静电除尘器内电场、流场和颗粒行为的双向耦合模拟

田茂; 雷洪; 亓捷; 张立莹

doi:10.13205/j.hjgc.202601016

静电除尘器内电场、流场和颗粒行为的双向耦合模拟

doi: 10.13205/j.hjgc.202601016

田茂^1,2,
雷洪^1,2, ,,
亓捷²,
张立莹^1,2

1. 东北大学材料电磁过程研究教育部重点实验室, 沈阳 110819;
2. 东北大学冶金学院, 沈阳 110819

基金项目:

国家自然科学基金项目（U1460108）

详细信息

作者简介:
田茂（1998—），男，硕士，主要研究方向为静电除尘器、电磁流体力学。Tm01218@163.com

通讯作者:
雷洪（1973—），男，教授，博士生导师，主要研究方向为多相流、先进电磁冶金、智能冶金。leihong@epm.neu.edu.cn

计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-12-18
- 网络出版日期: 2026-02-26
- 刊出日期: 2026-01-22

Two-way coupling simulation for electric field， flow field and particle behaviors in an electrostatic precipitator

TIAN Mao^1,2,
LEI Hong^{1,2
, ,},
QI Jie²,
ZHANG Liying^1,2

1. Key Laboratory of Electromagnetic Processing of Materials, Ministry of Education, Northeastern University, Shenyang 110819, China;
2. School of Metallurgy, Northeastern University, Shenyang 110819, China

摘要

摘要: 为了深入研究线板式静电除尘器的电学特性和颗粒输运行为，采用开源软件OpenFOAM求解了Maxwell 方程组、连续性方程、动量方程、颗粒荷电和运动方程，研究了不同颗粒浓度下带电粒子对静电除尘器内的电场、流场和颗粒行为的影响。结果表明：颗粒空间电荷效应打破了电场强度、离子电荷密度和电场力对称分布的规律，颗粒浓度越高，非对称性越强。当颗粒浓度从0 mg/m³增加到500 mg/m³，电晕线附近的电场强度从1.4×10⁶V/m降至1.31×10⁶ V/m，第1根电晕线正对的收尘极附近的电场强度从7.5×10⁵ V/m增加到8.7×10⁵ V/m；离子电荷密度也呈下降趋势。颗粒浓度的增大导致电晕线附近电场力减小，极板附近的电场力增大，电场力对空气沿主流方向的速度有促进作用。颗粒浓度的增大也导致静电除尘器内颗粒轨迹出现向中心轴线偏移的现象；小尺寸颗粒的运动受湍流夹带作用的影响效果显著，粒径<5 µm的颗粒在湍流作用下轨迹会出现明显的分叉现象。
- 静电除尘器 /
- 双向耦合 /
- 电场 /
- 电子风 /
- 颗粒
Abstract: To study the electrical characteristics and particle transport behaviors of a wire-plate electrostatic precipitator， the open-source software OpenFOAM was applied to solve the Maxwell equations， continuity equations， momentum equations， particle charge-motion equations， and to investigate the effects of charged particles in the cases of different particle concentrations on the electric field， flow field， and particle behaviors in the electrostatic precipitator. The numerical results showed that the spatial charge effect of particles broke the law of symmetrical distribution of electric field strength， ionic charge density， and electric field force， and the greater the particle concentration， the stronger the asymmetry of the electric field. When the particle concentration increased from 0 mg/m³ to 500 mg/m³， the electric field intensity near the corona wire decreased from 1.4×10⁶ V/m to 1.31×10⁶ V/m， and the electric field intensity near the grounded plate toward the first corona wire increased from 7.5×10⁵V/m to 8.7×10⁵ V/m. The ionic charge density decreased with the increase in particle concentration. The increase in particle concentration led to a decrease in the electric field force near the corona wire and an increase in the electric field force near the plate， which had a promoting effect on the velocity of the air along the main flow direction. The increase in particle concentration also led to the phenomenon that the particle trajectories in the electrostatic precipitator shifted to the central axis. The movement of small particles was significantly affected by turbulent flow， and the trajectories of particles less than 5 µm bifurcated obviously in the case of turbulent flow.
- electrostatic precipitator /
- two-way coupling /
- electric field /
- electric wind /
- particle

