碳毡-铁-壳聚糖电极强化低C/N污水铁自养反硝化脱氮中试

吕同慧; 安法财; 孙德智

doi:10.13205/j.hjgc.202604008

碳毡-铁-壳聚糖电极强化低C/N污水铁自养反硝化脱氮中试

doi: 10.13205/j.hjgc.202604008

北京林业大学环境与工程学院北京市水体污染源与控制技术重点实验室, 北京 100083

基金项目:

国家自然科学基金面上项目“异养氨氧化强化垃圾焚烧渗沥液脱氮处理过程的机制与系统优化研究”（52270024）

详细信息

作者简介:
吕同慧(2001—),女,研究生,主要研究方向为水体污染控制技术。lthhcm@163.com

通讯作者:
孙德智(1960—),男,教授,主要从事污染水体源控与生态修复研究。sdzlab@126.com

计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2026-03-15
- 网络出版日期: 2026-06-06
- 刊出日期: 2026-04-01

A pilot-scale study on iron-driven autotrophic denitrification enhanced by CF-Fe-CS cathode for low C/N wastewater treatment

Beijing Key Laboratory for Source Control Technology of Water Pollution, College of Environmental Science and Engineering, Beijing Forestry University, Beijing 100083, China

摘要

摘要: 城镇污水处理厂尾水由于其低碳氮比（C/N）特征，用传统异养反硝化工艺深度脱氮需投加大量碳源，导致成本高且易产生二次污染。铁自养反硝化（NAFO）是一种具有应用潜力的反硝化技术，但存在铁源不可持续和易钝化的瓶颈。构建了内置表观填充率为5%的复合阴极碳毡-铁-壳聚糖（CF-Fe-CS）电极，有效容积为200 L，处理能力为100 L/d的CF-Fe-CS/NAFO系统，在阴极施加-1.0 V（vs.Ag/AgCl）恒定电势以实现Fe（Ⅲ）的原位电化学还原。系统在水力停留时间（HRT）为48 h、以ρ（NO₃^--N）为15 mg/L人工配水为进水的连续稳定运行的16~60 d内，系统出水ρ（NO₃^--N）浓度稳定低于6.5 mg/L，总氮（TN）去除率维持在50%~60%；而对照组出水ρ（NO₃^--N）>12 mg/L，TN去除率<20%。在以污水处理厂二沉池出水为进水的第61~74天的连续运行中，系统出水ρ（NO₃^--N）由15.29 mg/L降至6.06 mg/L，TN去除率仍保持在50%以上。将HRT由48 h依次调整为24，12，6，3h的第74~98天的连续运行中，出水ρ（NO₃^--N）浓度分别达到9.5，11.9，13.6，14.6 mg/L，TN去除率分别为32.6%、19.9%、10.9%和5.8%。上述研究结果表明，在无需外加有机碳源的条件下，CF-Fe-CS/NAFO电化学系统能够实现城镇污水处理厂二沉池出水长期、稳定深度脱氮。
- 污水处理厂深度脱氮 /
- 铁自养反硝化 /
- 碳毡-铁-壳聚糖电极 /
- 中试试验
Abstract: The effluent from municipal wastewater treatment plants （WWTPs） is characterized by a low carbon-to-nitrogen （C/N） ratio in China. Achieving deep nitrogen removal using traditional heterotrophic denitrification processes requires substantial external carbon source addition， leading to high operational costs and potential secondary pollution. Nitrate-dependent ferrous oxidation （NDFO） presents a promising alternative denitrification technology. However， it faces bottlenecks such as unsustainable iron sources and surface passivation. In this study， a pilot-scale electrochemical-biological coupled system （CF-Fe-CS/NAFO） was constructed， featuring a built-in composite cathode （5% apparent filling rate of carbon felt-iron-chitosan， CF-Fe-CS）， an effective volume of 200 L， and a treatment capacity of 100 L/d. A constant potential of -1.0 V （vs. Ag/AgCl） was applied to the cathode to achieve the in-situ electrochemical reduction of Fe（Ⅲ）. In the test reactor， during stable operation from day 16 to 60 with a hydraulic retention time （HRT） of 48 h and synthetic wastewater containing 15 mg/L NO₃^--N， the effluent NO₃^--N concentration remained consistently below 6.5 mg/L， with a total nitrogen （TN） removal efficiency of 50% to 60%. In contrast， the control reactor （without an applied potential） showed an effluent NO₃^--N concentration above 12 mg/L and a TN removal efficiency below 20%. During continuous operation from day 61 to 74 using real secondary sedimentation tank effluent from a WWTP （influent NO₃^--N： 15.29 mg/L）， the system reduced the effluent NO₃^--N to 6.06 mg/L， maintaining a TN removal efficiency above 50%. From day 74 to 98， as the HRT was sequentially reduced from 48 h to 24 h， 12 h， 6 h， and 3 h， the corresponding effluent NO₃^--N concentrations increased to 9.5 mg/L， 11.9 mg/L， 13.6 mg/L， and 14.6 mg/L， with TN removal efficiencies of 32.6%， 19.9%， 10.9%， and 5.8%， respectively. These results demonstrate that the CF-Fe-CS/NAFO electrochemical system can achieve long-term， stable， and advanced nitrogen removal from WWTP secondary effluent without the need for an external organic carbon source.
- advanced nitrogen removal from WWTPs /
- iron-driven autotrophic denitrification /
- carbon felt-iron-chitosan cathode /
- pilot-scale experiment

HTML全文

参考文献(43)

