Fe3O4-MWCNTs改性NF阴极生物电化学还原CO2产CH4

柴强龙; 章浩文; 孙德智; 孙广东; 王浩鹏; 党岩

doi:10.13205/j.hjgc.202603009

Fe₃O₄-MWCNTs改性NF阴极生物电化学还原CO₂产CH₄

doi: 10.13205/j.hjgc.202603009

柴强龙^1,2,
章浩文^1,2,
孙德智^1,2,
孙广东^1,2,
王浩鹏^1,2,
党岩^1,2, ,

1. 北京林业大学水体污染源控制技术北京市重点实验室，北京 100083;
2. 北京林业大学污染水体源控与生态修复技术北京高校工程研究中心，北京 100083

基金项目:

国家自然科学基金面上项目（52270023）

详细信息

作者简介:
柴强龙（2003—），男，硕士研究生，研究方向为微生物电化学产甲烷。19166160762@163.com

通讯作者:
党岩（1983—），男，教授，主要从事有机固废资源化能源化和废水低能耗处理领域研究。yandang@bjfu.edu.cn

计量
- 文章访问数: 15
- HTML全文浏览量: 3
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2026-02-27
- 网络出版日期: 2026-04-11
- 刊出日期: 2026-03-01

Bioelectrochemical reduction of CO₂ to CH₄via Fe₃O₄-MWCNTs modified nickel foam cathode

1. Beijing Key Lab for Source Control Technology of Water Pollution，Beijing Forestry University，Beijing 100083，China;
2. Beijing Engineering Research Center for Source Control & Eco-remediation Technology of Water Pollution，Beijing Forestry University，Beijing 100083，China

摘要

摘要: 在碳中和目标与能源转型背景下，开发将CO₂高效转化为可再生能源载体（如CH₄）的新技术迫在眉睫。微生物电解池（MECs）作为一种耦合了电化学与微生物代谢的CO₂转化技术，其性能高度依赖于阴极的电子传递能力与生物相容性。因此用Nafion将纳米Fe₃O₄和羧基化多壁碳纳米管负载到泡沫镍（NF）上，并通过EIS、CV、LSV等电化学手段表征其电化学性能，结果表明：经过改性的NF具有更低的内阻、更大的电化学活性面积和更好的析氢能力。最终将其用于恒电流双室厌氧产甲烷MECs的阴极，通过电化学还原CO₂产CH₄。结果表明：在-0.1 A恒电流下，纳米Fe₃O₄和羧基化多壁碳纳米管改性泡沫镍（F/C-NF）组的产CH₄浓度可达到90%，高于NF组的80%，且F/C-NF组的CH₄日均产量为295 mL，高于NF组的260 mL，相比提高了13%，这是由于改性后的泡沫镍有更高的H₂产量和更低的内阻，有利于嗜氢产甲烷菌生长富集以电化学还原CO₂产CH₄。微生物群落分析也表明，F/C-NF组反应器中的氢营养型产甲烷菌Methanobacterium的相对丰度比NF组更高，这也有利于H₂作为电子供体还原CO₂产CH₄过程的发生。研究成果为推动生物电化学体系的新型非贵金属复合阴极材料提供了新的思路与实验依据。
- 微生物电解池 /
- 纳米Fe₃O₄ /
- 碳纳米管 /
- 改性泡沫镍 /
- 产甲烷菌
Abstract: In the context of global carbon neutrality goals and energy transformation，it is urgent to develop new technologies that efficiently convert CO₂ into renewable energy carriers such as CH₄. Microbial electrolysis cells （MECs）， which couple electrochemistry with microbial metabolism for CO₂ conversion， exhibit performance that is heavily dependent on the electron transfer capabilities and biocompatibility of the cathode.Therefore，Nafion was employed to load nanoscale Fe₃O₄ and carboxylated multi-walled carbon nanotubes onto nickel foam （NF）. The electrochemical performance of the modified NF was characterized using techniques such as electrochemical impedance spectroscopy （EIS），cyclic voltammetry （CV），and linear sweep voltammetry （LSV）. The results indicated that the modified NF exhibited lower internal resistance，a larger electrochemical active surface area，and enhanced hydrogen evolution capabilities.Ultimately，this modified cathode was employed in a constant current dual-chamber anaerobic methanogenic MECs for the electrochemical reduction of CO₂ to CH₄.The results demonstrated that under a constant current of -0.1 A，the CH₄concentration of the nanoscale Fe₃O₄ and carboxylated multi-walled carbon nanotube-modified NF group could reach 90%，surpassing the 80% CH₄ concentration of the NF group. Moreover，the daily CH₄ production of the modified group was 295 mL，higher than the 260 mL daily methane production of the NF group，reflecting an increase of 13%. It was found that the modified NF exhibited higher hydrogen production and lower internal resistance， creating a more favorable environment for the growth and enrichment of hydrogenotrophic methanogens， thereby facilitating the electrochemical reduction of CO₂ to CH₄. Subsequent microbial community analysis also indicated that the relative abundance of the hydrogenotrophic methanogen Methanobacterium in the reactor with the modified NF was higher than that in the NF group，further facilitating the process of H₂ serving as an electron donor for CO₂ reduction to CH₄. This research provides new ideas and experimental evidence for the development of novel non-precious metal composite cathode materials in bioelectrochemical systems.
- microbial electrolysis cell /
- nanoscale Fe₃O₄ /
- carbon nanotubes /
- modified nickel foam /
- methanogen

