生活污水混凝-动态吸附强化碳源磷源捕获的工艺特性研究

赵梓程; 周柯; 陈荣

doi:10.13205/j.hjgc.202509014

生活污水混凝-动态吸附强化碳源磷源捕获的工艺特性研究

doi: 10.13205/j.hjgc.202509014

赵梓程^1,2,
周柯²,
陈荣^2, ,

1. 西安建筑科技大学资源工程学院, 西安 710055;
2. 西安建筑科技大学西北水资源与环境生态教育部重点实验室, 西安 710055

基金项目:

国家重点研发项目“城市污水能量与资源回收关键技术及装备”（2022YFC3203102）

详细信息

作者简介:
赵梓程，男，硕士研究生，主要研究方向为废水资源化。2367042880@qq.com

通讯作者:
陈荣（1980—），博士，教授，主要研究方向为废水处理与资源化。chenrong@xauat.edu.cn

计量
- 文章访问数: 50
- HTML全文浏览量: 19
- PDF下载量: 1
- 被引次数: 0
出版历程
- 收稿日期: 2025-02-14
- 网络出版日期: 2025-11-05
- 刊出日期: 2025-09-01

Study on process characteristics of coagulation-dynamic adsorption for carbon source and phosphorus source from domestic wastewater

ZHAO Zicheng^1,2,
ZHOU Ke²,
CHEN Rong^{2
, ,}

1. School of Resources Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China;
2. Key Laboratory of Northwest Ministry of Water Resources, Environment and Ecology, Xi'an University of Architecture and Technology, Xi'an 710055, China

摘要

摘要: 生活污水排放量大且有资源回收潜力，浓缩有机物对收集污水能源意义重大。目前，混凝沉淀法是污水浓缩的主流手段。以西安市思源学院下设水厂实际污水为研究对象，探究混凝剂种类、投加量、沉淀时间、初始pH值对碳源捕获及磷源富集效果的影响。通过生物炭动态吸附柱工艺进一步处理混凝出水，使出水主要指标符合GB 18918—2002《城镇污水处理厂污染物排放》一级A标准。随后通过超声辅助解吸-复吸循环实验，提升解吸率并对氯化铁改性玉米芯生物炭的可循环利用特性进行探究。研究发现：当混凝剂为 FeCl₃·6H₂O，投加混凝液300 mg/L，沉淀时间30 min，初始pH = 6时，COD 捕获率最高达 67.76%，总磷与磷酸盐富集率超 98%；改性玉米芯生物炭动态吸附柱高度45 cm，进水流速4 mL/min时，连续工作5 h内，出水主要指标达GB 18918—2002《城镇污水处理厂污染物排放标准》一级A标准；HCl作为解吸液效果理想，且可作为pH调节剂回用于混凝实验，实现资源循环利用。在0.5 mol/L HCl、25 ℃、超声时间75 min条件下，COD与NH₄⁺-N的解吸率分别提升至（94.65±0.01）%、（94.25±0.05）%，接近体系理论极限，同时解吸时间降幅分别达83.3%与92.2%。经5次解吸-复吸循环实验，改性玉米芯生物炭仍能吸附50%以上的COD与NH₄⁺-N。该研究成果为污水处理厂废水净化和资源回收利用提供了科学依据。
- 混凝法 /
- 动态吸附柱 /
- 碳磷捕获 /
- 超声辅助 /
- 循环利用
Abstract: Domestic wastewater， characterized by its substantial discharge volume and resource recovery potential， holds significant importance for energy recovery through the concentration of organic matter. Currently， coagulation-sedimentation stands as the predominant method for wastewater concentration. This study investigated coagulation process optimization using wastewater from the treatment plant of Xi'an Siyuan University， focusing on the impacts of coagulant type （FeCl₃·6H₂O vs. PAC）， dosage （30~500 mg/L）， sedimentation time （15~120 min）， and initial pH （3~8） on carbon source capture and phosphorus enrichment. A subsequent dynamic biochar adsorption column （45 cm height， 4 mL/min flow rate） was employed to further treat coagulated effluent， achieving compliance with Class 1A in Discharge Standard of Pollutants for Municipal Wastewater Treatment Plant ［ρ（COD） < 50 mg/L， ρ（NH₄⁺-N） < 5 mg/L］. Ultrasonic-assisted desorption-regeneration cycles （0.5 mol/L HCl， 30°C， 75 min ultrasonication） enhanced desorption efficiency while enabling closed-loop resource recovery through the reuse of HCl for pH adjustment.Key findings include：Optimal coagulation at 300 mg/L FeCl₃·6H₂O， 30 min sedimentation， and pH value of 6， achieved 67.76% COD capture and >98% TP/PO₄^3--P enrichment. Modified corncob biochar maintained >50% COD/NH₄⁺-N adsorption capacity after 5 regeneration cycles. Ultrasonic desorption boosted COD/NH₄⁺-N desorption rates to （94.65±0.01）% and （94.25±0.05）%， respectively， with process duration reduced by 83.3% to 92.2% versus the conventional methods.This integrated strategy provides a scientifically validated solution for simultaneous wastewater purification and resource recovery， aligning with circular economy principles in municipal wastewater treatment.
- coagulation method /
- dynamic adsorption column /
- carbon and phosphorus capture /
- ultrasonic-assisted /
- recycling

