机械活化钢渣负载氧化镁复合材料对废水氮、磷同步吸附性能研究

洪英傑; 赵聪; 彭道平

doi:10.13205/j.hjgc.202511022

机械活化钢渣负载氧化镁复合材料对废水氮、磷同步吸附性能研究

doi: 10.13205/j.hjgc.202511022

西南交通大学环境科学与工程学院, 成都 611756

基金项目:

四川省自然科学基金项目（2025ZNSFSC0440）

详细信息

作者简介:
洪英傑（2000—），男，主要研究方向为固体废物处置与资源化。hyj_chengdu@163.com

通讯作者:
彭道平（1984—），男，副教授，主要研究方向为固体废物资源化、工程水环境效应及其控制。pdp0330@swjtu.edu.cn

计量
- 文章访问数: 58
- HTML全文浏览量: 18
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-02-26
- 录用日期: 2025-04-23
- 修回日期: 2025-03-29
- 网络出版日期: 2026-01-09

Simultaneous adsorption performance of nitrogen and phosphorus from water by mechano-activated steel slag loaded with MgO

Southwest Jiaotong University, Chengdu 611756, China

摘要

摘要: 为从废水中回收营养物质、有效利用钢渣材料，制备了一种负载氧化镁的改性钢渣材料，研究了该材料吸附水中氨氮、磷酸盐的影响因素，对吸附前后的材料进行表征，并结合动力学模型和等温吸附曲线模型探究镁改性钢渣回收氮、磷营养物质的吸附机理。结果表明：当镁改性钢渣投加量为0.1 g/L、初始溶液pH为3.0、吸附时间为360 min、磷酸盐初始浓度为220 mg/L、氨氮初始浓度为100 mg/L时，磷酸盐和氨氮回收率分别为97.39%、79.60%；镁改性钢渣最大吸附容量达到氨氮74.973 mg/g，磷酸盐216.362 mg/g。此外，镁改性钢渣材料对氮、磷的吸附过程能被准二级动力学模型和Langmuir吸附等温线模型较好地描述，表明吸附过程为化学吸附和单分子层吸附，主要产物为鸟粪石沉淀。镁改性钢渣有望成一种具有应用前景的氮、磷回收材料。
- 机械活化钢渣 /
- 磷 /
- 氨氮 /
- 同步回收 /
- 鸟粪石
Abstract: To recover nutrients from wastewater and use steel slag material effectively， this study synthesized a modified steel slag material loaded with magnesium oxide， and probed the factors of adsorbing ammonia nitrogen and phosphate from water solution by this material. This study also analyzed the characterization of magnesium modified steel slag materials before and after adsorption by SEM-EDS， XRD， and RITR， in addition， explored the adsorption mechanism by kinetic model and adsorption isotherm model. The results showed that when the steel slag dosage was equal to 0.1 g/L， initial pH was equal to 3， adsorption time was 360 minutes， phosphate and ammonia nitrogen concentration were 220 mg/L and 100 mg/L， the magnesium-modified steel slag demonstrated a good performance in the simultaneous removal of ammonia nitrogen and phosphate， with maximum removal rates of 79.60% and 97.39% for ammonia nitrogen and phosphate. The maximum adsorption capacity of modified steel slag material was 74.973 mg/g and 216.362 mg/g for ammonia nitrogen and phosphate. Furthermore， it was found that the pseudo-2nd-order kinetic model and the Langmuir temperature adsorption curve model could describe the dynamic process of adsorption well. It indicated that the adsorption processes were chemisorption and molecular layer adsorption， and the final products were mainly struvite， suggesting that magnesium-modified steel slag is expected to become a promising material for nitrogen and phosphorus recovery
- mechano-activated steel slag /
- phosphorus /
- ammonia nitrogen /
- simultaneous recycling /
- struvite

HTML全文

参考文献(39)