HTML全文

参考文献(34)

[1]	HUEI-RU MOLLY J，MA S，KENIS P J. Electrochemical conversion of CO₂ to useful chemicals：current status，remaining challenges，and future opportunities[J]. Current Opinion in Chemical Engineering，2013（2）：191-199.
[2]	GATTRELL M，GUPTA N，CO A. A review of the aqueous electrochemical reduction of CO₂ to hydrocarbons at copper[J]. Journal of Electroanalytical Chemistry，2006，594（1）：1-19.
[3]	QIAO J，LIU Y，HONG F，et al. A review of catalysts for the electroreduction of carbon dioxide to produce low-carbon fuels[J]. Chemical Society reviews，2014，43（2）：631-675.
[4]	NEVIN D R L A. Electrobiocommodities：powering microbial production of fuels and commodity chemicals from carbon dioxide with electricity[J]. Current Opinion in Biotechnology，2013（24）：385-390.
[5]	SU C Y，ZHENG P，LU Y X，et al. Effects of magnetic Fe₃O₄ nanoparticles on the characteristics of anaerobic granular sludge and its interior microbial community[J]. Environmental Science，2018，39（3）：1316-1324. 宿程远，郑鹏，卢宇翔，等. 磁性纳米铁对厌氧颗粒污泥特性及其微生物群落的影响[J]. 环境科学，2018，39（3）：1316-1324.
[6]	ZHANG W J，HOU C L，LI T H，et al. Magnetic and electrocatalytic properties of multi-walled carbon nanotube/Fe₃O₄ composites[J]. The Chinese Journal of Nonferrous Metals，2012，22（9）：2594-2599. 张文娟，侯翠岭，李铁虎，等. 碳纳米管/四氧化三铁复合材料的磁性能和电催化性能[J]. 中国有色金属学报，2012，22（9）：2594-2599.
[7]	YE R R，CAO Y Y，ZHOU L N，et al. Research progress of three-dimensional self-supporting electrocatalytic hydrogen evolution catalyst[J]. Scientia Sinica Chimica，2025，55（3）：636-660. 叶荣榕，曹圆圆，周丽娜，等. 三维自支撑电催化析氢催化剂的研究进展[J]. 中国科学：化学，2025，55（3）：636-660.
[8]	LI Y C，WANG Z，YUAN T，et al. Binding site diversity promotes CO₂ electroreduction to ethanol[J]. Journal of the American Chemical Society，2019，141（21）：8584-8591.
[9]	LIU C Q. The study of mechanism and application of in-situ biogas upgrading in microbial electrochemical systems based on direct electron[D]. Beijing：Beijing Forestry University，2025. 刘传奇. 基于直接电子传递的微生物电化学原位沼气提质的机制与应用研究[D]. 北京：北京林业大学，2025.
[10]	SHANG G，YU J，CAI W，et al. Comparison of in-situ and ex-situ electrolytic H₂ supply for microbial methane production from CO₂[J]. Bioresource Technology，2023，388：129728.
[11]	PEIFFER J A，SPOR A，KOREN O，et al. Diversity and heritability of the maize rhizosphere microbiome under field conditions[J]. Proceedings of the National Academy of Sciences，2013，110（16）：6548-6553.
[12]	HUI S，JIANG Y，JIANG Y，et al. Cathode materials in microbial electrosynthesis systems for carbon dioxide reduction：recent progress and perspectives[J]. Energy Materials，2023，3（6）：300055.
[13]	CAI W W. Enhanced methane production from wastewater through the extrcellular electron transfer mechanism[D]. Harbin：Harbin Institute of Technology，2018. 蔡伟伟. 基于胞外电子传递作用强化污水厌氧产甲烷效能研究[D]. 哈尔滨：哈尔滨工业大学，2018.
[14]	WANG Y T. Research on microbial electrolysis cell based on nickel-based cathode modification and alkaline control for simultaneous purification of wastewater and production of hydrogen[D]. Guangzhou：Guangzhou University，2025. 王元通. 基于镍基阴极修饰和碱性调控的微生物电解池同步污水净化和产氢研究[D]. 广州：广州大学，2025.
[15]	ZHANG Z Y. Development of iron-bearing multi-dimensional electrode for enhancing CO₂ electromethanogenesis in microbial electrolysis cell and the possible molecular mechanisms of electron transport[D]. Shanghai：East China Normal University，2022. 张衷译. 铁基负载多维材料强化微生物电解池还原CO₂产甲烷效能及界面电子传输分子机制研究[D]. 上海：华东师范大学，2022.
[16]	ZHOU J M，WANG Y，TANG P P，et al. Growth of multi-walled carbon nanotubes by catalytic pyrolysis of CH₄ in fluidized-bed reactor[J]. Chinese Journal of Applied Chemistry，2005，22（2）：117-122. 周金梅，王毅，汤培平，等. 甲烷在流态化催化剂床裂解生长多壁碳纳米管[J]. 应用化学，2005，22（2）：117-122.
