^3,4,
杨增奎^3,4,
吉博文^3,4,
岳昌盛^1,2,3,
彭犇^1,2,3

1. 钢铁工业环境保护国家重点实验室, 北京 100088;
2. 中冶节能环保有限责任公司, 北京 100088;
3. 中冶建筑研究总院有限公司, 北京 100088;
4. 湛江中冶环保运营管理有限公司, 广东湛江 524000

基金项目:

国家自然科学基金面上项目(52178265；52178264)

详细信息

作者简介:
王会刚(1987-),男,博士,主要研究方向为冶金固废处理及资源化利用。wanghuigang0822@126.com

通讯作者:
吴龙(1985-),男,博士,主要研究方向为冶金固废处理及资源化利用的技术开发及应用。332409636@qq.com

计量
- 文章访问数: 86
- HTML全文浏览量: 7
- PDF下载量: 5
- 被引次数: 0
出版历程
- 收稿日期: 2022-10-30
- 网络出版日期: 2024-04-29

REVIEW ON EXTRACTION OF POTASSIUM FROM METALLURGICAL DUST-CONTAINING POTASSIUM

WANG Huigang^1,2,3,
WU Long^{1,2,3
, ,},
QIU Guibo^3,4,
HAO Yidang^1,2,3,
ZHANG Fangbin^3,4,
YANG Zengkui^3,4,
JI Bowen^3,4,
YUE Changsheng^1,2,3,
PENG Ben^1,2,3

1. State Key Laboratory of Iron and Steel Industry Environmental Protection, Beijing 100088, China;
2. Energy Conservation and Environment Protection Co., Ltd., MCC Group, Beijing 100088, China;
3. Central Research Institute of Building and Construction Co., Ltd., MCC Group, Beijing 100088, China;
4. Zhanjiang Environmental Protection Operation Management Co., Ltd., MCC Group, Zhanjiang 524000, China

摘要

摘要: 钢铁企业产生的烧结机头灰等固体废弃物钾含量较高,若不经处理直接作为炼铁原料返回烧结循环利用,不仅会影响烧结矿质量,还会导致高炉炼铁过程焦比升高、顺行受阻等问题。同时,我国钾矿储量不足,钾盐对外依存度超过1/2。针对上述问题,对钢铁除尘灰的处理和钾盐的生产消耗现状进行了简单介绍,深入剖析了含钾除尘作为烧结原料对炼铁过程的影响;介绍了转底炉回转窑处理除尘灰工艺,并指出其也会造成二次锌灰中K的富集;基于含钾除尘灰的理化特性及含钾物质存在状态,对采用“浮选-重选”和“水浸-分离-净化-结晶”2种工艺对含钾除尘灰中钾提取的研究进展进行了详细介绍。明确了若冶金烧结含钾除尘灰、转底炉和回转窑二次锌灰全部进行KCl的回收,有望使我国KCl的对外依存度降低20%左右,具有重要的意义。
- 含钾除尘灰 /
- 提钾 /
- 浮选-重选 /
- 水浸-分离-净化-结晶
Abstract: The solid waste, such as sintering machine head ash generated by steel enterprises has a high potassium content. If it is directly returned as ironmaking raw materials for sintering and recycling without treatment, it will not only affect the quality of sintered ore, but also lead to problems such as an increase in coke ratio and obstruction in the blast furnace ironmaking process. At the same time, China's potassium ore reserves are insufficient, and the external dependence of potash is higher than 1/2. Given the above problems, this paper first introduces the treatment of iron and steel dust and the production and consumption status of potassium salt, and deeply analyzes the impact of potassium dust removal as sintering raw material on the ironmaking process. After that, the dust removal process of the rotary kiln and rotary hearth furnace is introduced, which also leads to the enrichment of potassium in the secondary zinc dust. Finally, based on the physical and chemical properties and the existing state of potassium-containing substances in the dust, the research progress of potassium extraction from the potassium-containing dust by two processes of “flotation gravity separation” and “water leaching-separation-purification-crystallization” is introduced. If the potassium-containing dust from the sintering process and the secondary zinc dust from the rotary hearth furnace are all recycled for KCl, it is expected to reduce the external dependence proportion of KCl in China by about 20%.
- sintering dust containing potassium /
- potassium extraction /
- flotation gravity separation /
- water leaching-separation-purification-crystallization

