基于净水污泥与沸石制备的复合材料同步吸附去除沉积物所释放氮磷的研究

徐金兰; 何晨; 白文广; 荣悦彤; 刘璐; 许开慧; 李峰森; 刘宏伟

doi:10.13205/j.hjgc.202507004

基于净水污泥与沸石制备的复合材料同步吸附去除沉积物所释放氮磷的研究

doi: 10.13205/j.hjgc.202507004

徐金兰^1,2, ,,
何晨^1,2,
白文广^1,2,
荣悦彤^1,2,
刘璐^1,2,
许开慧^1,2,
李峰森^1,2,
刘宏伟^1,2,3

1. 西安建筑科技大学环境与市政工程学院, 西安 710055;
2. 陕西省环境工程重点实验室, 西安 710055;
3. 中圣环境科技发展有限公司, 西安 710076

基金项目:

陕西省秦创原“科学家+工程师”（2024QCY-KXJ-045）

详细信息

作者简介:
徐金兰（1973—），女，教授，主要研究方向为水处理理论与技术。xujinlan@xauat.edu.cn

通讯作者:
徐金兰（1973—），女，教授，主要研究方向为水处理理论与技术。xujinlan@xauat.edu.cn

计量
- 文章访问数: 16
- HTML全文浏览量: 2
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-10-19
- 录用日期: 2024-12-05
- 修回日期: 2024-11-20
- 网络出版日期: 2025-09-11

Simultaneous inhibition of nitrogen and phosphorus released from sediments using composite materials prepared from water purfication sludge and zeolite

XU Jinlan^{1,2
, ,},
HE Chen^1,2,
BAI Wenguang^1,2,
RONG Yuetong^1,2,
LIU Lu^1,2,
XU Kaihui^1,2,
LI Fengsen^1,2,
LIU Hongwei^1,2,3

1. College of Environmental and Municipal Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China;
2. Key Laboratory of Environmental Engineering, Shaanxi Province, Xi'an 710055, China;
3. Zhongsheng Environmental Technology Development Co., Xi'an 710076, China

摘要

摘要: 针对沉积物向上覆水释放营养盐和有机物导致水体发生富营养化的问题，拟采用原位覆盖技术对沉积物释放污染物进行去除实验。利用响应曲面法优化沸石的改性方法，并通过单因素实验探究净水厂污泥的最佳煅烧时间和温度。煅烧净水污泥和复合改性沸石，利用鸡蛋壳制备CaO₂，并用水泥作为黏合剂将其混合制备了覆合覆盖材料CCM（composite cover material），以实现长效释氧并同步强效去除氮磷。研究发现：CCM疏松多孔，并且存在丰富的含氧官能团增强吸附能力与吸附容量，其中存在的Ca²⁺、Al³⁺、Na⁺可促进NH₄⁺交换与磷酸盐的固定化。CCM的存在还可以诱导微生物生长，强化硝化反应，去除水体中TOC。经过3轮覆盖实验后，总氮、氨氮、总磷、正磷酸盐、TOC的去除率仍能达到81.75%、79.55%、86.64%、85.82%、29.16%。CCM作为一种环境友好型材料，使用寿命长，可在同步去除氮磷及有机物的同时诱导生态系统原生微生物生长，高效恢复水体活力。
- 废物利用 /
- 氮磷去除 /
- 响应曲面 /
- 生物诱导
Abstract: In response to nutrient and organic matter release from sediments into overlying water， which leads to eutrophication， an in-situ capping technology was proposed to mitigate pollution released from sediments in an experiment. The response surface method was used to optimize the modification method of zeolite， and a one-way experiment was conducted to determine the optimal calcination time and temperature for water purification plant sludge. The composite cover material（CCM） was prepared by calcining water purification sludge and composite-modified zeolite， preparing CaO₂ from eggshell， and mixing them with cement as a binder for long-lasting oxygen release and simultaneous efficient removal of nitrogen and phosphorus. It was found that the CCM was loose and porous， with abundant oxygen-containing functional groups that enhanced its adsorption capability and capacity. The presence of Ca²⁺， Al³⁺， and Na⁺ promoted the ion exchange with NH₄⁺ and the immobilization of phosphate. Additionally， the CCM could induce microbial growth， strengthen the nitrification reaction， and remove the TOC from the water body. After three rounds of capping experiments， total nitrogen， ammonia， total phosphorus， orthophosphate， and TOC were simultaneously and efficiently removed， achieving a removal rate of 81.75%， 79.55%， 86.64%， 85.82%， and 29.16%， respectively. CCM， as an environmentally friendly material with a long service life， promotes the growth of ecosystem-originating microorganisms while enabling the synchronous removal of nitrogen， phosphorus， and organic matter， thus efficiently restoring the ecological vitality of the water.
- waste utilization /
- nitrogen and phosphorus removal /
- response surface /
- biological induction