[17]	SUN K. Preparation and characterization of novel proton exchange membrane based on Nafion[D]. Beijing：Beijing Jiaotong University，2009. 孙琨. 基于Nafion膜改性的新型质子交换膜的制备与表征[D]. 北京：北京交通大学，2009.
[18]	ZHU G X，LI X Y，LIU Y J，et al. Scalable surface engineering of commercial metal foams for defect-rich hydroxides towards improved oxygen evolution[J]. Journal of Materials Chemistry A，2020，8（25）：12603-12612.
[19]	OOI F，DUCHENE J S，QIU J，et al. A facile solvothermal synthesis of octahedral Fe₃O₄ nanoparticles[J]. Small，2015，11（22）：2649-2653.
[20]	WEI G，JIA C，LIU J，et al. Carbon felt supported carbon nanotubes catalysts composite electrode for vanadium redox flow battery application[J]. Journal of Power Sources，2012，220：185-192.
[21]	SONG T S，FEI K，ZHANG H，et al. High efficiency microbial electrosynthesis of acetate from carbon dioxide using a novel graphene-nickel foam as cathode[J]. Journal of Chemical Technology& Biotechnology，2018，93（2）：457-466.
[22]	LIM S S，FONTMORIN J，IZADI P，et al. Impact of applied cell voltage on the performance of a microbial electrolysis cell fully catalysed by microorganisms[J]. International Journal of Hydrogen Energy，2020，45（4）：2557-2568.
[23]	MARSILI E，ROLLEFSON J B，BARON D B，et al. Microbial biofilm voltammetry：direct electrochemical characterization of catalytic electrode-attached biofilms[J]. Applied and Environmental Microbiology，2008，74（23）：7329-7337.
[24]	SIEGERT M，YATES M D，SPORMANN A M，et al. Methanobacterium dominates biocathodic archaeal communities in methanogenic microbial electrolysis cells[J]. ACS Sustainable Chemistry& Engineering，2015，3（7）：1668-1676.
[25]	WANG C，YE X，LIU Y，et al. Enhanced anaerobic digestion for degradation of swine wastewater through a Fe/Ni-MOF modified microbial electrolysis cell[J]. Journal of Cleaner Production，2022，380：134773.
[26]	VILLANO M，AULENTA F，CIUCCI C，et al. Bioelectrochemical reduction of CO₂ to CH₄ via direct and indirect extracellular electron transfer by a hydrogenophilic methanogenic culture[J]. Bioresource Technology，2010，101（9）：3085-3090.
[27]	LEE J K，LEE H IN，CHO H S，et al. Redox reactivity of titania-doped YSZ-promoted iron-based oxygen carrier over multiple redox cycles for chemical looping reforming of methane and hydrogen production[J]. International Journal of Energy Research，2020，44（6）：4919-4932.
[28]	KATO S，HASHIMOTO K，WATANABE K. Methanogenesis facilitated by electric syntrophy via（semi）conductive iron-oxide minerals[J]. Environmental Microbiology，2012，14（7）：1646-1654.
[29]	WANG H，REN Z J. A comprehensive review of microbial electrochemical systems as a platform technology[J]. Biotechnology Advances，2013，31（8）：1796-1807.
[30]	COSTA K C，WHITMAN W B. Model organisms to study methanogenesis，a uniquely archaeal metabolism[J]. Journal of Bacteriology，2023，205（8）：e00123-23.
[31]	YAMAMOTO S，SUZUKI K，ARAKI Y，et al. Dynamics of different bacterial communities are capable of generating sustainable electricity from microbial fuel cells with organic waste[J]. Microbes and Environments，2014，29（2）：145-153.
[32]	HUSSAIN A，GUIOT S R，MEHTA P，et al. Electricity generation from carbon monoxide and syngas in a microbial fuel cell[J]. Applied Microbiology and Biotechnology，2011，90（3）：827-836.
[33]	XIE Z，WANG Z，WANG Q，et al. An anaerobic dynamic membrane bioreactor（AnDMBR）for landfill leachate treatment：performance and microbial community identification[J]. Bioresource Technology，2014，161：29-39.
[34]	WU M，ZHANG M，SHEN L，et al. High propensity of membrane fouling and the underlying mechanisms in a membrane bioreactor during occurrence of sludge bulking[J]. Water Research，2023，229：119456.
