固相萃取-液相色谱-串联四极杆质谱法测定地表水中22种全氟和多氟烷基类化合物

唐诗; 孙涛; 孙攀; 陈杰

doi:10.13205/j.hjgc.202604002

固相萃取-液相色谱-串联四极杆质谱法测定地表水中22种全氟和多氟烷基类化合物

doi: 10.13205/j.hjgc.202604002

唐诗¹,
孙涛^2, ,,
孙攀¹,
陈杰¹

1. 河南省郑州生态环境监测中心, 郑州 450007;
2. 北京师范大学环境学院, 北京 100875

基金项目:

国家自然科学基金山东联合基金重点项目“黄河三角洲盐沼湿地退化与生态保护机制研究”（U1806217）

详细信息

作者简介:
唐诗(1989—),女,工程师,主要研究方向为环境监测。tangshi89@163.com

通讯作者:
孙涛(1975—),男,教授,主要研究方向为生态需水。Suntao@bnu.edu.cn

计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-12-10
- 网络出版日期: 2026-06-06
- 刊出日期: 2026-04-01

Determination of 22 per- and polyfluoroalkyl substances in surface water by solid-phase extraction with ultra-high performance liquid chromatography-tandem mass spectrometry

TANG Shi¹,
SUN Tao^{2
, ,},
SUN Pan¹,
CHEN Jie¹

1. Zhengzhou Ecological Environment Monitoring Center of Henan Province, Zhengzhou 450007, China;
2. School of Environment, Beijing Normal University, Beijing 100875, China

摘要

摘要: 建立了一种基于超高效液相色谱-串联四极杆质谱（UHPLC-MS/MS）联用技术，用于测定地表水中22种全/多氟烷基类化合物（PFAS）的分析方法。该方法增设了颗粒物甲醇提取环节：将水样过滤后，对截留的颗粒物用甲醇提取，再将颗粒物甲醇提取液与水样滤液合并，实现对“溶解态-颗粒态”两相中PFAS的高效捕获。样品经弱阴离子交换（WAX）固相萃取（SPE）柱富集和净化后，洗脱液经氮吹浓缩，用甲醇/水（体积比为8∶2）复溶、过滤，随后进样至UHPLC-MS/MS系统进行分离和检测，并采用同位素内标法定量分析。结果表明，该方法在1~250 μg/L的浓度范围内线性关系良好（R²>0.995）；水样中各目标化合物的方法检出限为0.2~0.6 ng/L，方法定量限为0.8~2.4 ng/L；在空白水基质和地表水基质中，目标化合物的回收率分别为85.3%~139%和76.4%~127%，且相对标准偏差（RSD，n=6）均<15%。与未提取颗粒态PFAS的传统方法相比，该方法对地表水基质中目标化合物的回收率具有显著优势。结果表明，所开发的方法灵敏、准确、可靠，其通过增设甲醇提取步骤可有效消除颗粒吸附导致的负偏差，显著提高PFAS的回收率，适用于环境地表水基质中22种常见PFAS的定量筛查。
- 超高效液相色谱串联四极杆质谱 /
- 全/多氟烷基类化合物 /
- 固相萃取 /
- 颗粒态全/多氟烷基类化合物
Abstract: A method for the determination of 22 per- and polyfluoroalkyl substances （PFAS） by ultra-high performance liquid chromatography-tandem mass spectrometry （UPLC-MS/MS） was developed. The optimized method involves extracting particulate matter from filtered water samples with methanol， followed by combining the particulate methanol extract with the filtrate， thereby enabling efficient capture of PFAS from both dissolved and particulate phases. The samples were concentrated and purified using weak anion exchange （WAX） solid-phase extraction （SPE） columns. After nitrogen blowing， the residue was reconstituted in methanol/water （V/V=8∶2） and filtered prior to analysis by mass spectrometry， with quantification performed via the isotope internal standard method. The linear correlation coefficients （R²） of the standard curves for the 22 PFAS were all greater than 0.995， with linear ranges of 1 to 100 µg/L， detection limits of 0.2 to 0.6 ng/L， and quantification limits of 0.8 to 24 ng/L. The recovery rates of the 22 PFAS in blank water and surface water ranged from 85.3% to 139% and 76.4% to 127%， respectively， with relative standard deviations （RSD） of less than 15% （n=6）. Compared with the methods that do not involve the extraction of particulate PFAS， this method exhibited distinct advantages in the recovery rates of the 22 PFAS in surface water. These results demonstrate that the developed method is sensitive， accurate， and reliable. The incorporation of a methanol extraction step can effectively eliminate the negative bias induced by particulate adsorption， thus significantly enhancing the recovery of PFAS. This method is suitable for the quantitative determination of 22 common PFAS in surface water.

