圆筒和褶皱滤袋过滤风速分布的数值模拟分析

闫彩莲; 林秀丽; 胡隆基; 柳静献

doi:10.13205/j.hjgc.202403028

圆筒和褶皱滤袋过滤风速分布的数值模拟分析

doi: 10.13205/j.hjgc.202403028

东北大学资源与土木工程学院, 沈阳 110819

基金项目:

国家重点研发计划项目(2022YFC2503201)

辽宁省教育厅基本科研面上项目(LJKMZ20220352)

详细信息

作者简介:
闫彩莲(1998-),女,硕士,主要研究方向为工业粉尘防治以及数值模拟研究。ycl0919@163.com

通讯作者:
林秀丽(1974-),女,副教授,主要研究方向为通风除尘理论与技术、安全科学理论及系统安全工程。linxiuli@mail.neu.edu.cn

计量
- 文章访问数: 84
- HTML全文浏览量: 16
- PDF下载量: 4
- 被引次数: 0
出版历程
- 收稿日期: 2023-02-03
- 网络出版日期: 2024-05-31

NUMERICAL SIMULATION ANALYSIS OF FILTRATION VELOCITY DISTRIBUTION OF CYLINDRICAL AND PLEATED FILTER BAGS

School of Resources and Civil Engineering, Northeastern University, Shenyang 110819, China

摘要

摘要: 为指导袋式除尘器滤袋由圆筒变为褶皱结构的升级改造设计,采用计算流体力学数值模拟方法对比分析了滤袋长度和结构、理论过滤风速、渗透率对圆筒滤袋和褶皱滤袋纵向过滤风速均匀性的影响,并分析了过滤风量不变时,将圆筒滤袋改造为不同长度褶皱滤袋后过滤风速分布的变化。结果表明,褶皱滤袋较同长度、同外径、同过滤风量圆筒滤袋过滤风速分布不均匀,且随袋长增加均匀性变差,袋长超过4 m的褶皱滤袋上部1/4处过滤风速迅速增大,甚至超过圆筒滤袋;随理论过滤风速的增加,褶皱滤袋下部过滤风速变化不大,但上部1/4处过滤风速迅速增大,故褶皱滤袋理论过滤风速的设置不宜过高,以<0.63 m/min为宜;随着滤袋渗透率的减小,滤袋整体过滤风速分布不均匀,褶皱滤袋差异性更加显著,因此其清灰阻力不宜过高。将L=8 m的圆筒滤袋改造为L=5~8 m的褶皱滤袋后,滤袋越长,理论过滤风速越小,过滤风速均匀性越差,综合考虑过滤风速及其均匀性两方面因素,建议将袋长设计为7 m。
- 过滤风速 /
- 滤袋长度 /
- 褶皱滤袋 /
- 袋式除尘器 /
- 数值模拟
Abstract: To guide the upgrading design of bag filter’s bag from cylindrical to pleated structure, the effects of filter bag length and structure, theoretical face velocity, and permeability on the vertical filtration velocity distribution uniformity of cylindrical and pleated filter bag were compared and analyzed by computational fluid dynamics numerical simulation method. The change of face velocity distribution after changing the cylindrical filter bag into a pleated filter bag with different lengths was analyzed under the condition of constant filter air volume. The results showed that along the length direction of the filter bag, the face velocity distribution of the pleated filter bag was more uneven than that of the same length, the same outer diameter and the same filter air volume cylindrical filter bag, and the uniformity became worse with the increase of the bag length. The face velocity at the upper 1/4 of the pleated filter bag with a bag length of more than 4 m increased rapidly and even exceeded the cylindrical filter bag. With the increase of the theoretical face velocity, the face velocity at the lower part of the pleated filter bag did not change much, but at the upper 1/4, velocity increased rapidly. Therefore, the setting of the theoretical face velocity of the pleated filter bag should not be too high. Under the conditions of this study, it was advisable to be 0.63 m/min below. With the decrease in permeability of the filter bag, the face velocity distribution was more uneven, and the difference along the pleated filter bag was more significant, so the cleaning pressure drop should not be too high. After transforming the cylindrical filter bag with L=8 m into the pleated filter bag with L=5 to 8 m, the longer the filter bag, the smaller the theoretical face velocity, but the worse the uniformity of the face velocity. Considering these two factors, face velocity and uniformity, it was recommended to be 7 m under the conditions of this study.
- face velocity /
- filter bag length /
- pleated filter bag /
- bag filter /
- numerical simulation

