MnPO/TiO<sub>2</sub>催化剂低温脱硝性能及反应物吸附特性研究

李小海; 姜东生; 程贤卿; 刘翔; 丁正宇; 贾勇; 龙红明

doi:10.13205/j.hjgc.202511011

MnPO/TiO₂催化剂低温脱硝性能及反应物吸附特性研究

doi: 10.13205/j.hjgc.202511011

1. 大唐南京环保科技有限责任公司, 南京 211111;
2. 安徽工业大学环境科学与工程系, 安徽马鞍山 243002;
3. 安徽工业大学冶金工程系, 安徽马鞍山 243032

基金项目:

冶金减排与资源综合利用教育部重点实验室开放基金（JKF23-04）

详细信息

作者简介:
李小海（1985—），男，高级工程师，主要从事脱硝催化剂研发与应用研究。lixiaohai5613@163.com

通讯作者:
贾勇，教授，主要从事烟气脱硝方面的研究。jiayong2000@163.com

计量
- 文章访问数: 53
- HTML全文浏览量: 16
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-06-16
- 录用日期: 2024-07-30
- 修回日期: 2024-07-10
- 网络出版日期: 2026-01-09

Low temperature denitrification performance and reactant adsorption characteristics of MnPO/TiO₂ catalysts

1. Datang Nanjing Environment Protection Technology Co., Ltd., Nanjing 211111, China;
2. Department of Environmental Science and Engineering, Anhui University of Technology, Maanshan 243002, China;
3. Department of Metallurgical Engineering, Anhui University of Technology, Maanshan 243032, China

摘要

摘要: 以具有较强电子传输能力、优异的氧化还原性和环境友好性的MnO _x 为活性组分，利用磷酸调节Mn/TiO₂的酸性和氧化还原性能，制备了MnPO/TiO₂催化剂，并对其脱硝性能进行测试，同时采用DFT方法对反应物分子在催化剂表面的吸附特性进行了模拟。结果表明：当n（Mn）/n（P）=2，活性组分负载量为10%，煅烧温度为350 ℃时，催化剂的脱硝活性最好；反应温度为120 ℃时，脱硝率>80%；反应温度为150~210 ℃时，脱硝率>99%。抗硫抗水性测试和表征分析结果显示，Mn₂P₂O₇可有效提高MnPO/TiO₂催化剂的抗硫性能。DFT模拟结果表明：NH₃和NO在Mn₂P₂O₇（111）和Mn₃O₄（110）表面都发生稳定的化学吸附，并且NO以N端吸附在Mn₂P₂O₇（111）和Mn₃O₄（110）表面的吸附作用相对较强。SO₂在Mn₂P₂O₇（111）和Mn₃O₄（110）表面的吸附能均远大于NO的吸附能，SO₂与NO在催化剂表面竞争吸附处于劣势。同时，SO₂在Mn₂P₂O₇（111）表面的吸附能比在Mn₃O₄（110）表面的吸附能大，说明SO₂在Mn₂P₂O₇表面的吸附能力更弱，Mn₂P₂O₇能够提升MnPO/TiO₂催化剂的抗硫性能。H₂O分子在Mn₂P₂O₇（111）表面的吸附能为-129.56 kJ/mol，在Mn₃O₄（110）表面的吸附能分别为-135.2，-133.65 kJ/mol（Mn1、Mn2），均为化学吸附。
- MnPO /
- SCR脱硝 /
- 抗硫性 /
- DFT模拟 /
- 吸附特性
Abstract: In the paper， MnPO/TiO₂ catalysts was prepared by using MnO _x， which has strong electron transport capacity， excellent redox property and environmental friendliness， as the active component， and phosphoric acid was used to modulate the acidity and redox property of Mn/TiO₂catalysts， and their denitrification performance was tested， and the adsorption characteristics of reactant molecules on the surface of the catalysts were simulated by DFT method. The results showed that the highest denitrification activity occurred when the Mn/P was 2， the active component loading was 10%， and the calcination temperature was 350 ℃， and the denitrification efficiency was above 80% at 120 ℃， and above 99% at a temperature range of 150 to 210 ℃. The results of the anti-SO₂ test and characterization showed that the Mn₂P₂O₇ could effectively improve the sulfur resistance of the MnPO/TiO₂ catalysts. DFT simulation result showed that the adsorption characteristics of NH₃ and NO on the surfaces of Mn₂P₂O₇ （111） and Mn₃O₄ （110）， and the adsorption of NO on the surfaces of Mn₂P₂O₇（111） and Mn₃O₄（110） with N-terminal adsorption， were relatively stronger. The adsorption energies of SO₂ on the surfaces of Mn₂P₂O₇（111） and Mn₃O₄（110） were much larger than those of NO. SO₂ was at a disadvantage for competitive adsorption with NO on the catalyst surface. Meanwhile， the adsorption energy of SO₂ on the surface of Mn₂P₂O₇（111） was larger than that on the surface of Mn₃O₄（110）， which indicated Mn₂P₂O₇could improve the sulfur resistance of MnPO/TiO₂. The adsorption energy of the H₂O molecule on the surface of Mn₂P₂O₇（111） was -129.56 kJ/mol， and on the surface of Mn₃O₄（110） surface was -135.2 kJ/mol and -133.65 kJ/mol for Mn1 and Mn2， respectively， both of which are chemisorbed.
- MnPO /
- SCR denitrification /
- sulfur resistance /
- DFT simulation /
- adsorption characteristics

