碱热处理SnO2/g-C3N4催化还原CO2的影响机制研究

苏明雪; 顾春晗; 张涵; 李宁

doi:10.13205/j.hjgc.202602017

碱热处理SnO₂/g-C₃N₄催化还原CO₂的影响机制研究

doi: 10.13205/j.hjgc.202602017

苏明雪^1,2,
顾春晗^1,2,
张涵^1,2,
李宁^1,2

1. 合肥水泥研究设计院有限公司, 合肥 230022;
2. 水泥制造绿色低碳技术安徽省重点实验室, 合肥 230022

基金项目:

中国中材国际工程股份有限公司前沿科学开放基金 “水泥窑烟气CO2电化学还原制甲酸关键技术研究”

详细信息

作者简介:
苏明雪（1993—），男，高级工程师，主要研究方向为固废资源化及碳捕集利用。smx@hcrdi.com

计量
- 文章访问数: 8
- HTML全文浏览量: 3
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-05-08
- 网络出版日期: 2026-04-11
- 刊出日期: 2026-02-01

Research on mechanism of catalytic reduction of CO₂ by alkali-heat treated SnO₂/g-C₃N₄

SU Mingxue^1,2,
GU Chunhan^1,2,
ZHANG Han^1,2,
LI Ning^1,2

1. Hefei Cement Research & Design Institute Corporation Ltd., Hefei 230022, China;
2. Anhui Key Laboratory of Green and Low-Carbon Technology in Cement Manufacturing, Hefei 230022, China

摘要

摘要: 电催化还原CO₂是我国实现“双碳”战略的重要途经。石墨相氮化碳（g-C₃N₄）由于其原料来源广泛、制备工艺简单、成本低廉，在电催化领域被广泛用于催化剂或载体。针对g-C₃N₄作为CO₂电还原（eCO₂RR）催化剂载体，存在比表面积小、碱性弱以及实际烟气中低浓度CO₂和O₂竞争还原的瓶颈，研究提出通过碱热处理改性SnO₂/g-C₃N₄复合催化剂的技术路线。XPS和CO₂-TPD等表征结果表明：碱热处理显著提升了g-C₃N₄载体的表面氨基含量（由3.7%增至7.0%），增强了催化剂整体碱性及CO₂吸附能力（由7.69 mmol/g增至48.80 mmol/g）。碱热处理诱导电子从g-C₃N₄中的N元素向Sn活性位点加速转移，形成富电子态Sn中心，并产生更多氧空位，协同促进了CO₂的活化与还原。竞争吸附实验表明，改性后的SnO₂/CNOHHT在CO₂/O₂混合气中对CO₂具有更高的选择性吸附（分离系数0.90），有利于在反应界面形成CO₂富集微环境，抑制O₂还原竞争反应。电催化性能测试显示，在纯CO₂气氛下，SnO₂/CNOHHT电催化还原制甲酸的法拉第效率高达80.5%（电流密度23.5 mA/cm²）；在含4% O₂的模拟烟气氛围下，其甲酸法拉第效率仍可达59.4%，显著优于未改性及碱处理的催化剂。研究为开发适用于实际含氧烟气CO₂高效电还原的g-C₃N₄基催化剂提供了新思路。
- CO₂电还原 /
- 氧化锡 /
- 石墨相氮化碳 /
- 烟气 /
- 传质强化
Abstract: Electrocatalytic reduction of CO₂ （eCO₂RR） is a crucial pathway for China to achieve its "Carbon Peak and Carbon Neutrality" goals. Graphitic carbon nitride （g-C₃N₄） is widely employed as a catalyst or catalyst support in electrocatalysis due to its abundant raw materials， simple preparation process， and low cost. However， g-C₃N₄， when used as a catalyst support for eCO₂RR， faces bottlenecks such as low specific surface area， weak alkalinity， and competitive reduction of low-concentration CO₂ and O₂ in actual flue gas. Therefore， this study proposed a modification strategy for SnO₂/g-C₃N₄ composite catalysts through alkali-thermal treatment. Characterization techniques such as XPS and CO₂-TPD revealed that the alkali-thermal treatment significantly increased the surface amino group content of the g-C₃N₄ support （from 3.7% to 7.0%）， enhancing the overall alkalinity and CO₂ adsorption capacity of the catalyst （from 7.69 mmol/g to 48.80 mmol/g）. This treatment accelerated electron transfer from N atoms in g-C₃N₄ to Sn active sites， forming electron-rich Sn centers and generating more oxygen vacancies. These effects synergistically promoted the activation and reduction of CO₂. Competitive adsorption experiments demonstrated that SnO₂/CNOHHT exhibited a higher adsorption capacity for CO₂ than for O₂ in a CO₂/O₂ mixture （with a separation factor of 0.90）. This selectivity favors the formation of a CO₂-enriched microenvironment at the reaction interface， thereby suppressing the competitive oxygen reduction reaction （ORR）. Electrocatalytic performance tests showed that under a pure CO₂ atmosphere， SnO₂/CNOHHT achieved a high Faradaic efficiency （FE） of 80.5% for formate production at a current density of 23.5 mA/cm². Remarkably， in a simulated flue gas atmosphere containing 4% O₂， it still maintained a FE for formate of 59.4%， significantly outperforming both the unmodified and the alkali-treated-only catalysts. This study provides new insight for developing g-C₃N₄-based eCO₂RR catalysts suitable for practical oxygen-containing flue gas conditions.
- CO₂ electroreduction /
- SnO₂ /
- graphitic carbon nitride /
- flue gas /
- mass transfer enhancement