HTML全文

参考文献(22)

[1]	US EPA. PFAS Structure Lists［EB/OL］. 2022- 08. https://comptox.epa.gov/dashboard/chemical-lists/PFASSTRUCT.
[2]	WANG Z，DEWITT J C，HIGGINS C P，et al. Neverending story of per-and polyfluoroalkyl substances（PFASs）［J］. Environmental Science and Technology. 2017，51：2508- 2518.
[3]	CHEN H C，CAO W C，LIU X F，et al. Contamination levels of perfluorinated and polyfluoroalkyl compounds in breast milk and assessment of their exposure risk to infants［J］. Chinese Journal of Chromatography，2024，42（2）：211- 216. 陈海川，曹文成，刘小方，等. 母乳中全氟及多氟烷基化合物污染水平及婴儿暴露风险评估［J］. 色谱，2024，42（2）：211- 216.
[4]	FENTON S E，DUCATMANB A，BOOBISC A，et al. Per-and polyfluoroalkyl substance toxicity and human health review：current state of knowledge and strategies for informing future research［J］. Environmental Toxicology and Chemistry，2021，40（3）：606- 630.
[5]	LINDSTROM A B，STRYNAR M J，LIBELO E L. Polyfluorinated compounds:past，present，and future［J］. Environmental Science and Technology，2011，45：7954- 7961.
[6]	State Adminastration for Market Regulation，National standardization Adminastration of the People’s Republic of China. Standards for drinking water quality：GB 5749—2022［S］. Beijing：Standards Press of China，2022. 国家市场监督管理总局，国家标准化管理委员会. 生活饮用水卫生标准：GB 5749—2022［S］. 北京：中国标准出版社，2022.
[7]	Ministry of Ecology and Environment of the People’s Republic of China，Ministry of Industry and Information Technology of the People’s Republic of China，Ministry of Agriculture and Rural Affairs of the People’s Republic of China，et al. Key control list of new pollutants（2023 Edition）（No.28）［S］. 2022. 中国生态环境部，工业和信息化部，农业农村部，等. 重点管控新污染物清单（2023年版）（部令第28号）［S］. 2022.
[8]	Ministry of Ecology and Environment of the People’s Republic of China. Water quality Determination of perfluorooctanesulfonic acid，perfluorooctanoic acid and their salts Isotope dilution liquid chromatography-triple quadrupole mass spectrometry：HJ 1333—2023［S］. Beijing：China Environmental Publishing Group Co.，Ltd，2023. 生态环境部. 水质全氟辛基磺酸和全氟辛酸及其盐类的测定同位素稀释/液相色谱-三重四极杆质谱法：HJ 1333—2023［S］. 北京：中国环境出版集团有限公司，2023.
[9]	Ministry of Ecology and Environment of the People’s Republic of China. Soil and sediment Determination of perfluorooctanesulfonic acid，perfluorooctanoic acid and their salts Isotope dilution liquid chromatography-triple quadrupole mass spectrometry：HJ 1334—2023［S］. Beijing：China Environmental Publishing Group Co.，Ltd，2023. 生态环境部. 土壤和沉积物全氟辛基磺酸和全氟辛酸及其盐类的测定同位素稀释/液相色谱-三重四极杆质谱法：HJ 1334—2023［S］. 北京：中国环境出版集团有限公司，2023.
[10]	ZHANG C，MCELROY A C，LIBERATORE H K，et al. Stability of per-and polyfluoroalkyl substances in solvents relevant to environmental and toxicological analysis［J］. Environmental Science and Technology，2022，56（10）：6103- 6112.
[11]	Ministry of Ecology and Environment of the People’s Republic of China. Technical guideline for the development of environmental monitoring analytical method standards:HJ 168—2020［S］. Beijing：China Environmental Publishing Group Co.，Ltd，2020. 生态环境部. 环境监测分析方法标准制订技术导则：HJ 168—2020［S］. 北京：中国环境出版集团有限公司，2020.
[12]	WANG Q H，XIONG M Y，MENG L，et al. Determination of 8 perfluorinated compounds in surface water by on-line solid phase extraction-high performance liquid chromatography-tandem mass spectrometry［J］. Environmental Chemistry，2023，42（2）：388- 398. 王巧环，熊满艳，孟龄，等. 在线固相萃取-高效液相色谱-串联质谱法测定地表水中8种全氟化合物［J］. 环境化学，2023，42（2）：388- 398.
