V2O5/TiO2和Cs/Co3O4催化剂联合催化脱除NO x 和N2O

苗静文; 樊星; 刘若雯; 张雅坤

doi:10.13205/j.hjgc.202602012

V₂O₅/TiO₂和Cs/Co₃O₄催化剂联合催化脱除NO _x 和N₂O

doi: 10.13205/j.hjgc.202602012

苗静文¹,
樊星^1,2, ,,
刘若雯¹,
张雅坤¹

1. 北京工业大学环境科学与工程学院, 北京 100124;
2. 北京工业大学区域大气复合污染防治北京市重点实验室, 北京 100124

基金项目:

国家自然科学基金项目（21707004）；北京市自然科学基金项目（8152011）

详细信息

作者简介:
苗静文（1998—），女，硕士研究生，主要研究方向为催化脱除NO_x和N₂O。miaojingwen1998@163.com

通讯作者:
樊星（1985—），女，博士，副教授，主要研究方向为大气污染控制理论与技术。fanxing@bjut.edu.cn

计量
- 文章访问数: 7
- HTML全文浏览量: 2
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-01-11
- 网络出版日期: 2026-04-11
- 刊出日期: 2026-02-01

Catalytic removal of NO _x and N₂O over combined V₂O₅/TiO₂ and Cs/Co₃O₄ catalysts

1. College of Environmental Science and Engineering, Beijing University of Technology, Beijing 100124, China;
2. Key Laboratory of Beijing on Regional Air Pollution Control, Beijing University of Technology, Beijing 100124, China

摘要

摘要: 针对高效脱除硝酸生产尾气中NO _x 和N₂O的需求，提出了先催化NO _x 还原后催化N₂O分解的技术路线。分别考察了V₂O₅/TiO₂和Co₃O₄基催化剂催化NO _x 还原和N₂O分解的性能，在优选出2.0Cs/Co₃O₄催化剂的基础上，重点考察了在V₂O₅/TiO₂催化剂之后串接2.0Cs/Co₃O₄催化剂的联合催化脱除NO _x 和N₂O的性能，并采用N₂吸脱附、XRD、XPS和O₂-TPD等手段对催化剂理化特性进行表征。结果表明：V₂O₅/TiO₂催化还原NO _x 时，进气中含2% H₂O有利于拓宽活性温度窗口和提高N₂选择性，以及抑制N₂O形成。在Co₃O₄表面负载2.0% Cs显著提高了催化剂催化N₂O分解性能，这可能与Cs的引入导致部分Co³⁺还原为Co²⁺以及催化剂表面形成了更多氧空位有关。高温（400 ℃）下通入2% H₂O对2.0Cs/Co₃O₄催化N₂O分解的抑制作用较弱，但同时通入2% H₂O和50×10^-6 NO显著抑制了2.0Cs/Co₃O₄催化剂的活性。采用先V₂O₅/TiO₂后2.0Cs/Co₃O₄的两段式催化剂联合脱除NO _x 和N₂O时，前端的V₂O₅/TiO₂催化剂主要催化NO _x 的还原反应，N₂O对脱硝过程的影响有限；在V₂O₅/TiO₂催化剂高效脱除NO _x （和NH₃）的温度范围内，后端的2.0Cs/Co₃O₄催化剂可较为稳定地催化N₂O分解；在温度400 ℃，进气中含2% H₂O时，NO _x 和NH₃转化率均接近100%，N₂O转化率为61.3%。
- NO _x 还原 /
- N₂O分解 /
- V₂O₅/TiO₂ /
- Cs/Co₃O₄ /
- 联合催化
Abstract: Aiming at efficiently removing NO _x and N₂O from the tail gas of nitric acid production， a technique route of catalytic reduction of NO _x followed by catalytic decomposition of N₂O was proposed. NO _x reduction over V₂O₅/TiO₂ catalyst and N₂O decomposition over Co₃O₄-based catalysts were separately investigated. The combined removal of NO _x and N₂O was then investigated by connecting the V₂O₅/TiO₂ catalyst with the optimized 2.0Cs/Co₃O₄ catalyst in series. Physicochemical characteristics of the catalysts were characterized by N₂ adsorption-desorption， XRD， XPS， and O₂-TPD techniques. The results showed that， for NO _x reduction over the V₂O₅/TiO₂ catalyst， the presence of 2% H₂O in the feed gas could broaden the active temperature window of the catalyst， improve the N₂ selectivity， and inhibit the formation of N₂O. By loading 2.0% Cs on Co₃O₄， the N₂O decomposition was greatly improved， which might be explained by the reduction of some Co³⁺ to Co²⁺ and the formation of more oxygen vacancies on the catalyst surface， due to the introduction of Cs. At high temperatures （400 ℃）. the presence of 2.0% H₂O in the feed gas showed weak inhibitory effects on the decomposition of N₂O over the 2.0Cs/Co₃O₄ catalyst， while the coexistence of 2% H₂O and 50×10^-6 NO significantly deactivated the 2.0Cs/Co₃O₄ catalyst. When the two-stage catalyst， consisting of upstream V₂O₅/TiO₂ and downstream 2.0Cs/Co₃O₄ catalyst， was used to remove NO _x and N₂O， NO _x was mainly reduced over the V₂O₅/TiO₂ catalyst， with limited influence from the presence of N₂O. In the temperature range for efficient removal of NO _x （and NH₃） over the V₂O₅/TiO₂ catalyst， N₂O could be stably decomposed over the downstream 2.0Cs/Co₃O₄ catalyst. With 2% H₂O contained in the feed gas， complete conversion of NO _x and NH₃ was achieved at 400 ℃， whereas the conversion of N₂O reached 61.3%.
- NO _x reduction /
- N₂O decomposition /
- V₂O₅/TiO₂ /
- Cs/Co₃O₄ /
- combined catalysis