HTML全文

参考文献(25)

[1]	LIU H，CAI B F，ZHANG L，et al. Research on carbon dioxide abatement technologies and cost in China's power industry［J］. Environmental Engineering，2021，39（10）:8-14. 刘惠，蔡博峰，张立，等. 中国电力行业CO₂减排技术及成本研究［J］. 环境工程，2021，39（10）:8-14.
[2]	LI Q N，CHEN Y G，ZHANG Q R. Research progress on bio-photo/electrocatalytic hybrid systems for efficient CO₂ reduction［J］. Environmental Engineering，2025，43（3）:77-89. 李倩男，陈银广，张清然. 生物光/电催化复合系统用于高效CO₂还原的研究进展［J］. 环境工程，2025，43（3）:77-89.
[3]	JOUNY M，LUC W，JIAO F. General techno-economic analysis of CO₂ electrolysis systems［J］. Industrial& Engineering Chemistry Research，2018，57（6）:2165-2177.
[4]	ZHANG Z K，WAN D，XU H，et al. Research status and developing trend of electro-catalytic reduction of CO₂ based on bibliometric［J］. Environmental Engineering，2022，40（11）:222-230. 张泽坤，万丹，徐浩，等. 基于文献计量的电催化还原CO₂研究状况及发展趋势分析［J］. 环境工程，2022，40（11）:222-230.
[5]	YANG W，JIA L，WU P，et al. Effect of thermal program on structure-activity relationship of g-C₃N₄ prepared by urea pyrolysis and its application for controllable production of g-C₃N₄［J］. Journal of Solid State Chemistry，2021，304:122545.
[6]	REN F Y，SUN Z，MA T，et al. Recent research progress in photocatalytic reduction of CO₂ using g-C₃N₄-based heterostructures［J］. Journal of Fuel Chemistry and Technology，2025，53（1）:40-52. 任富彦，孙振，马涛，等. g-C₃N₄基异质结光还原CO₂的研究进展［J］. 燃料化学学报（中英文），2025，53（1）:40-52.
[7]	LIAO H H，ZOU W X，DONG L. Photocatalytic CO₂ reduction on K-OMS-2/g-C₃N₄ composite［J］. Environmental Chemistry，2025，44（9）:1-8. 廖浩宏，邹伟欣，董林. K-OMS-2/g-C₃N₄复合材料光催化还原CO₂［J］. 环境化学，2025，44（9）:1-8.
[8]	WANG Y，ZHAO Y X，CAI W. Construction of Ni₂P/g-C₃N₄/ZnIn₂S₄ photocatalysts and their boosted photocatalytic reduction of CO₂［J］. Journal of Nanjing University of Information Science& Technology，2024，16（4）:562-572. 王一，赵云霞，蔡炜. Ni₂P/g-C₃N₄/ZnIn₂S₄复合材料的制备及其光还原CO₂性能研究［J］. 南京信息工程大学学报，2024，16（4）:562-572.
[9]	LIU B Z，NIU D F. Highly efficient electrocatalytic reduction of CO₂ to CO by nitrogen-doped carbon/carbon nanotube composite catalysts with abundant mesoporous structures［J］. Journal of Shanghai University，2023，23（5）:960-972. 刘丙泽，钮东方. 富含介孔结构的氮化碳/碳纳米管复合催化剂高效电催化还原CO₂为CO［J］. 上海大学学报，2023，23（5）:960-972.
[10]	ZHU B K，OU H，JIN L L，et al. Fe/C₃N₄ nanoparticles for highly efficient electrocatalytic reduction of carbon dioxide to carbon monoxide［J］. Journal of Zhejiang Ocean University，2020，39（1）:76-81. 竺柏康，欧浩，金凌雷，等. Fe/C₃N₄纳米颗粒用于高效电催化还原CO₂至CO［J］. 浙江海洋大学学报（自然科学版），2020，39（1）:76-81.
[11]	GONG Q. Theoretic study of electrocatalytic CO₂ reduction reaction at composite interface between g-C₃N₄ nanocluster and transition metal［D］. Zhenjiang:Jiangsu University，2024. 龚强. g-C₃N₄纳米团簇与过渡金属复合界面电催化CO₂还原反应的理论研究［D］. 镇江:江苏大学，2024.
