不同HRT挂膜策略对生物膜启动阶段生物量及种群结构的影响

江乐勇; 赵颖出; 孙事昊; 邢亿园; 王博; 彭永臻; 张璐晶; 庞洪涛; 杨慎华

doi:10.13205/j.hjgc.202509009

不同HRT挂膜策略对生物膜启动阶段生物量及种群结构的影响

doi: 10.13205/j.hjgc.202509009

1. 信开环境投资有限公司, 北京 101101;
2. 北京工业大学城镇污水处理与资源化利用技术国家工程实验室, 北京 100024;
3. 中国社会科学院数量经济与技术经济研究所, 北京 100732

基金项目:

北京市通州区科技创新人才资助项目（CXTD2023004）；国家自然科学基金面上项目（22176007）

详细信息

作者简介:
江乐勇（1981—），男，博士，高级工程师，主要研究方向为城市水污染控制与水环境治理。jiangleyong@sdic.com.cn

通讯作者:
孙事昊（1991—），男，博士，高级工程师，主要研究方向为城市污水脱氮除磷与生物除臭。ssh_fire@163.com

计量
- 文章访问数: 22
- HTML全文浏览量: 6
- PDF下载量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2024-11-26
- 网络出版日期: 2025-11-05
- 刊出日期: 2025-09-01

Effects of hydraulic retention time on biofilm attachment in moving bed biofilm reactors for aspects of biomass and microbial community structure

1. Xinkai Environment Investment Co., Ltd., Beijing 101101, China;
2. National Engineering Laboratory for Advanced Municipal Wastewater Treatment and Reuse Technology, Beijing University of Technology, Beijing 100024, China;
3. Institute of Quantitative & Technological Economics, CASS, Beijing 100732, China

摘要

摘要: 挂膜是生物膜工艺运行的关键步骤，水力停留时间（HRT）是其关键影响因素之一。建立4个纯生物膜反应器，以北方某污水处理厂原水作为进水，探究不同HRT对生物膜量、生物膜种群结构的影响。试验结果显示：短HRT策略（2 h）在挂膜前15 d生物膜量可达到（21.23±1.2） mg SS/carrier，相比不进水、长HRT策略（6 h）和长短HRT切换（6 h→2 h）3种策略，在挂膜前期具有显著的优势。扫描电镜（SEM）和高通量测序（Illumina Miseq）分析15，32，57 d的样品的结果显示，4个反应器生物膜群落结构均随挂膜时间的延长发生了显著变化，变多的菌属主要有Acinetobacter属、Pseudomonas属，变少的菌属主要有Ottowia属、Acidovorax属等。但是，不同HRT策略之间群落结构的α多样性H检验、β多样性ANOSIM/Adonis检验结果均显示出4组之间无显著性差异。这说明不同HRT策略会影响生物膜量，但对生物膜群落结构的影响不显著，基于此结论提出了“先挂膜再驯化”的功能性生物膜启动方法。
- 生物膜 /
- 挂膜 /
- 纯生物膜反应器 /
- MBBR
Abstract: Formation process is a key step for a moving bed biofilm reactor （MBBR）， and the hydraulic retention time （HRT） is one of the key influencing factors. This study established four biofilm reactors， using raw water from a sewage treatment plant as the influent to explore the effects of different HRT strategies on biomass and microbial community structure of biofilm. Results revealed that the short HRT strategy （2 h） achieved a biomass of （21.23±1.2） mg SS/carrier in 15 d， which showed significant advantages compared with the three strategies： no water intake， long HRT strategy （6 h） and long-short HRT switching strategy （6 h → 2 h）. SEM and MiSeq Illumina analysis of the samples at 15 d， 32 d， and 57 d revealed that the microbial community structure of the biofilm changed significantly over time. Acinetobacter and Pseudomonas were the main genera with an increasing trend， while Ottowia and Acidovorax were the main genera with a decreasing trend. However， the H-test for α-diversity and the ANOSIM/Adonis test for β-diversity of the microbial community structure revealed no significant differences among the four groups under different HRT strategies. This indicates that different HRT strategies influence the biomass of the biofilm but have no significant effect on its microbial community structure. Based on these findings， this study proposes a functional biofilm initiation method described as "biofilm attachment first， domestication afterward".
- biofilm /
- biofilm attachment /
- pure biofilm reactor /
- MBBR

HTML全文

参考文献(35)

