质能耦合高温AOD渣处置不锈钢酸洗污泥工艺

冯晓明; 赵峥; 郁健; 张延玲

doi:10.13205/j.hjgc.202507002

质能耦合高温AOD渣处置不锈钢酸洗污泥工艺

doi: 10.13205/j.hjgc.202507002

冯晓明¹,
赵峥²,
郁健³,
张延玲^2, ,

1. 建龙钢铁控股有限公司, 北京 100070;
2. 北京科技大学绿色低碳钢铁冶金全国重点实验室, 北京 100083;
3. 北京北科环境工程有限公司, 北京 100083

基金项目:

国家重点研发计划项目（2019YFC1905701）

详细信息

作者简介:
冯晓明（1985—），男，工程师。937251421@qq.com

通讯作者:
张延玲（1972—），女，博士，教授。ustbzly1108@163.com

计量
- 文章访问数: 8
- HTML全文浏览量: 1
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-05-02
- 录用日期: 2024-08-05
- 修回日期: 2024-07-31
- 网络出版日期: 2025-09-11

A mass-energy coupling treatment process for stainless steel pickling sludge using high-temperature argon-oxygen decarburization （AOD） slag

1. Jianlong Steel Holdings Co., Ltd., Beijing 100070, China;
2. State Key Laboratory for Advanced Metallurgy, University of Science and Technology Beijing, Beijing 100083, China;
3. Beijing Beike Environmental Engineering Co., Ltd., Beijing 100083, China

摘要

摘要: 提出质能耦合处理不锈钢酸洗污泥工艺路线，以实现AOD渣能源资源双利用和酸洗污泥解毒。基于实验室实验、计算热力学与SEM-EDS分析，探究AOD渣-污泥混合体系中硫、铬、铁元素的分配与转化机制。结果显示，含碳酸洗污泥球团预处理时无含硫气体逸出，高温AOD渣浴还原时硫在气相中的分配比为0.55%、渣中固定率达99.68%，铬铁金属回收率约为90%。球团在高温AOD渣中的内在转化机制：内部还原由CaSO₄向CaS转变、FeCr₂O₄生成、Fe—Cr—C金属聚集长大，球团在熔渣中的溶解行为包括铁氧化物向Mg（Fe，Cr）₂O₄、Mg（Al，Cr）₂O₄转变，最终形成MgCr₂O₄的过程以及CaS在渣中的稳定化过程。该研究为二者协同处置的工业应用提供了依据。
- AOD熔渣 /
- 不锈钢酸洗污泥 /
- 质能耦合 /
- 物相转变 /
- 溶解路径
Abstract: A technical route for the coupled treatment of stainless steel pickling sludge based on mass-energy coupling is proposed in this paper. This process features a groundbreaking technical route， which can synergistically recover energy and resources from argon-oxygen decarburization （AOD） slag and carry out eco-friendly detoxification of hazardous pickling sludge. Through systematic laboratory experiments， combined with computational thermodynamics modeling and SEM - EDS analysis， the migration modes and phase transformation mechanisms of key elements（such as S， Cr， and Fe） in the molten AOD slag-sludge mixed system were studied. The results showed that during the pretreatment stage of carbon-containing pickling sludge particles， the risk of sulfur pollution was effectively suppressed， and no sulfur-containing gas emission was detected. Subsequently， in the thermal reduction stage in the AOD slag bath （operating temperature：1550℃）， the distribution ratio of sulfur in the gas phase was 0.55%， and the sulfur fixation rate in the slag phase reached 99.68% through the formation of stable sulfides. The recovery rate of high-value metal components mainly composed of Fe-Cr alloy was approximately 90%. The basic mechanism analysis revealed a multi-stage reaction pathway： the redox transformation within the particles involved sulfate reduction （CaSO₄→CaS）， spinel crystallization （formation of FeCr₂O₄）， and coarsening of metal particles （Fe—Cr—C）. The interfacial interactions during the slag dissolution process promoted the complex reconstruction of MgCr₂O₄ spinel while enabling the thermodynamically stable encapsulation of CaS in the slag matrix. This study lays a theoretical and technical foundation for the industrial-scale implementation of the energy-coupled co-processing system and presents a paradigm shift for the stainless steel manufacturing industry towards a circular economy.
- AOD slag /
- stainless steel pickling sludge /
- mass-energy coupling /
- phase transformation /
- dissolution pathway