HTML全文

参考文献(33)

[1]	THRUSH S F,HEWITT J E,GLADSTONE GALLAGHER R V,et al. Cumulative stressors reduce the self-regulating capacity of coastal ecosystems[J]. Ecological Applications. 2021,31(1):e02223.
[2]	ZHANG W,SHEN J,WANG J. Linking pollution to biodiversity and ecosystem multifunctionality across benthic-pelagic habitats of a large eutrophic lake:a whole-ecosystem perspective[J]. Environmental Pollution,2021,285:117501.
[3]	RAO Q,SU H,RUAN L,et al. Stoichiometric and physiological mechanisms that link hub traits of submerged macrophytes with ecosystem structure and functioning[J]. Water Research,2021,202:117392.
[4]	LI X,XIE Q,CHEN S,et al. Inactivation of phosphorus in the sediment of the Lake Taihu by lanthanum modified zeolite using laboratory studies[J]. Environ Pollut,2019,247:9-17.
[5]	YU C,HUANG X,CHEN H,et al. Managing nitrogen to restore water quality in China[J]. Nature,2019,567(7749):516-520.
[6]	PAERL H W,XU H. Protecting global aquatic resources from the mountains to the sea:growing need for dual nutrient (N and P) input controls along the freshwater-to-marine continuum[J]. Science Bulletin,2023,68(1):21-24.
[7]	HU X Y,ZHU Y R,SUN F H,et al. Research on the influence mechanism of river nitrogen,phosphorus and water input on the eutrophication of Taihu Lake[J]. Research of Environmental Sciences,2022,35(6):1407-1418.胡晓燕,朱元荣,孙福红,等.河流氮磷和水量输入对太湖富营养化的影响机理研究[J].环境科学研究,2022,35(6):1407-1418.
[8]	GAO Y,WANG C,WANG P F,et al. Research on the reduction law and influencing factors of nitrogen and phosphorus in paddy field drainage water by drainage channels of different scales[J]. Environmental Engineering,2023,41(5):8-15.高阳,王超,王沛芳,等.不同尺度排水沟道对稻田退水中氮磷的削减规律及影响因素研究[J].环境工程,2023,41(5):8-15.
[9]	WAUER G,GONSIORCZYK T,KRETSCHMER K,et al. Sediment treatment with a nitrate-storing compound to reduce phosphorus release[J]. Water Research,2005,39(2/3):494-500.
[10]	ZHANG X,GU J,LIU Y. Necessity of direct energy and ammonium recovery for carbon neutral municipal wastewater reclamation in an innovative anaerobic MBR-biochar adsorption-reverse osmosis process[J]. Water Research,2022,211:118058.
[11]	TAN Y L,ZHONG X L,WANG T,et al. Research progress on the adsorption and removal of VOCs by zeolite molecular sieves[J]. Environmental Science and Technology,2023,46(2):178-189.谭映临,钟晓亮,王涛,等.沸石分子筛吸附去除VOCs的研究进展[J].环境科学与技术,2023,46(2):178-189.
[12]	HUANG H,YANG L,XUE Q,et al. Removal of ammonium from swine wastewater by zeolite combined with chlorination for regeneration[J]. Journal of Environmental Management,2015,160:333-341.
[13]	LI Y,FAN Y,LI X,et al. Evaluation of zeolite/hydrous aluminum oxide as a sediment capping agent to reduce nutrients level in a pond[J]. Ecological Engineering,2017,101:170-178.
[14]	LIU Q,LIN H,DONG Y,et al. Anion effect and mechanism of sodium modified clinoptilolite for ammonia nitrogen removal from aqueous solution[J]. Environmental Engineering Science,2018,35(7):710-719.
[15]	WU Y M,DENG L Z,ZHAO H,et al. Experimental study on the removal of ammonia-nitrogen from the sewage in highway service areas by artificial zeolite[J]. Industrial Water Treatment,2023,43(6):99-105.吴永明,邓利智,赵红,等.人造沸石去除高速公路服务区污水氨氮的实验研究[J].工业水处理,2023,43(6):99-105.
[16]	YU L,XU B F,TUO J Y,et al. Research progress on the treatment of ammonia-nitrogen wastewater by modified zeolite[J]. Industrial Safety and Environmental Protection,2021,47(9),88-92.喻岚,徐冰峰,庹婧艺,等.改性沸石处理氨氮废水的研究进展[J].工业安全与环保,2021,47(9):88-92.
[17]	ZHOU Z,LIU Q,LI S,et al. Characterizing the correlation between dephosphorization and solution pH in a calcined water treatment plant sludge[J]. Environmental Science and Pollution Research,2018,25(19):18510-18518.