HTML全文

参考文献(35)

[1]	ALVES L，HOLZ L I V，FERNANDES C，et al. A comprehensive review of NO _x and N₂O mitigation from industrial streams［J］. Renewable and Sustainable Energy Reviews，2022，155:111916.
[2]	ZHANG Y Q，SUN P K，TONG H，et al. Wide window denitrification of V₂O₅/microporous TiO₂ under synergistic effect of dielectric barrier discharge plasma［J］. Environmental Engineering，2024，42（6）:82-93. 张宇晴，孙朋琨，童华，等. 介质阻挡放电协同V₂O₅/微孔TiO₂催化剂宽窗口脱硝［J］. 环境工程，2024，42（6）:82-93.
[3]	LI J，FAN X，CHEN L，et al. Research progress of simultaneous removal of NO_x and N₂O from the tail gas of nitric acid production［J］. Chemical Industry and Engineering Progress，2023，42（7）:3770-3779. 李佳，樊星，陈莉，等. 硝酸生产尾气中 NO_x和 N₂O 联合脱除技术研究进展［J］. 化工进展，2023，42（7）:3770-3779.
[4]	KANG B，GUO M，WU H，et al. Effect of alkali/alkaline-earth-metal doping on the Co₃O₄ spinel structure and N₂O decomposition［J］. Catalysis Science& Technology，2024，14（10）:2825-2837.
[5]	SI Q Y，FAN X，ZHANG W H，et al. Simultaneous reduction of NO_x and decomposition of N₂O over Fe-Beta and Cu-SSZ-13 composite catalyst［J］. China Environmental Science，2024，44（9）:4826-4834. 司庆宇，樊星，张玮航，等. Fe-Beta和Cu-SSZ-13复合催化剂同时催化NO_x还原和N₂O分解［J］. 中国环境科学，2024，44（9）:4826-4834.
[6]	CHEN C，CAO Y，LIU S，et al. Review on the latest developments in modified vanadium-titanium-based SCR catalysts［J］. Chinese Journal of Catalysis，2018，39（8）:1347-1365.
[7]	LIU T A，GUO L，WANG S J，et al. Research progress on medium and low temperature denitrification catalysts in thermal power plants［J］. Environmental Engineering，2023，41（S2）:422-425. 刘艇安，郭磊，王世杰，等. 火电厂环保岛中低温脱硝催化剂研究进展［J］. 环境工程，2023，41（增刊2）:422-425.
[8]	KONSOLAKIS M. Recent advances on nitrous oxide（N₂O）decomposition over non-noble-metal oxide catalysts:catalytic performance，mechanistic considerations，and surface chemistry aspects［J］. ACS Catalysis，2015，5（11）:6397-6421.
[9]	YANG B，SHEN Y S，ZHU S M. New progress in research on catalysts for N₂O decomposition［J］. Environmental Engineering（China），2012，30（2）:114-119. 杨波，沈岳松，祝社民. 催化分解 N₂O 催化剂的研究新进展［J］. 环境工程，2012，30（2）:114-119.
[10]	WANG Q，YANG W，DANG H，et al. Enhancement of N₂O decomposition performance by co-doping of Ni and Y to Co₃O₄ catalyst［J］. Journal of Environmental Chemical Engineering，2024，12（2）:112463.
[11]	SUN J，LIU J，HUANG D，et al. Unravelling the effect of alkali metal deposition on Co₃O for catalytic decomposition of N₂O［J］. SSRN Electronic Journal，2024.
[12]	YU T，ZOU Z，JIANG T，et al. A novel activated vanadium extraction tailing catalyst for NO_x removal in NH₃-SCR［J］. Journal of Sustainable Metallurgy，2024，10（3）:497-508.
[13]	KLEGOVA A，PACULTOVÁ K，KIŠKA T，et al. On the optimal Cs/Co ratio responsible for the N₂O decomposition activity of the foam supported cobalt oxide catalysts［J］. Arabian Journal of Chemistry，2023，16（12）:105311.
[14]	INGER M，RAJEWSKI J，RUSZAK M，et al. The influence of NO_x presence on the catalytic N₂O decomposition over the supported double-promoted cobalt spinel catalyst［J］. Chemical Papers，2019，73（8）:1979-1986.
[15]	ZHANG L，WANG H，SHEN W，et al. Controlled synthesis of graphitic carbon nitride and its catalytic properties in knoevenagel condensations［J］. Journal of Catalysis，2016，344:293-302.
[16]	BAI B，LI J. Positive effects of K⁺ ions on three-dimensional mesoporous Ag/Co₃O₄ catalyst for HCHO oxidation［J］. ACS Catalysis，2014，4（8）:2753-2762.
[17]	ALEMANY L J，LIETTI L，FERLAZZO N，et al. Reactivity and physicochemical characterization of V₂O₅-WO₃/TiO₂ de-NO_x catalysts［J］. Journal of Catalysis，1995，155（1）:117-130.