[1]	SOLOMON O A. Eutrophication：causes，consequences，physical，chemical and biological techniques for mitigation strategies［J］. Environmental Challenges，2023（12）：100733.
[2]	SONARGHARE P C，MASRAM S C，SONPAROTE U R，et al. Causes and effects of eutrophication on aquatic life（a review）［J］. International Journal for Environmental Rehabilitation and Conservation，XI，2020：213-218.
[3]	GUAN Q，ZENG G，SONG J，et al. Ultrasonic power combined with seed materials for recovery of phosphorus from swine wastewater via struvite crystallization process［J］. Journal of Environmental Management，2021，293：112961.
[4]	CARRILLO V，FUENTES B，GÓMEZ G，et al. Characterization and recovery of phosphorus from wastewater by combined technologies［J］. Reviews in Environmental Science and Bio/Technology，2020，19：389-418.
[5]	GUAN Q，LI Y，ZHONG Y，et al. A review of struvite crystallization for nutrient source recovery from wastewater［J］. Journal of Environmental Management，2023，344：118383.
[6]	AGUADO D，BARAT R，BOUZAS A，et al. P-recovery in a pilot-scale struvite crystallisation reactor for source separated urine systems using seawater and magnesium chloride as magnesium sources［J］. Science of the Total Environment，2019，672：88-96.
[7]	DAVIS R W，SICCARDI III A J，HUYSMAN N D，et al. Growth of mono-and mixed cultures of Nannochloropsis salina and Phaeodactylum tricornutum on struvite as a nutrient source［J］. Bioresource Technology，2015，198：577-585.
[8]	ZHANG T，HE X，DENG Y，et al. Phosphorus recovered from digestate by hydrothermal processes with struvite crystallization and its potential as a fertilizer［J］. Science of the Total Environment，2020，698：134240.
[9]	WANG J，YE X，ZHANG Z，et al. Selection of cost-effective magnesium sources for fluidized struvite crystallization［J］. Journal of Environmental Sciences，2018，70：144-153.
[10]	RABINOVICH A，HECKMAN J R，LEW B，et al. Magnesium supplementation for improved struvite recovery from dairy lagoon wastewater［J］. Journal of Environmental Chemical Engineering，2021，9（4）：105628.
[11]	LEE S H，YOO B H，LIM S J，et al. Development and validation of an equilibrium model for struvite formation with calcium co-precipitation［J］. Journal of Crystal Growth，2013，372：129-137.
[12]	SHADDEL S，GRINI T，UCAR S，et al. Struvite crystallization by using raw seawater：Improving economics and environmental footprint while maintaining phosphorus recovery and product quality［J］. Water Research，2020，173：115572.
[13]	ZANGARINI S，PEPÈ Sciarria T，TAMBONE F，et al. Phosphorus removal from livestock effluents：recent technologies and new perspectives on low-cost strategies［J］. Environmental Science and Pollution Research，2020，27（6）：5730-5743.
[14]	ASGARI G，SALARI M. Optimized synthesis of carbon-doped nano-MgO and its performance study in catalyzed ozonation of humic acid in aqueous solutions：Modeling based on response surface methodology［J］. Journal of Environmental Management，2019，239：198-210.
[15]	PARK N，CHANG H，JANG Y，et al. Prediction of adequate pH and Mg²⁺ dosage using an empirical MgO solubility model for struvite crystallization［J］. Environmental Technology& Innovation，2021，21：101347.
[16]	XIA Y，DONG K，XIANG X，et al. Phosphorus hyperaccumulation in nano-MgO using a circular recovery process based on multiple phase transitions from periclase to brucite［J］. Science of The Total Environment，2020，727：138510.
[17]	LI S，ZENG W，XU H，et al. Performance investigation of struvite high-efficiency precipitation from wastewater using silicon-doped magnesium oxide［J］. Environmental Science and Pollution Research，2020，27：15463-15474.
[18]	FANG H，ZHOU T，CHEN X，et al. Controlled preparation and characterization of nano-sized hexagonal Mg（OH）₂ flame retardant［J］. Particuology，2014，14：51-56.
[19]	PEI Y，WANG M，TIAN D，et al. Synthesis of core-shell SiO₂@ MgO with flower like morphology for removal of crystal violet in water［J］. Journal of Colloid and Interface Science，2015，453：194-201.