HTML全文

参考文献(28)

[1]	MILLER L，XU X H. Ambient PM_2.5 human health effects—findings in China and research directions[J]. Atmosphere，2018，9（11）：424.
[2]	HE Z H，YI M T，ZHONG Q M，et al. Influencing factors of synergy degree for industrial pollutant and carbon reductions in Chinese cities[J]. Environmental Science& Technology，2024，42（1）：206-214. 何子豪，易梦婷，钟秋萌，等. 中国城市工业减污降碳协同度的影响因素分析[J]. 环境工程，2024，42（1）：206-214.
[3]	LI Y R，XING Y，SUN Y J，et al. Low-carbon green development path and practice of the iron and steel industry[J]. Chinese Journal of Engineering，2023，45（9）：1583-1591. 李毅仁，邢奕，孙宇佳，等. 钢铁工业低碳绿色发展路径与实践[J]. 工程科学学报，2023，45（9）：1583-1591.
[4]	SU X W，ZHANG L，XIAO Y X，et al. Evaluation of a flue gas cleaning system of a circulating fluidized bed incineration power plant by the analysis of pollutant emissions[J]. Powder Technology，2015，286：9-15.
[5]	HAN J Z，ZHANG J，YAN Z W，et al. Emission characteristics and control suggestions of colored smoke plumes from coal-fired power plants and iron and steel plants’ sintering processes[J]. Environmental Engineering，2024，42（2）：144-151. 韩军赞，张洁，闫威卓，等. 燃煤电厂和钢铁厂烧结烟气有色烟羽排放特征与管控建议[J]. 环境工程，2024，42（2）：144-151.
[6]	PARK J.H.，HA M Y，LEE D A. Numerical study on particle collection for wavy dielectric plate in two-stage wire-plate electrostatic precipitator[J]. Journal of Mechanical Science and Technology，2023，37（10）：5147-5157.
[7]	YAO Y P，LIU H X，XI L Q，et al. Research on ultra-low emission technology for ESP[J]. Environmental Science& Technology，2018，36（7）：81-86. 姚宇平，刘含笑，奚力强，等. 基于电除尘器的烟尘超低排放技术研究[J]. 环境工程，2018，36（7）：81-86.
[8]	ADAMIAK K. Numerical models in simulating wire-plate electrostatic precipitators：a review[J]. Journal of Electrostatics，2013，71（4）：373-680.
[9]	ZHANG L Y，LEI H，NIU H，et al. Numerical simulation for electric field，flow field and particle concentration distribution in wire-plate electrostatic precipitator[J]. High Voltage Engineering，2021，47（11）：4144-4151. 张立莹，雷洪，牛宏，等. 线板型静电除尘器的电场、流场与颗粒浓度分布的数值模拟[J]. 高电压技术，2021，47（11）：4144-4151.
[10]	LIU M K，DANG X Q，XIE D M，et al. Influence of electrode configuration and parameters on electric field and dust removal performance of porous electrode ESP[J]. Environmental Science& Technology，2024，42（3）：122-130. 刘明坤，党小庆，谢东明，等. 电极配置及参数对多孔电极电除尘器电场与除尘性能影响研究[J]. 环境工程，2024，42（3）：122-130.
[11]	GOO J H，LEE J W. Stochastic simulation of particle charging and collection characteristics for a wire-plate electrostatic precipitator of short length[J]. Journal of Aerosol Science，1997，28（5）：875-893.
[12]	FENG Y X，LUO K，FAN J R. Particle transport and charging mechanism of the nano particle within an electrostatic precipitator[J]. Journal of University of Chinese Academy of Sciences，2021，38（3）：297-305. 冯宇轩，罗坤，樊建人. 静电除尘器中纳米颗粒运动与荷电特性[J]. 中国科学院大学学报，2021，38（3）：297-305.
[13]	LEI H，WANG L Z，WU Z N. EHD turbulent flow and Monte-Carlo simulation for particle charging and tracing in a wire-plate electrostatic precipitator[J]. Journal of Electrostatics，2008，66（3/4）：130-141.