HTML全文

参考文献(19)

[1]	柳静献,毛宁,孙熙, 等.我国袋式除尘技术历史、现状与发展趋势综述[J].中国环保产业,2022(1):47-58.
[2]	张波波,赵宝杰,王志永.高效褶皱布袋在焦炉装煤除尘器中的应用[J].燃料与化工,2019,50(6):25-26 ,29.
[3]	杜然,舒刚,文福,等.钢铁企业矿焦槽除尘超低排放改造方案分析[J].建筑热能通风空调,2020,39(1):102-105.
[4]	KIM J S, LEE M H. Measurement of effective filtration area of pleated bag filter for pulse-jet cleaning[J]. Powder Technology, 2018.
[5]	ALI ERGVDENLER, TANG W S, CLIVE M H B, et al. Performance of high temperature fabric filters under gasification and combustion conditions[J]. Separation & Purification Technology, 1997, 11(1):1-16.
[6]	丁倩倩,李珊红,李彩亭,等.滤袋长度对袋式除尘器内流场影响的数值模拟研究[J].环境工程学报,2015,9(11):5521-5526.
[7]	乐文毅,段超龙,谢冬明.组合袋式除尘器的内部流场模拟[J].环境工程,2020,38(5):120-125 ,95.
[8]	刘威,仲兆平,刘瑾,等.基于CFD的袋式除尘器流场优化及漏袋模拟[J].环境工程,2022,40(11):84-91 ,142.
[9]	方璨,钱付平,叶蒙蒙,等.无纺针刺毡滤料褶式滤袋的阻力特性分析[J].过程工程学报,2020,20(3):285-293.
[10]	SUBRENAT A, BELLETTRE J, CLOIREC P L.3-D numerical simulations of flows in a cylindrical pleated filter packed with activated carbon cloth[J]. Chemical Engineering Science,2003, 58(22):4965-4973.
[11]	THÉRON F, JOUBERT A, LAURENCE L. Numerical and experimental investigations of the influence of the pleat geometry on the pressure drop and velocity field of a pleated fibrous filter[J]. Separation and Purification Technology, 2017, 182(56):69-77.
[12]	鲁进利,何杰,庄乾双,等. 基于CFD的双褶数滤袋阻力特性的数值模拟[J]. 中国粉体技术,2022,28(3):59-67.
[13]	SANGCHEOL P, YUN H J, JOONMOK S, et al. Non-uniform filtration velocity of process gas passing through a long bag filter[J]. Journal of Hazardous Materials,2019,365:440-447.
[14]	王福军. 计算流体动力学分析-CFD 软件原理与应用[M]. 北京:清华大学出版社, 2004:125-127.
[15]	FLUENT 6.3. 26, User's Guide, Fluent Inc.[R/OL]. https://www.academia.edu/43373884/FLUENT_6_3_Users_Guide.
[16]	许馨月,林秀丽,柳静献.数值模拟滤袋长度对除尘器流场及粉尘沉降的影响[J].环境工程学报,2022,16(9):2939-2948.
[17]	GENTRY B, IVAN B, HEEJIN C. A comprehensive review of particle loading models of fibrous air filters[J]. Journal of Aerosol Science,2023,167:1-34.
[18]	刘志强.袋式除尘器用滤料过滤性能的实验研究[D].沈阳:东北大学,2019.
[19]	林宏,邓晓东,陈奎续, 等.袋式除尘器除尘效率公式推导建立与工程验证[J].电力科技与环保,2022,38(1):43-48.