[20]	HÖVELMANN J，PUTNIS C V. In situ nanoscale imaging of struvite formation during the dissolution of natural brucite：Implications for phosphorus recovery from wastewaters［J］. Environmental Science& Technology，2016，50：13032-13041.
[21]	SHI C，WANG X，ZHOU S，et al. Mechanism，application，influencing factors and environmental benefit assessment of steel slag in removing pollutants from water：a review［J］. Journal of Water Process Engineering，2022，47：102666.
[22]	GUO J，BAO Y，WANG M. Steel slag in China：treatment，recycling，and management［J］. Waste Management，2018，78：318-330.
[23]	YU C，ZHANG W，GAO F，et al. An overview of resource utilization of steel slag as absorbent material for waste water treatment［C］// E3S web of conferences. EDP Sciences，2020，199：00017.
[24]	BING L，BIAO T，ZHEN M，et al. Physical and chemical properties of steel slag and utilization technology of steel slag at home and abroad［C］// IOP Conference Series：Earth and Environmental Science，IOP Publishing，2019，242（3）：032012.
[25]	YANG M，LU C，QUAN X，et al. Mechanism of acid mine drainage remediation with steel slag：a review［J］. ACS omega，2021，6（45）：30205-30213.
[26]	CHANDRU P，KARTHIKEYAN J，SAHU A K，et al. Some durability characteristics of ternary blended SCC containing crushed stone and induction furnace slag as coarse aggregate［J］. Construction and Building Materials，2021，270：121483.
[27]	BARCA C，GÉRENTE C，MEYER D，et al. Phosphate removal from synthetic and real wastewater using steel slags produced in Europe［J］. Water research，2012，46（7）：2376-2384.
[28]	WU F，YU Q，GAUVIN F，et al. A facile manufacture of highly adsorptive aggregates using steel slag and porous expanded silica for phosphorus removal［J］. Resources，Conservation and Recycling，2021，166：105238.
[29]	WANG W，SARDANS J，WANG C，et al. Steel slag amendment increases nutrient availability and rice yield in a subtropical paddy field in China［J］. Experimental agriculture，2018，54（6）：842-856.
[30]	DAS S，GWON H S，KHAN M I，et al. Steel slag amendment impacts on soil microbial communities and activities of rice（Oryza sativa L.）［J］. Scientific Reports，2020，10（1）：6746.
[31]	LEE S，WEON S，LEE C，et al. Removal of nitrogen and phosphate from wastewater by addition of bittern［J］. Chemosphere，2003，51（4）：265-271.
[32]	HUANG H，XIAO D，LIU J，et al. Recovery and removal of nutrients from swine wastewater by using a novel integrated reactor for struvite decomposition and recycling［J］. Scientific Reports，2015，5（1）：10183.
[33]	LI B，HUANG H，BOIARKINA I，et al. Phosphorus recovery through struvite crystallisation：recent developments in the understanding of operational factors［J］. Journal of Environmental Management，2019，248：109254.
[34]	PARK N，CHANG H，JANG Y，et al. Prediction of adequate pH and Mg²⁺ dosage using an empirical MgO solubility model for struvite crystallization［J］. Environmental Technology& Innovation，2021，21：101347.
[35]	LIANG J，LV Y，LU Y，et al. Recovery of ammonium and phosphate from corn processing wastewater using magnetic MgO-Biochar［J］. Environmental Engineering，2020，38（9）：89-94. 梁嘉琪，吕媛，陆茵，等. 铁磁性氧化镁生物炭对玉米加工废水中氮磷的回收效果［J］. 环境工程，2020，38（9）：89-94.
[36]	ZHU T，LU Z，LIU Y，et al. Effects of preparation conditions of Mg-modified biochar on the removal of ammonium and phosphate in wastewater［J］. Environmental Engineering，2018，36（1）：37-41. 祝天宇，卢泽玲，刘月娥，等. 镁改性生物炭制备条件对其氮、磷去除性能的影响［J］. 环境工程，2018，36（1）：37-41.
[37]	ZHAO C，LI Y，PANG Y，et al. Red mud as a magnesium carrier for enhanced N and P recovery from wastewater by the struvite method［J］. Environmental Technology& Innovation，2023，30：103030.
[38]	XIA P，WANG X，WANG X，et al. Struvite crystallization combined adsorption of phosphate and ammonium from aqueous solutions by mesoporous MgO loaded diatomite［J］. Colloids and Surfaces A：Physicochemical and Engineering Aspects，2016，506：220-227.
[39]	ZHU Y，SHAN S，HU T，et al. Hierarchical pore carbon-calcium nanocages for highly effective removal of ammonium-nitrogen and phosphorus［J］. Fuel Processing Technology，2023，247：107804.