HTML全文

参考文献(41)

[1]	YANG Y，DENG W H，HU Y S，et al. Research progress on the recovery of energy from urban sewage by carbon capture-anaerobic digestion coupling technology[J]. Environmental Engineering，2023，41（5）:213-221.
[2]	HENG L B，WU Z J，ZHANG H Q，et al. Removal characteristics of phosphorus and dissolved organic matter and coagulation mechanism in medium-loaded coagulation process[J]. Chinese Journal of Environmental Engineering，2020，14（12）:3352-3362.
[3]	WANG L，PAN L. Research progress of sewage carbon capture technology based on cases[J]. Technology of Water Treatment，2023，49（9）:19-22
[4]	XU G R，ZHANG W T，LI G B. Adsorbent obtained from CEPT sludge in wastewater chemically enhanced treatment[J]. Water research，2005，39（20）:5175-5185.
[5]	SHEWA W A，DAGNEW M. Revisiting chemically enhanced primary treatment of wastewater:A review[J]. Sustainability，2020，12（15）:5928.
[6]	REN J Z，LI J，WANG C C，et al. Influence of ferric chloride on operating efficiency and membrane fouling of A/O-MBR process[J]. China Water & Wastewater，2014，30（13）:27-32.
[7]	KANG S，LI Q X，WU Z J，et al. Research on pollutant characteristics and mechanism of magnetic coagulation for removing pollutants from black and odorous water bodies[J]. Technology of Water Treatment，2021，47（10）:24-28.
[8]	CHANG S L，GAO Q，WEI J Y，et al. Adsorption characteristics of calcium-modified corncob biochar for nitrogen and phosphorus in water[J]. Chinese Journal of Environmental Engineering，2024，18（2）:481-491
[9]	CHENG Y S，HE H，LIU Y. Removal efficiency and mechanism of turbidity，ammonia nitrogen and total phosphorus in black and odorous water by magnetic flocculation-adsorption technology[J]. Chinese Journal of Environmental Engineering，2022，16（2）:481-493.
[10]	LI W J，LI J，ZHANG Y Z，et al. Adsorption mechanism of NaCl-modified zeolite for ammonia-nitrogen in water[J]. China Environmental Science，2016，36（12）:3675-3682.
[11]	HE M Z，ZHANG M D，CHEN Q P，et al. Preparation of low-cost seawater-modified biochar particles and their dynamic adsorption performance for phosphorus in Water[J]. Chinese Journal of Environmental Engineering，2023，17（2）:380-389.
[12]	DENG J，FANG Y，HOU C，et al. Ultrasonic assisted activation of persulfate for the treatment of spent porous biochar:Degradation of adsorbed PFOA and adsorbent regeneration[J]. Journal of Environmental Chemical Engineering，2023，11（6）:111146.
[13]	SAJJADI B，BROOME J W，CHEN W Y，et al. Urea functionalization of ultrasound-treated biochar:a feasible strategy for enhancing heavy metal adsorption capacity[J]. Ultrasonics sonochemistry，2019，51:20-30.
[14]	ZHOU B. Operation effect of phosphorus and nitrogen removal in improved A²/O process[J]. China Water & Wastewater，2001，17（7）:46-48.
[15]	CHEN L，CAO Y，ZHANG R Z，et al. Pretreatment process of long-chain dicarboxylic acid production wastewater based on ettringite precipitation method[J]. Chinese Journal of Environmental Engineering，2023，17（7）:2169-2180.
[16]	JIA H，NIU J R，GAO W，et al. Degradation of tetracycline by cobalt-loaded biochar activating PMS dominated by electron transfer[J]. Acta Scientiae Circumstantiae，2024，44（3）:51-60.
[17]	LI Z H，YANG K，WU Y H. Advanced treatment of municipal sewage by coagulation-carbonized sludge adsorption[J]. Chinese Journal of Environmental Engineering，2012，6（7）:2356-2360.
[18]	ZHANG J，ZHANG Z G，HE C，et al. Research on the treatment of selenium-containing wastewater from flour mills by coagulation and electrocoagulation methods[J/OL]. Industrial Water Treatment，1-16[ 2025-02-11].
[19]	LI S Y，PENG H J，HU Y J，et al. Optimization of coagulation conditions for water-based paint washing wastewater[J]. Chinese Journal of Environmental Engineering，2017，11（3）:1587-1592.
[20]	YANG W J，QI J，YANG Q Y，et al. Treatment of high-turbidity acrylic emulsion wastewater by PAC with PDMDAAC as coagulant aid[J]. Industrial Water Treatment，2023，43（1）:102-107.