[13]	ZHAO C C，CHEN Y，HOU X L，et al. Direct determination of 15 kinds of perfluoroalkyl substances in water by liquid chromatography-tandem mass spectrometry coupled with online solid phase extraction［J］. Environmental Monitoring in China，2024，40（2）：185- 197. 赵陈晨，陈勇，侯晓玲，等. 在线固相萃取-液相色谱-串联质谱法直接测定水中15种全氟烷基化合物［J］. 中国环境监测，2024，40（2）：185- 197.
[14]	WU P，WANG W，LIU H M，et al. Determination of 25 per-and polyfluoroalkyl substances in complex water by ultra high performance liquid chromatography-tandem mass spectrometry［J］. Chemical Analysis and Meterage，2025，34（1）：12- 20. 吴萍，王炜，刘惠敏，等. 超高效液相色谱-串联质谱法测定复杂水质中25种全氟/多氟化合物［J］. 化学分析计量，2025，34（1）：12- 20.
[15]	YANG Y Y，LI S L，ZHAO J L，et al. Determination of 57 kinds of Per-and Polyfluoroalkyl Substances in water，sediments and biological samples by ultra-high performance liquid chromatography- tandem mass spectrometry［J］. Chinese Journal of Analytical Chemistry，2022，50（8）：1243- 1251. 杨愿愿，李偲琳，赵建亮，等. 超高效液相色谱-串联质谱法同时测定水、沉积物和生物样品中57种全/多氟化合物［J］. 分析化学，2022，50（8）：1243- 1251.
[16]	WANG G Q，WANG W W，ZHANG F J. Determination of 17 perfluorinated compounds in water by solid phase extraction with liquid chromatography-tandem mass spectrometry［J］. Journal of Analytical Science，2024，40（6）：709- 714. 王国庆，王维维，张凤杰. 固相萃取-液相色谱-串联质谱法测定水中17种全氟化合物［J］. 分析科学学报，2024，40（6）：709- 714.
[17]	LIU X L，LIU J，GUO R，et al. Ultra performance liquid chromatography-tandem mass spectrometry for determination of per-and polyfluorinated compounds in surface water［J］. Chinese Journal of Analytical Chemistry，2018，46（9）：1400- 1407. 刘晓雷，刘婕，郭睿，等. 超高效液相色谱-串联质谱法测定表层水中全氟及多氟化合物［J］. 分析化学，2018，46（9）：1400- 1407.
[18]	ZHOU H Y，GONG X J，JIANG J，et al. Determination of seventeen perfluorinated compounds in water by solid phase extraction coupled with HPLC-ESI-MS/MS［J］. Textile Auxiliaries，2024，41（7）：62- 70. 周昊昱，龚孝铰，蒋晶，等. 固相萃取-HPLC-ESI-MS/MS法测定水中全氟化合物［J］. 印染助剂，2024，41（7）：62- 70.
[19]	LIU T，ZHOU Y Q，SONG Z，et al. Determination of 17 perfluorinated compounds in water by fully-automated SPE-UPLC-MS/MS［J］. Chemical Research and Application，2025，37（2）：410- 418. 刘田，周宇齐，宋洲，等. 全自动固相萃取-UPLC-MS/MS法测定水中17种全氟化合物［J］. 化学研究与应用，2025，37（2）：410- 418.
[20]	State Adminastration for Market Regulation，National standardization Adminastration of the People’s Republic of China. Standard examination methods for drinking water-Part 8：Organic indices:GB/T 5750.8—2023［S］. Beijing：Standards Press of China，2023. 国家市场监督管理总局，国家标准化管理委员会. 生活饮用水标准检验方法第8部分：有机物指标：GB/T 5750.8—2023［S］. 北京：中国标准出版社，2023.
[21]	China National Environmental Monitroring Centre. Guidelines for the investigation of water quality of national centralized drinking water sources（2024—2026）［R］. 2024. 中国环境监测总站. 全国集中式饮用水水源水质专项调查作业指导书（2024—2026年）［R］. 2024.
[22]	Jiangsu Province of Adminastration for Market Regulation. Water quality Determination of 17 Perfluoroalkyl Acids High performance liquid chromatography-tandem mass spectrometry：DB 32/T 4004—2021［S］. Nanjing：Jiangsu Province of Adminastration for Market Regulation，2021. 江苏省市场监督管理局. 水质 17种全氟化合物的测定高效液相色谱串联质谱法：DB 32/T 4004—2021［S］. 南京：江苏省市场监督管理局，2021.