[18]	LIANG Q，LI J，HE H，et al. Effects of SO₂ and H₂O on low-temperature NO conversion over F-V₂O₅-WO₃/TiO₂ catalysts［J］. Journal of Environmental Sciences，2020，90:253-261.
[19]	YU H，TURSUN M，WANG X，et al. Pb_0.04Co catalyst for N₂O decomposition in presence of impurity gases［J］. Applied Catalysis B:Environmental，2016，185:110-118.
[20]	WANG Y，CHANG H，SHI C，et al. Novel Fe-Ce-O mixed metal oxides catalyst prepared by hydrothermal method for Hg⁰ oxidation in the presence of NH₃［J］. Catalysis Communications，2027，100:210-213.
[21]	MA X，YU X，GE M. Highly efficient catalytic oxidation of benzene over Ag-assisted Co₃O₄ catalysts［J］. Catalysis Today，2021，376:262-268.
[22]	ZHANG J，ZHAO C，ZOU M，et al. An effective strategy to improve the photothermocatalytic activity of Co₃O₄ for VOCs degradation:specifically enhancing the surface lattice oxygen activity［J］. Separation and Purification Technology，2023，327:124905.
[23]	GONG Y，LIU Z，LI Z，et al. Boosting N₂O decomposition by fabricating the Cs-O-Co structure over Co₃O₄ with single-layer atoms of Cs［J］. Environmental Science& Technology，2024，58（1）:906-914.
[24]	LIU K，HUANG X，WANG H，et al. Co₃O₄-CeO₂/C as a highly active electrocatalyst for oxygen reduction reaction in Al-air batteries［J］. ACS Applied Materials& Interfaces，2016，8（50）:34422-34430.
[25]	WU Z，NIU H，CHEN J，et al. Metal-organic frameworks-derived hierarchical Co₃O₄/CoNi-layered double oxides nanocages with the enhanced catalytic activity for toluene oxidation［J］. Chemosphere，2021，280:130801.
[26]	QU F，ZHANG N，ZHANG S，et al. Construction of Co₃O₄/CoWO₄ core-shell urchin-like microspheres through ion-exchange method for high-performance acetone gas sensing performance［J］. Sensors and Actuators B:Chemical，2020，309:127711.
[27]	LIU W J，WANG H，LEE J，et al. Investigating crystal plane effect of Co₃O₄ with various morphologies on catalytic activation of monopersulfate for degradation of phenol in water［J］. Separation and Purification Technology，2021，276:119368.
[28]	LIU H，FAN Z，SUN C，et al. Improved activity and significant SO₂ tolerance of samarium modified CeO₂-TiO₂ catalyst for NO selective catalytic reduction with NH₃［J］. Applied Catalysis B:Environmental，2019，244:671-683.
[29]	ZHAO F，WANG D，LI X，et al. Enhancement of Cs on Co₃O₄ for N₂O catalytic decomposition:N₂O activation and O₂ desorption［J］. Industrial& Engineering Chemistry Research，2022，61（37）:13854-13862.
[30]	LAI J K，WACHS I E. A perspective on the selective catalytic reduction（SCR）of NO with NH₃ by supported V₂O₅-WO₃/TiO₂ catalysts［J］. ACS Catalysis，2018，8（7）:6537-6551.
[31]	LEI Z，HAN B，YANG K，et al. Influence of H₂O on the low-temperature NH₃-SCR of NO over V₂O₅/AC catalyst:an experimental and modeling study［J］. Chemical Engineering Journal，2013，215-216:651-657.
[32]	ZHAO H，WANG P，LI Z，et al. Improved activity and significant O₂ resistance of Cs doped Co₃O₄ catalyst for N₂O decomposition［J］. Journal of Environmental Chemical Engineering，2024，12（5）:113907.
[33]	KAPTEIJN F，RODRIGUEZ-MIRASOL J，MOULIJN J A. Heterogeneous catalytic decomposition of nitrous oxide［J］. Applied Catalysis B:Environmental，1996，9（1）:25-64.
[34]	KOMVOKIS V G，MARNELLOS G E，VASALOS I A，et al. Effect of pretreatment and regeneration conditions of Ru/γ-Al₂O₃ catalysts for N₂O decomposition and/or reduction in O₂-rich atmospheres and in the presence of NO _x，SO₂ and H₂O［J］. Applied Catalysis B:Environmental，2009，89（3-4）:627-634.
[35]	LIU X，WANG Y，WU R，et al. Investigation of different apatites-supported Co₃O₄ as catalysts for N₂O decomposition［J］. Catalysis Surveys from Asia，2021，25（3）:168-179.