[12]	HU C，LIU M T，SAKAI A，et al. Synergistic effect of Cu and Ru decoration on g-C₃N₄ for electrocatalytic CO₂ reduction［J］. Journal of Industrial and Engineering Chemistry，2022，115:329-338.
[13]	MULIK B B，BANKAR B D，MUNDE A V，et al. Electrocatalytic and catalytic CO₂ hydrogenation on ZnO/g-C₃N₄ hybrid nanoelectrodes［J］. Applied Surface Science，2021，538:148120.
[14]	XU Y，EDWAEDS J P，ZHONG J，et al. Oxygen-tolerant electroproduction of C₂ products from simulated flue gas［J］. Energy& Environmental Science，2020，13:554-561.
[15]	LI J J，QIN X R，WANG X R，et al. Direct electroreduction of low-concentration CO₂:progress and perspective［J］. ACS Nano，2025，19:10620-10629.
[16]	LI P S，LU X，WU Z S，et al. Acid-Base interaction enhancing oxygen tolerance in electrocatalytic carbon dioxide reduction［J］. Angewandte Chemie International Edition，2020，59（27）:10918-10923.
[17]	ZHANG B，CHEN S，WULAN B，et al. Surface modification of SnO₂ nanosheets via ultrathin N-doped carbon layers for improving CO₂ electrocatalytic reduction［J］. Chemical Engineering Journal，2021，421:130003.
[18]	WANG G，CHEN J，LI K，et al. Cost-effective and durable electrocatalysts for co-electrolysis of CO₂ conversion and glycerol upgrading［J］. Nano Energy，2022，92:106751-106760.
[19]	HU X，YANG H，GUO M，et al. Synthesis and characterization of（Cu，S）co-doped SnO₂ for electrocatalytic reduction of CO₂ to formate at low overpotential［J］. ChemElectroChem，2018，5（9）:1330-1335.
[20]	LI X，SUN X，ZHANG L，et al. Efficient photocatalytic fixation of N₂ by KOH-treated g-C₃N₄［J］. Journal of Materials Chemistry A，2018，6（7）:3005-3011.
[21]	SUN Z H. The promotion mechanism of g-C₃N₄ modified by alkali in CO₂ photocatalytic reduction and its expanded application in constructing three-component catalyst［D］. Hangzhou:Zhejiang University，2017. 孙朱行. 碱改性g-C₃N₄光催化还原CO₂的性能提升机制及其拓展应用［D］. 杭州:浙江大学，2017.
[22]	SUN Z，FISCHER J M T A，LI Q，et al. Enhanced CO₂ photocatalytic reduction on alkali-decorated graphitic carbon nitride［J］. Applied Catalysis B:Environmental，2017，216:146-155.
[23]	SHANG Y，DING Y，ZHANG P，et al. Pyrrolic N or pyridinic N:The active center of N-doped carbon for CO₂ reduction［J］. Chinese Journal of Catalysis，2022，43:2405-2413.
[24]	TIAN J，WANG M，SHEN M，et al. Highly efficient and selective CO₂ electro-reduction to HCOOH on Sn particle-decorated polymeric carbon nitride［J］. Chem Sus Chem，2020，13（23）:6442-6448.
[25]	KIM Y E，LEE W，YOUN M H，et al. Leaching-resistant SnO₂/γ-Al₂O₃ nanocatalyst for stable electrochemical CO₂ reduction into formate［J］. Industrial& Engineering Chemistry Research，2019，78:73-78.