HTML全文

参考文献(30)

[1]	WU M,LI Y,GUO Q,et al. Harmless treatment and resource utilization of stainless steel pickling sludge via direct reduction and magnetic separation[J]. Journal of Cleaner Production,2019,240:118187.
[2]	ZHAO J,ZHAO Z,SHI R,et al. Issues Relevant to Recycling of Stainless-Steel Pickling Sludge[J]. JOM,2018,70(12):2825-2836.
[3]	LI X M,JIA L F,ZOU C,et al. Progress and trend on comprehensive utilization of stainless steel pickling sludge[J]. Iron&Steel,2019,54(10):1-11.李小明,贾李锋,邹冲,等.不锈钢酸洗污泥资源化利用技术进展及趋势[J].钢铁,2019,54(10):1-11.
[4]	.谢高. 2022年全球不锈钢粗钢产量同比下降5.2%[N].中国冶金报,2023. XIE G. Global stainless steel crude steel production to fall 5.2% year-on-year in 2022[N]. China Metallurgical Newspaper,2023
[5]	CASTRO F,TAVARES P B,CRISTELO N,et al. Characterization of stainless steel spent pickling sludge and prospects for its valorization[J]. Metals,2022,12(9):1539.
[6]	LI G,WANG J,RAO M,et al. Coprocessing of stainless-steel pickling sludge with laterite ore via rotary kiln-electric furnace route enhanced desulfurization and metal recovery[J]. Process Safety and Environmental Protection,2020,142:92-98.
[7]	GU B S,PENG C,WANG N,et al. The current situation and prospects of resource utilization and disposal of stainless steel pickling sludge[J]. Journal of Iron and Steel Research,2024,36(8):975-990.顾宝澍,彭程,王宁,等.不锈钢酸洗污泥的资源化处置现状及展望[J].钢铁研究学报,2024,36(8):975-990.
[8]	YANG C,PAN J,ZHU D,et al. Pyrometallurgical recycling of stainless steel pickling sludge a review[J]. Journal of Iron and Steel Research International,2019,26(6):547-557.
[9]	LIU S,LI Q,WANG Z,et al. Metals droplet assembling mechanism during carbon reduction of stainless steel pickling sludge[J]. Journal of Cleaner Production,2020,247:119580.
[10]	WANG H,ZHANG G,CHOU K. Preparation of low-carbon and low-sulfur Fe-Cr-Ni-Si alloy by using CaSO₄-containing stainless steel pickling sludge[J]. Metallurgical and Materials Transactions B,2020,51(5):2057-2067.
[11]	ZHANG S,YANG J,LIU B,et al. One-step crystallization kinetic parameters of the glass-ceramics prepared from stainless steel slag and pickling sludge[J]. Journal of Iron and Steel Research International,2016,23(3):220-224.
[12]	PAN D A,LI L J,YANG J,et al. Production of glass-ceramics from heavy metal gypsum and pickling sludge[J]. International Journal of Environmental Science and Technology,2015,12(9):3047-3052.
[13]	CLAUDIU A,LUCIA M D,DANAADRIANA I. Study regarding the micro filler effect of sludge resulting from steel pickling[J]. Metals,2021,11(2):361.
[14]	BYOUNGSUN P,CHEOL C Y. Investigation of carbon-capture property of foam concrete using stainless steel AOD slag[J]. Journal of Cleaner Production,2020,288:125621.
[15]	XU Y,ZHANG Z Z,WANG B,et al. Curing influence factors and mechanism of stainless steel slag in AOD[J]. Iron&Steel,2017,52(8):43-47,80.许莹,张孜孜,王变,等.不锈钢AOD渣固化效果影响因素及其机理[J].钢铁,2017,52(8):43-47,80.