HTML全文

参考文献(39)

[1]	CHEN Y H，WANG P，MENG F Y，et al. The optimization of surface acidity VPO/TiO₂ catalyst and its low-temperature NH₃-SCR denitration performance［J］. China Environmental Science，2023，43（4）：1558-1566. 陈宜华，王攀，孟凡禹，等. VPO/TiO₂催化剂表面酸性位调控及低温NH₃-SCR脱硝性能研究［J］. 中国环境科学，2023，43（4）：1558-1566.
[2]	WANG Y X，LIU J，YI H H. Research progress of desulfurization and denitration technologies for sintering flue gas in iron and steel industry［J］. Environmental Engineering，2022，40（9）：253-261. 王雅新，刘俊，易红宏，等. 钢铁行业烧结烟气脱硫脱硝技术研究进展［J］. 环境工程，2022，40（9）：253-261.
[3]	ZHAO L，WANG C Y，ZHANG T. NH₃-SCR Properties of CeMn/ZSM-5 Catalyst modified by alkali-treatment［J］. Environmental Engineering，2024，42（8）：87-96. 赵磊，王传义，张婷，等. 碱处理改性CeMn/ZSM-5催化剂的NH₃-SCR性能［J］. 环境工程，2024，42（8）：87-96.
[4]	ZHANG M Y，GUAN Z Z，QIAO Y H，et al. The impact of catalyst structure and morphology on the catalytic performance in NH₃-SCR reaction：A review［J］. Fuel，2024，361：130541.
[5]	LI Y Y，ZHANG T R，NIU X Y，et al. Vanadium-based catalysts for selective catalytic reduction of NO_x with ammonia：Synthesis，poisoning mechanism，regeneration methods and research prospects［J］. Fuel，2024，365：131184.
[6]	HE Z H，WANG Y，LIU Y X，et al. Recent advances in sulfur poisoning of selective catalytic reduction（SCR）denitration catalysts［J］. Fuel，2024，365：131126.
[7]	CHEN J J，LONG J S，CHEN L. Status and development trend of integrated technology for muti-pollutant control in waste incineration flue gas［J］. Environmental Engineering，2024，42（9）：211-221 陈建军，龙吉生，陈琳，等. 垃圾焚烧烟气多污染物一体化净化技术现状和发展趋势［J］. 环境工程，2024，42（9）：211-221.
[8]	YANG S J，LIU C X，CHANG H Z，et al. Improvement of the activity of γ-Fe₂O₃ for the selective catalytic reduction of NO with NH₃ at high temperatures：NO reduction versus NH₃ oxidization［J］. Industrial& Engineering Chemistry Research，2013，52（16）：5601-5610.
[9]	LI Y，WAN Y，LI Y P，et al. Low-temperature selective catalytic reduction of NO with NH₃ over Mn₂O₃-doped Fe₂O₃ hexagonal microsheets［J］. ACS Applied Materials& Interfaces，2016，8（8）：5224-5233.
[10]	SUN J F，LU Y Y，ZHANG L，et al. Comparative study of different doped metal cations on the reduction，acidity，and activity of Fe₉ M₁O _x（M= Ti⁴⁺，Ce^4+/3+，Al³⁺）catalysts for NH₃-SCR reaction［J］. Industrial& Engineering Chemistry Research，2017，56（42）：12101-12110.
[11]	SUN C Z，CHEN W，JIA X X，et al. Comprehensive understanding of the superior performance of Sm-modified Fe₂O₃ catalysts with regard to NO conversion and H₂O/SO₂ resistance in the NH₃-SCR reaction［J］. Chinese Journal of Catalysis，2021，42（3）：417-430.
[12]	MU J C，LI X Y，SUN W B，et al. Inductive effect boosting catalytic performance of advanced Fe_1- _x V _x O _δ catalysts in low-temperature NH₃ selective catalytic reduction：Insight into the structure，interaction，and mechanisms［J］. ACS Catalysis，2018，8（8）：6760-6774.