[14]	WANG J H，HUANG C，YANG Z M，et al. Influence of plate shape on flow field and efficiency of electrostatic precipitator[J]. Energy Environmental Protection，2020，34（6）：40-46. 王佳豪，黄超，杨振民，等. 板型对电除尘器内部流场和除尘效率的影响[J]. 能源环境保护，2020，34（6）：40-46.
[15]	FARNOOSH N，ADAMIAK K，CASTLE G S P. Three-dimensional analysis of electrohydrodynamic flow in a spiked electrode-plate electrostatic precipitator[J]. Journal of Electrostatics，2011，69（5）：419-428.
[16]	YAN D J，ZHANG X H，YUAN L Y，et al. Effect of wire electrode structure parameters on dust removal performance of perforated plate electrostatic precipitators[J]. Environmental Science& Technology，2023，41（5）：61-68. 闫东杰，张晓海，袁良宇，等. 极线结构参数对孔板式电除尘器除尘性能的影响[J]. 环境工程，2023，41（5）：61-68.
[17]	SONG Y D，ZHANG Y N，ZHU W P，et al. Study on the influence of electrodes on the collection efficiency during the treatment of welding fume in electrostatic precipitators[J]. Journal of Electrostatics，2023，123：103808.
[18]	LI J R，DUAN L P，CHEN J H，et al. Research on the effect of different corrugated dust collection plates on particle removal in electrostatic precipitators[J]. Chemical Engineering Research and Design，2023，197：323-333.
[19]	LUO K，LI Y，ZHENG C H，et al. Numerical simulation of temperature effect on particles behavior via electrostatic precipitators[J]. Applied Thermal Engineering，2015，88：127-139.
[20]	LU Q Y，YANG Z D，ZHENG C H，et al. Numerical simulation on the fine particle charging and transport behaviors in a wire-plate electrostatic precipitator[J]. Advanced Powder Technology，2016，27（5）：1905-1911.
[21]	SONG Y D，ZHANG Y N，LIU Y L，et al. Numerical simulation of the collection efficiency of welding fume particles in electrostatic precipitator[J]. Powder Technology，2023，415，118173.
[22]	PODLINSKI J，NIEWULIS A，MIZERACZYK P，et al. ESP performance for various dust densities[J]. Journal of Electrostatics，2008，66（5/6）：246-253.
[23]	YANG Z D，ZHENG C H，ZHANG X F，et al. Challenge of SO₃removal by wet electrostatic precipitator under simulated flue gas with high SO₃ concentration[J]. Fuel，2018，217：597-604.
[24]	ZHENG C H，ZHANG X F，YANG Z D，et al. Numerical simulation of corona discharge and particle transport behavior with the particle space charge effect[J]. Journal of Aerosol Science，2018，118：22-33.
[25]	DING Y，GUO B Y，YE X L，et al. Numerical simulation of electrostatic precipitator considering the dust particle space charge[J]. Powder Technology，2019，354：552-560.
[26]	LAWLESS P A. Particle charging bounds，symmetry relations，and an analytic charging rate model for the continuum regime[J]. Journal of Aerosol Science，1996，27（2）：191-215.
[27]	PENNEY G W，MATICK R E. Potentials in D-C corona fields[J]. Transactions of the American Institute of Electrical Engineers，Part I：Communication and Electronics，1960，79（2）：91-99.
[28]	KALLIO G A，STOCK. Interaction of electrostatic and fluid dynamic fields in wire-plate precipitators[J]. Journal of Fluid Mechanics，1992，240：133-166.