[1]	WANG K，KE S Z，YUAN H Z，et al. Effect of ammonia-nitrogen concentration on microbial community structure in a mbbr process[J]. Environmental Engineering，2020，38（9）:119-125. 王坤，柯水洲，袁辉洲，等. 氨氮浓度对MBBR工艺中微生物群落结构的影响[J]. 环境工程，2020，38（9）:119-125.
[2]	ZHANG J H，PENG Y Z，ZHANG M，et al. Start-up and steady operation of simultaneous nitrification and denitrification in SBBR treating low C/N ratio domestic wastewater[J]. CIESC Journal，2016，67（11）:4817-4824. 张建华，彭永臻，张淼，等. 同步硝化反硝化SBBR处理低C/N比生活污水的启动与稳定运行[J]. 化工学报，2016，67（11）:4817-4824.
[3]	PERSSON F，SUAREZ C，HERMANSSON M，et al. Community structure of partial nitritation‐anammox biofilms at decreasing substrate concentrations and low temperature[J]. Microbial Biotechnology，2016，10:761-772.
[4]	LI J W，PENG Y Z，ZHANG L，et al. Quantify the contribution of anammox for enhanced nitrogen removal through metagenomic analysis and mass balance in an anoxic moving bed biofilm reactor[J]. Water Research，2019，160:178-187.
[5]	ZHANG X C，MIAO Y Y，YU D S，et al. Culturing partial denitrification biofilm in side stream incubator with ordinary activated sludge as inoculum:one step closer to mainstream anammox upgrade[J]. Bioresource Technology，2022，347:126679.
[6]	ZHAO Q，CHEN K Q，LI J W，et al. Pilot-scale evaluation of partial denitrification/anammox on nitrogen removal from low cod/n real sewage based on a modified process[J]. Bioresource Technology，2021，338:125580.
[7]	YANG S H，ZHANG L J，PENG Y Z，et al. Research advances of enhancing biofilm formation of ANAMMOX[J]. Environmental Engineering，2024，42（1）:1-8. 杨慎华，张璐晶，彭永臻，等. 强化厌氧氨氧化生物膜形成的研究进展[J]. 环境工程，2024，42（1）:1-8.
[8]	ZHANG Y，WANG S Y，ZHAO W H，et al. Start-up of pilot-scale AAO-BAF two-sludge system[J]. CIESC Journal，2015，66（10）:4228-4235. 张勇，王淑莹，赵伟华，等. 中试规模AAO-曝气生物滤池双污泥系统的启动运行[J]. 化工学报，2015，66（10）:4228-4235.
[9]	DONG K，QIU Y L，WANG X X，et al. Towards low carbon demand and highly efficient nutrient removal:establishing denitrifying phosphorus removal in a biofilm-based system[J]. Bioresource Technology，2023，372:128658.
[10]	HE Q，HAO J G. National survey and design registered public equipment engineers water supply and drainage professional qualification examination textbook volume 2 drainage[M]. Beijing:China Building Industry Press，2024:274. 何强，赫俊国. 全国勘察设计注册公用设备工程师给水排水专业执业资格考试教材第2册排水[M]. 北京:中国建筑工业出版社，2024:274.
[11]	GU Q Y，SUN T C，WU G，et al. Influence of carrier filling ratio on the performance of moving bed biofilm reactor in treating coking wastewater[J]. Bioresource Technology，2014，166:72-78.
[12]	PECHAUD Y，LAVIGNE M P，BESSIERE Y E，et al. Influence of shear stress，organic loading rate and hydraulic retention time on the biofilm structure and on the competition between different biological aggregate morphotypes[J]. Journal of Environmental Chemical Engineering，2022，10:107597.
[13]	HOU F，WANG K J，SHAO Y Q，et al. Upgrading project of Bishui underground wastewater treatment plant and ecological complex construction[J]. China Water & Wastewater，2017，33（10）:54-58. 侯锋，王凯军，邵彦青，等. 北京碧水下沉式再生水厂升级改造及生态综合体建设[J]. 中国给水排水，2017，33（10）:54-58.
[14]	SUN S H，JIA T P，CHEN K Q，et al. Simultaneous removal of hydrogen sulfide and volatile organic sulfur compounds in off-gas mixture from a wastewater treatment plant using a two-stage bio-trickling filter system[J]. Frontiers of Environmental Science & Engineering，2019，13:1-13.
[15]	ZHENG Z J，WU D，ZHANG J J，et al. Denitrification performance of a two-stage post-MBBR[J]. Environmental Engineering，2019，37（9）:68-73. 郑志佳，吴迪，张晶晶，等. 两级后置纯膜MBBR的反硝化性能研究[J]. 环境工程，2019，37（9）:68-73.
[16]	WIJEYEKOON S，MINO T，SATOH H，et al. Effects of substrate loading rate on biofilm structure[J]. Water Research，2004，38:2479-2488.