[16]	DI MARIA A,SALMAN M,DUBOIS M,et al. Life cycle assessment to evaluate the environmental performance of new construction material from stainless steel slag[J]. The International Journal of Life Cycle Assessment,2018,32(11):2091-2109.
[17]	LIU B,LI J,ZENG Y,et al. Toxicity assessment and geochemical model of chromium leaching from AOD slag[J]. Chemosphere,2016,144:2052-2057.
[18]	ZHANG X,NA H,LIU P,et al. A novel"two-step"γ → α,L → β phase transformation method for dicalcium silicate in AOD Slag for improving hydration activity[J]. Metallurgical and Materials Transactions,2023,54(2):712-733.
[19]	WANG H,ZHOU G,MU Y,et al. Enhanced carbon dioxide sequestration and Cr detoxification direct carbonation of AOD slag with additives under ambient conditions[J]. Journal of Cleaner Production,2024,443:141181.
[20]	HUANG L,WEI G,LAN Z,et al. Preparation and mechanism analysis of stainless steel AOD slag mixture base materials[J]. Materials,2024,17(5).
[21]	WU S,ZHANG S,ZHANG Y,et al. Reuse of vitrified argon oxygen decarburization slag as supplementary cementitious materials Comprehensive performance and chromium immobilization mechanism[J]. Construction and Building Materials,2022,348.
[22]	TAO M,WANG Y,LI J,et al. Slurry-phase carbonation reaction characteristics of AOD stainless steel slag[J]. Processes,2021,9(12):2266.
[23]	YANG Z Q,SAIYIN B,SHI Z K,et al. Study on the properties of C30 concrete prepared by multi-solid waste coupled cement[J]. Environmental Engineering,2023,41(3):143-147.杨志强,赛音巴特尔,时朝昆,等.多固废耦合水泥制备C30混凝土性能研究[J].环境工程,2023,41(3):143-147.
[24]	BARATI M,JAHANSHAHI S. Granulation and heat recovery from metallurgical slags[J]. Journal of Sustainable Metallurgy,2020,6(11):191-206.
[25]	DURINCK D,ENGSTRÖM F,ARNOUT S,et al. Hot stage processing of metallurgical slags[J]. Resources,Conservation&Recycling,2008,52(10):1121-1131.
[26]	LI Y,DAI W. Modifying hot slag and converting it into value-added materials:a review[J]. Journal of Cleaner Production,2018,175:176-189.
[27]	SONG W M,ZHOU J A,LI S,et al. Experimen on coal char reductive decomposition and sintering flue gas desulfurization gypsum[J]. Iron&Steel,2019,54(11):110-115.宋伟明,周建安,李数,等.煤焦还原分解烧结烟气脱硫石膏的试验[J].钢铁,2019,54(11):110-115.
[28]	WEI J,GONG L,ZUO D W,et al. Experimental studies on reduction desulfurization of pellets containing carbon of FGD gypsum from iron ore sintering process[J]. Energy for Metallurgical Industry,2023,42(1):17-21.韦杰,巩磊,左大文,等.烧结烟气脱硫石膏含碳球团还原脱硫实验研究[J].冶金能源,2023,42(1):17-21.
[29]	QI Q S,XU A J,HE D F,et al. Carbothermic reduction for recycling of iron and chromium from stainless steel slag[J]. Iron&Steel,2017,52(3):82-87.漆启松,徐安军,贺东风,等.碳热还原法回收不锈钢尾渣中铁和铬的试验[J].钢铁,2017,52(3):82-87.
[30]	WU T,ZHANG Y,ZHAO Z,et al. Effects of Fe₂O₃ on reduction process of Cr-containing solid waste self-reduction briquette and relevant mechanism[J]. Metals,2019,9(1):51.