[21]	XIE H N，LI J，ZHU X Y，et al. Optimization of coagulation treatment of high-turbidity Yellow River Water in summer by response surface methodology[J]. Industrial Water Treatment，2020，40（2）:45-49.
[22]	LÓPEZ-MALDONADO E A，Oropeza-Guzman M T，Jurado-Baizaval J L，et al. Coagulation-flocculation mechanisms in wastewater treatment plants through zeta potential measurements[J]. Journal of hazardous materials，2014，279:1-10.
[23]	YAN Q，ZHOU N N，XU J. Optimization experiment on hydraulic conditions for enhanced coagulation treatment of a slightly polluted source water in Southern Jiangxi[J]. Technology of Water Treatment，2013（12）:108-111.
[24]	LIANG J，YANG Q，DING R，et al. Influence of coagulant dosage on water quality and variation characteristics of floc size[J]. Water & Wastewater Engineering，2012（S1）:56-60.
[25]	GIL C，PATRICK W，MATTHEW M. Enhanced coagulation:its effect on NOM removal and chemical costs[J]. Journal，1995，87（1）:78-89.
[26]	WANG D S，LIU H L，YAN M Q，et al. Enhanced coagulation and optimized coagulation:necessity，research progress and development trends[J]. Acta Scientiae Circumstantiae，2006，26（4）:559-565.
[27]	XIAO Y. Study on the Efficiency of removing Sb（Ⅲ）and Sb（Ⅴ）from water by coagulation-sedimentation method and the influence of matrix[D]. Xi'an:Xi'an University of Architecture and Technology，2021.
[28]	REN P F，JIANG B Y，HE N H，et al. Efficiency of coagulation/premarket oxidation in removing cylindrospermopsis raciborskii from slightly polluted source water[J]. China Water & Wastewater，2019，35（11）:68-73.
[29]	CHENG W F，LI H，YANG Y Q，et al. Preparation of biochar by pyrolysis of anaerobic fermentation residue of municipal sludge and its adsorption of nitrogen and phosphorus[J]. CIESC Journal，2016，67（4）:1432-1439.
[30]	YIN Q，LIU M，REN H. Biochar produced from the co-pyrolysis of sewage sludge and walnut shell for ammonium and phosphate adsorption from water[J]. Journal of Environmental Management，2019，249:109410.
[31]	SONG G. Adsorption and mechanism of ammonia nitrogen in water by reed biochar[D]. China Jiliang University，2020.
[32]	PAN J. Preparation of red mud-based granular adsorbent and its adsorption of nitrogen and phosphorus in water[D]. Guangxi University，2015.
[33]	XIAO Q L，XIONG L P，PENG H，et al. Study on the adsorption capacity of different substrate combinations for nitrogen and phosphorus[J]. Research of Environmental Sciences，2022，35（5）:1277-1287.
[34]	YU J，DING H，ZHANG Z L，et al. Adsorption performance and mechanism of modified water chestnut shell biochar for oxytetracycline in water[J]. China Environmental Science，2021，41（12）:5688-5700.
[35]	OUYANG T T，CAI C，LIN S N，et al. Passivation and remediation of cadmium-contaminated soil by carbon-based and phosphorus-based composite materials[J]. Chinese Journal of Environmental Engineering，2021，15（9）:2998-3007.
[36]	SONG X B，HE S Y，FENG Y F，et al. Preparation of lanthanum-loaded magnetic hydrothermal biochar and its phosphorus-removal performance[J]. Environmental Science，2020，41（2）:789-797.
[37]	YANG J Z，YANG F，ZHONG Y X，et al. Phosphorus adsorption performance and desorption characteristics of ethyleneamine-modified biochar chelated metal materials[J]. Environmental Chemistry，2025，44（2）:512-523.
[38]	ZENG T T，LI J，LI X X，et al. Hydrothermal synthesis of dairy manure hydrochar in the medium of KMnO_4 solution and its adsorption properties for Pb（Ⅱ）[J]. Environmental Chemistry，2016，35（10）:2105-2113.
[39]	ZHOU C Y，TANG X F，QU X L，et al. Fluoride removal performance and mechanism of Ce-BDC-Derived carbon[J]. Chinese Journal of Environmental Engineering，2023，17（10）:3190-3199.
[40]	ZHANG Y，GUO X，WU F，et al. Mesocarbon microbead carbon-supported magnesium hydroxide nanoparticles:turning spent Li-ion battery anode into a highly efficient phosphate adsorbent for wastewater treatment[J]. ACS Applied Materials & Interfaces，2016，8（33）:21315-21325.
[41]	TAOUFIK N，BOUMYA W，JANANI F Z，et al. Removal of emerging pharmaceutical pollutants:a systematic mapping study review[J]. Journal of Environmental Chemical Engineering，2020:104251.