[17]	GUO J H，WANG S Y，ZHENG Y N，et al. Assessment of partial nitrification achieved by real-time aeration duration control through microbial population shift using FISH and SEM[J]. Journal of Harbin Institute of Technology，2010，42（8）:1259-1263. 郭建华，王淑莹，郑雅楠，等. 实时控制实现短程硝化过程中种群结构的演变[J]. 哈尔滨工业大学学报，2010，42（8）:1259-1263.
[18]	BöHNING J，TARAFDER A K，BHARAT T A M. The role of filamentous matrix molecules in shaping the architecture and emergent properties of bacterial biofilms[J]. Biochemical Journal，2024，481:245-263.
[19]	BOTTERO S，STORCK T，HEIMOVAARA T J，et al. Biofilm development and the dynamics of preferential flow paths in porous media[J]. Biofouling，2013，29:1069-1086.
[20]	FLEMMING H C，NEU T R，WOZNIAK D J. The eps matrix:the"house of biofilm cells"[J]. Journal of Bacteriology，2007，189:7945-7947.
[21]	LIU H，TIAN W X，IBRAHIM M，et al. Characterization of pilp，a gene required for twitching motility，pathogenicity，and biofilm formation of acidovorax avenae subsp. avenae Rs-1[J]. European Journal of Plant Pathology，2012，134:551-560.
[22]	YANG Y W，FEI N Y，JI W Q，et al. Pila gene contributes to virulence，motility，biofilm formation，and interspecific competition of bacteria in Acidovorax citrulli[J]. Microorganisms，2023，11:1806.
[23]	HIDALGO-CANTABRANA C，SáNCHEZ B，MILANI C，et al. Genomic overview and biological functions of exopolysaccharide biosynthesis in bifidobacterium Spp[J]. Applied and Environmental Microbiology，2014，80:9-18.
[24]	ALENEZI F N，REKIK I，BOUKET A C，et al. Increased biological activity of aneurinibacillus migulanus strains correlates with the production of new gramicidin secondary metabolites[J]. Frontiers in Microbiology，2017，8:517.
[25]	RAUTENBACH M，EYéGHé-BICKONG H A，VLOK N M，et al. Direct surfactin-gramicidins antagonism supports detoxification in mixed producer cultures of bacillus subtilis and aneurinibacillus migulanus[J]. Microbiology，2012，158:3072-3082.
[26]	WEI J，HUANG X，WANG H J，et al. Insight into biofilm formation of wastewater treatment processes:nitrogen removal performance and biological mechanisms[J]. Science of the Total Environment，2023，903:166550.
[27]	MENG F G，GUO S X，ZHANG L D，et al. Ecological mechanisms of biofilm development in the hybrid sludge-biofilm process:implications for process start-up and optimization[J]. Water Research，2023，245:120587.
[28]	D A VAN BERGEIJK，TERLOUW B R，MEDEMA M H，et al. Ecology and genomics of actinobacteria:new concepts for natural product discovery[J]. Nature Reviews Microbiology，2020，18:546-558.
[29]	MAHTO K U，DAS S. Bacterial biofilm and extracellular polymeric substances in the moving bed biofilm reactor for wastewater treatment:a review[J]. Bioresource Technology，2022，345:126476.
[30]	MAURYA A，KUMAR R，RAJ A. Biofilm-based technology for industrial wastewater treatment:current technology，applications and future perspectives[J]. World Journal of Microbiology and Biotechnology，2023，39:112.
[31]	WANG K，ZHOU C T，ZHOU H，et al. Comparison on biological nutrient removal and microbial community between full-scale anaerobic/anoxic/aerobic process and its upgrading processes[J]. Bioresource Technology，2023，374:128757.
[32]	NAZ I，HODGSON D，SMITH A，et al. Investigation of the active biofilm communities on polypropylene filter media in a fixed biofilm reactor for wastewater treatment[J]. Journal of Chemical Technology & Biotechnology，2018，93:3264-3275.
[33]	FANG D X，WU A Q，HUANG L P，et al. Polymer substrate reshapes the microbial assemblage and metabolic patterns within a biofilm denitrification system[J]. Chemical Engineering Journal，2020，387:124128.
[34]	KOWALSKI M S，DEVLIN T R，OLESZKIEWICZ J A. Attachment of anaerobic ammonium-oxidizing bacteria to augmented carrier material[J]. Environmental Technology，2017，40:576-583.
[35]	NIEDERDORFER R，FRAGNER L，YUAN L，et al. Distinct growth stages controlled by the interplay of deterministic and stochastic processes in functional anammox biofilms[J]. Water Research，2021，200:117225.