HTML全文

参考文献(26)

[1]	修春雨.含锌尘泥材料化利用过程中铁和锌的利用率优化[D].马鞍山:安徽工业大学,2019.
[2]	王亚雨.烧结电除尘灰内配碳球团还原实验研究[D].武汉:武汉科技大学,2017.
[3]	尹海涛,武杏荣,李辽沙,等.富铁冶金尘泥中有价元素的选择性还原研究[J].矿产综合利用,2013(5):67-71.
[4]	汪家铭.利用冶金烧结电除尘灰生产氯化钾新技术[J].化工矿物与加工,2013,42(7):46-47.
[5]	谭慧婷,孙伟,崔玉照,等.钾矿资源现状与杂卤石的开发应用分析[J].无机盐工业,2022,54(6):23-30.
[6]	刘自民.马钢含铁尘泥综合利用研究与实践[J].中国冶金,2018,28(9):71-76.
[7]	霍天玺,焦玉莉,侯莉萍.转底炉直接还原处理含锌尘泥的设计特点[J].河北冶金,2013,6:40-42.
[8]	王贤君.转底炉处理冶金含锌尘泥的理论分析及实验研究[D].重庆:重庆大学,2012.
[9]	杨春善,任明欣.日照钢铁固废尘泥处理实践[J].钢铁,2019(4):10.
[10]	殷磊明.煅烧含锌粉尘回转窑结圈的研究[D].马鞍山:安徽工业大学.
[11]	张庆明,段志军,幺田林,等.本钢高锌含铁尘泥回转窑处理工艺研究[J].中国废钢铁,2016,2:18-22.
[12]	庞建明,郭培民,赵沛.回转窑处理含锌、铅高炉灰新技术实践[J].中国有色冶金,2013(3):19-24.
[13]	PENG C,GUO Z,ZHANG F.Existing state of potassium chloride in agglomerated sintering dust and its water leaching kinetics[J].Transactions of Nonferrous Metals Society of China,2011,21(8):1847-1854.
[14]	MENAD N,TAYIBI H,CARCEDO F G,et al.Minimization methods for emissions generated from sinter strands:a review[J].Journal of Cleaner Production,2006,14(8):740-747.
[15]	彭犇,张业玲,岳昌盛,等.烧结除尘灰回用对烧结细颗粒排放的影响[J].环境工程,2018,36(12):151-154.
[16]	PENG C,GUO Z,ZHANG F.Discovery of potassium chloride in the sintering dust by chemical and physical characterization[J].ISIJ International,2008,48(10):1398-1403.
[17]	张梅.钢铁冶金含铁尘泥中氯化钾的回收[D].湘潭:湘潭大学,2015.
[18]	PENG C,ZHANG F,GUO Z.Separation and recovery of potassium chloride from sintering dust of ironmaking works[J].ISIJ International,2009,49(5):735-742.
[19]	PENG C,ZHANG F,LI H,et al.Removal behavior of Zn,Pb,K and Na from cold bonded briquettes of metallurgical dust in simulated RHF[J].ISIJ International,2009,49(12):1874-1881.
[20]	李志峰,林七女,董晓春,等.烧结机头除尘灰生产氯化钾的应用研究[J].中国资源综合利用,2010,28(2):13-15.
[21]	张福利,彭翠,郭占成.烧结电除尘灰提取氯化钾实验研究[J].环境工程,2009,27(增刊1):337-340.
[22]	ZHAN G,GUO Z.Water leaching kinetics and recovery of potassium salt from sintering dust[J].Transactions of Nonferrous Metals Society of China,2013,23(12):3770-3779.
[23]	张梅,付志刚,吴滨,等.钢铁冶金烧结机头电除尘灰中氯化钾的回收[J].过程工程学报,2014,14(6):979-983.
[24]	王彩虹,杨云虎,秦彩霞.酒钢冶炼工序除尘灰高效利用研究[J].矿冶工程,2015,35(3):103-105 ,110.
[25]	黄晓梅.炼铁烧结烟尘灰中氯化钾和银的提取研究.昆明理工大学.2015.
[26]	张静,薛彦辉,李伟杰,等.烧结机头灰化学浸出试验研究[J].烧结球团,2020,45(1):77-81.