[13]	BONINGARI T，SMIRNIOTIS P G. Impact of nitrogen oxides on the environment and human health：Mn-based materials for the NO _x abatement［J］. Current Opinion in Chemical Engineering，2016，13：133-141.
[14]	SHI Y R，YI H H，GAO F Y，et al. Evolution mechanism of transition metal in NH₃-SCR reaction over Mn-based bimetallic oxide catalysts：Structure-activity relationships［J］. Journal of Hazardous Materials，2021，413：125361.
[15]	ZENG Y Q，LU F Y，WANG Y N，et al. New insight on N₂O formation over MnO _x/TiO₂ catalysts for selective catalytic reduction of NO _x with NH₃［J］. Molecular Catalysis，2022，525：112356.
[16]	YIN Z J，ZHONG Y X，LU J W，et al. Getting insight into the oxidation of SO₂ to SO₃ over P modified VW/Ti catalyst：Effect and inhibition mechanism［J］. Chemical Engineering Journal，2023，459：141614.
[17]	TANG X L，WANG C Z，GAO F Y，et al. Acid modification enhances selective catalytic reduction activity and sulfur dioxide resistance of manganese-cerium-cobalt catalysts：Insight into the role of phosphotungstic acid［J］. Journal of Colloid and Interface Science，2021，603：291-306.
[18]	LU X N，SONG C Y，JIA S H，et al. Low-temperature selective catalytic reduction of NO _x with NH₃ over cerium and manganese oxides supported on TiO₂-graphene［J］. Chemical Engineering Journal，2015，260：776-784.
[19]	WANG H M，NING P，ZHANG Y Q，et al. Highly efficient WO₃-FeO _x catalysts synthesized using a novel solvent-free method for NH₃-SCR［J］. Journal of hazardous materials，2020，388：121812.
[20]	JIA Y，HUANG M Y，YUAN J，et al. Revealing the correlation between surface acid sites and activity of VPO/TiO₂ catalyst［J］. Catalysis Letters，2022：1-12.
[21]	ZHAO Z W，LI E W，QIN Y，et al. Density functional theory（DFT）studies of vanadium-titanium based selective catalytic reduction（SCR）catalysts［J］. Journal of Environmental Sciences，2020，90：119-137.
[22]	JIA Y，JIANG J，ZHENG R Z，et al. Insight into the reaction mechanism over PMoA for low temperature NH₃-SCR：A combined In-situ DRIFTs and DFT transition state calculations［J］. Journal of Hazardous Materials，2021，412：125258.
[23]	HUANG L B，HE L C，CHEN G Q，et al. The evolution of ammonium bisulfate on the surface of vanadium-titanium catalysts and its influence on catalytic activity［J］. Journal of Power Engineering，2025，45（4）：619-625. 黄林滨，何陆灿，陈国庆，等. 钒钛催化剂表面硫酸氢铵的演化及对催化活性的影响［J］. 动力工程学报，2025，45（4）：619-625.
[24]	BOONCHOM B，BAITAHE R. Synthesis and characterization of nanocrystalline manganese pyrophosphate Mn₂P₂O₇［J］. Materials Letters，2009，63（26）：2218-2220.
[25]	LU W H，CHEN J，KONG L S，et al. Oxygen vacancies modulation Mn₃O₄ nanozyme with enhanced oxidase-mimicking performance for l-cysteine detection［J］. Sensors and Actuators B：Chemical，2021，333：129560.