[18]	ZHOU Y,HAYNES R J. Removal of Pb (II),Cr (III) and Cr (VI) from aqueous solutions using alum-derived water treatment sludge[J]. Water,Air,&Soil Pollution,2011,215(1-4):631-643.
[19]	WANG W H,WANG Y,ZHOU K,et al. Response mechanism of microorganisms to the inhibition of endogenous pollution release by calcium peroxide[J]. Sci Total Environ,2022,848:157708.
[20]	WATANABE Y,YAMADA H,KOKUSEN H,et al. Ion exchange behavior of natural zeolites in distilled water,hydrochloric acid,and ammonium chloride solution[J]. Separation science and technology,2003,38(7):1519-1532.
[21]	GAO S J,WANG C H,PEI Y S. Phosphorus adsorption effect of thermally and acid-activated waste ferric and alum sludge from water treatment plants[J]. Acta Scientiae Circumstantiae,2012,32(3):606-611.高思佳,王昌辉,裴元生.热活化和酸活化给水处理厂废弃铁铝泥的吸磷效果[J].环境科学学报,2012,32(3):606-611.
[22]	TANTAWY M A. Characterization and pozzolanic properties of calcined alum sludge[J]. Materials Research Bulletin,2015,61:415-421.
[23]	WEI C,CHEN T,JIANG Q,et al. Removal of ammonia-nitrogen from black-odorous river water by PVA/sodium alginate-immobilized micron-sized zeolite powder[J]. Environmental Science,2012,42(12):5884-5895.魏超,陈涛,江桥,等.黑臭河道中聚乙烯醇/海藻酸钠固定微米沸石粉去除氨氮[J].环境科学,2021,42(12):5884-5895.
[24]	LIN C Y,TIAN W M,YE P C. Preparation of river sediment active cover plate and its inhibitory effect on the release of nitrogen and phosphorus from urban inland river sediment[J]. Chinese Journal of Environmental Engineering,2021,15(6):1927-1936.林灿阳,田委民,叶沛成.河流底泥活性覆盖板的制备及其对城市内河底泥氮磷释放的抑制效果[J].环境工程学报,2021,15(6):1927-1936.
[25]	BAO T,CHEN T,WILLE M,et al. Synthesis,application and evaluation of non-sintered zeolite porous filter (ZPF) as novel filter media in biological aerated filters (BAFs)[J]. Journal of environmental chemical engineering. 2016,4(3):3374-3384.
[26]	WANG Y,YUAN S,LIU S,et al. Removal efficacy and mechanism of nitrogen and phosphorus by biological aluminum-based P-inactivation agent (BA-PIA)[J]. Journal of Environmental Sciences,2023,127:187-196.
[27]	LIU Y,LIU X,WANG H,et al. Pyrite coupled with steel slag to enhance simultaneous nitrogen and phosphorus removal in constructed wetlands[J]. Chemical Engineering Journal,2023,470:143944.
[28]	ZHANG M K,YANG H W,DU M Y,et al. Adsorption characteristics of modified zeolite for ammonia-nitrogen in secondary biochemical effluent[J]. Chinese Journal of Environmental Engineering,2020,14(4),896-905.仉铭坤,杨红薇,杜明阳,等.改性沸石对二级生化出水中氨氮的吸附特性[J].环境工程学报,2020,14(4):896-905.
[29]	FU H,LI Y,YU Z,et al. Ammonium removal using a calcined natural zeolite modified with sodium nitrate[J]. Journal of Hazardous Materials,2020,393:122481.
[30]	LI W,ZENG L,KANG Y,et al. A solid waste,crashed autoclaved aerated concrete,as a crystalline nucleus for the removal of low concentration of phosphate[J]. Desalination and Water Treatment,2015(57):14169-14177.
[31]	KUŹNIARSKA-BIERNACKA I,FONSECA A M,NEVES I C. Manganese complexes with triazenido ligands encapsulated in NaY zeolite as heterogeneous catalysts[J]. Inorganica Chimica Acta,2013,394:591-597.
[32]	CHU J,XUE J H,JIN M J,et al. Research progress on the influence of biochar on the loss of nitrogen and phosphorus in agricultural non-point source pollution[J]. Journal of Ecology and Rural Environment,2014:,30(4):409-415.褚军,薛建辉,金梅娟,等.生物炭对农业面源污染氮、磷流失的影响研究进展[J].生态与农村环境学报,2014,30(4):409-415.
[33]	PAN X H. Experimental study on the adsorption of ammonia-nitrogen in water by natural and modified zeolite[D]. Nanchang:East China Jiaotong University,2020.盘贤豪.天然及改性沸石吸附水中氨氮的实验研究[D].南昌:华东交通大学,2020.