[26]	YANG B，QUAN H J，GAO J，et al. MnO nanoparticles with cationic defects encapsulated in nitrogen-doped porous carbon for high-performance aqueous zinc-ion batteries［J］. Journal of Alloys and Compounds，2021，889：161680.
[27]	LIU H，CUI X J，LU X C，et al. Mechanism of Mn incorporation into hydroxyapatite：Insights from SR-XRD，Raman，XAS，and DFT calculation［J］. Chemical Geology，2021，579：120354.
[28]	ZHANG Y，ZHAO L，KANG M D，et al. Insights into high CO-SCR performance of CuCoAlO catalysts derived from LDH/MOFs composites and study of H₂O/SO₂ and alkali metal resistance［J］. Chemical Engineering Journal，2021，426：131873.
[29]	LI J C，ZHANG C，LI Q，et al. Promoting mechanism of SO₂ resistance performance by anatase TiO₂｛0 0 1｝ facets on Mn-Ce/TiO₂ catalysts during NH₃-SCR reaction［J］. Chemical Engineering Science，2022，251：117438.
[30]	WANG F M，SHEN B X，ZHU S W，et al. Promotion of Fe and Co doped Mn-Ce/TiO₂ catalysts for low temperature NH₃-SCR with SO₂ tolerance［J］. Fuel，2019，249：54-60.
[31]	ILTON E S，POST J E，HEANEY P J，et al. XPS determination of Mn oxidation states in Mn（hydro）oxides［J］. Applied Surface Science，2016，366：475-485.
[32]	ZUO J，CHEN Z，WANG F，et al. Low-temperature selective catalytic reduction of NO_x with NH₃ over novel Mn-Zr mixed oxide catalysts［J］. Industrial& Engineering Chemistry Research，2014，53（7）：2647-2655.
[33]	ZHANG B L，ZHANG S G，LIU B. Comparative study on transition element doped Mn-Zr-Ti-oxides catalysts for the low-temperature selective catalytic reduction of NO with NH₃［J］. Reaction Kinetics，Mechanisms and Catalysis，2019，127（2）：637-652.
[34]	CHEN Z，ZHAO Y S，MA J Q，et al. Detailed XPS analysis and anomalous variation of chemical state for Mn-and V-doped TiO₂ coated on magnetic particles［J］. Ceramics International，2017，43（18）：16763-16772.
[35]	JI J W，JING M Z，WANG X W，et al. Activating low-temperature NH₃-SCR catalyst by breaking the strong interface between acid and redox sites：A case of model Ce₂（SO₄）₃-CeO₂ study［J］. Journal of Catalysis，2021，399：212-223.
[36]	LIU C，SHI J W，GAO C，et al. Manganese oxide-based catalysts for low-temperature selective catalytic reduction of NO_x with NH₃：A review［J］. Applied Catalysis A：General，2016，522：54-69.
[37]	LIU Y，GU T T，WENG X L，et al. DRIFT studies on the selectivity promotion mechanism of Ca-modified Ce-Mn/TiO₂ catalysts for low-temperature NO reduction with NH₃［J］. The Journal of Physical Chemistry C，2012，116（31）：16582-16592.
[38]	HORIKE S，DINCA M，TAMAKI K，et al. Size-selective Lewis acid catalysis in a microporous metal-organic framework with exposed Mn²⁺ coordination sites［J］. Journal of the American Chemical Society，2008，130（18）：5854-5855.
[39]	JIA Y，ZHENG R Z，YUAN J，et al. Promoting catalytic performance by balancing acid and redox sites on Mn₃O₄-Mn₂P₂O₇/TiO₂ for selective catalytic reduction of NO by NH₃ at low temperature［J］. Molecular Catalysis，2023，536：112913.