[1]	YANG Z，ZHOU Q，SUN H，et al. Metagenomic analyses of microbial structure and metabolic pathway in solid-phase denitrification systems for advanced nitrogen removal of wastewater treatment plant effluent：A pilot-scale study［J］. Water Research，2021，196：117067.
[2]	ZHANG D，LIU Y，HAN Y，et al. Nitrate removal from low C/N wastewater at low temperature by immobilized Pseudomonas sp. Y39-6 with versatile nitrate metabolism pathways［J］. Bioresource Technology，2021，326：124794.
[3]	HERATH A，REID C，PEREZ F，et al. Biochar-supported polyaniline hybrid for aqueous chromium and nitrate adsorption［J］. Journal of Environmental Management，2021，296：113186.
[4]	GONG L，QI J，LÜ N，et al. Mechanistic role of nitrate anion in TCE dechlorination by ball milled ZVI and sulfidated ZVI：Experimental investigation and theoretical analysis［J］. Journal of Hazardous Materials，2021，403：123844.
[5]	BI Z，ZHANG Q，XU X，et al. Perspective on inorganic electron donor-mediated biological denitrification process for low C/N wastewaters［J］. Bioresource Technology，2022，363：127890.
[6]	EBRAHIMI S，ROBERTS D J. Mathematical modelling and reactor design for multi-cycle bioregeneration of nitrate exhausted ion exchange resin［J］. Water Research，2016，88：766- 776.
[7]	HU Z，LI D，DENG S，et al. Combination with catalyzed Fe（0）-carbon microelectrolysis and activated carbon adsorption for advanced reclaimed water treatment：simultaneous nitrate and biorefractory organics removal［J］. Environmental Science and Pollution Research，2019，26（6）：5693- 5703.
[8]	WANG Y，LIN Z，HUANG W，et al. Electron storage and resupply modes during sulfur cycle enhanced nitrogen removal stability in electrochemically assisted constructed wetlands under low temperature［J］. Bioresource Technology，2020，300：122704.
[9]	CHENG Q，TU Y，NENGZI L，et al. Advanced C，N and P removal performance and mechanism of municipal wastewater in lab-scale denitrifying filter for generating biogenic manganese oxides［J］. Separation and Purification Technology，2025，362：131855.
[10]	KANG D，ZHAO X，WANG N，et al. Redirecting carbon to recover VFA to facilitate biological short-cut nitrogen removal in wastewater treatment：A critical review［J］. Water Research，2023，238：120015.
[11]	LI L，ZHANG J，SHI Q，et al. Comparison of nitrogen removal performance and mechanism from low-polluted wastewater by constructed wetlands with two oxygen supply strategies:Tidal flow and intermittent aeration［J］. Chemosphere，2023，313：137364.
[12]	FU X，HOU R，YANG P，et al. Application of external carbon source in heterotrophic denitrification of domestic sewage：A review［J］. Science of the Total Environment，2022，817：153061.
[13]	ZHOU T，LIU J，LIE Z，et al. Effects of applying different carbon substrates on nutrient removal and greenhouse gas emissions by constructed wetlands treating carbon-depleted hydroponic wastewater［J］. Bioresource Technology，2022，357：127312.
[14]	SHAO M F，ZHANG T，FANG H. Sulfur-driven autotrophic denitrification：Diversity，biochemistry，and engineering applications［J］. Applied Microbiology and Biotechnology，2010，88：1027- 1042.
[15]	TIAN T，YU H Q. Denitrification with non-organic electron donor for treating low C/N ratio wastewaters［J］. Bioresource Technology，2020，299：122686.
[16]	SHIN K H，CHA D K. Microbial reduction of nitrate in the presence of nanoscale zero-valent iron［J］. Chemosphere，2008，72（2）：257- 262.
[17]	YUAN Q，GAO J，LIU P，et al. Autotrophic denitrification based on sulfur-iron minerals:advanced wastewater treatment technology with simultaneous nitrogen and phosphorus removal［J］. Environmental Science and Pollution Research，2024，31（5）：6766- 6781.
[18]	ZHOU Y，CHEN Y，YANG J，et al. Insight into the enhancing mechanism of exogenous electron mediators on biological denitrification in microbial electrolytic cell［J］. Science of the Total Environment，2023，896：165096.
[19]	LIU C，GUO Z，ZHANG H，et al. Single-cell Raman spectra reveals the cytochrome c-mediated electron transfer in nanoscale zero-valent iron coupled denitrification process［J］. Chemical Engineering Journal，2023，454：140241.
[20]	MA Z，ZHAI S，SUN P. Enhancement mechanism of iron autotrophic denitrification system based on resource utilization of waste membranes［J］. Water Research，2025，287：124410.
[21]	WANG R，YANG C，ZHANG M，et al. Chemoautotrophic denitrification based on ferrous iron oxidation：Reactor performance and sludge characteristics［J］. Chemical Engineering Journal，2017，313：693- 701.
[22]	TIAN T，ZHOU K，LI Y S，et al. Recovery of iron-dependent autotrophic denitrification activity from cell-iron mineral aggregation-induced reversible inhibition by low-intensity ultrasonication［J］. Environ Sci Technol，2022，56（1）：595- 604.
[23]	FLORES-ALSINA X，SOLON K，KAZADI MBAMBA C，et al. Modelling phosphorus（P），sulfur（S）and iron（Fe）interactions for dynamic simulations of anaerobic digestion processes［J］. Water Research，2016，95：370- 382.
[24]	QIU A，QIAN A，LIAO P，et al. In-situ generation of diverse Fe（Ⅱ）species via iron electrocoagulation for redox transformation of contaminants-a critical review［J］. Separation and Purification Technology，2025，354：129224.
[25]	YAO X. Study and application of chitosan-modified electrodes［D］. Wuhan：Central China Normal University，2001. 姚鑫. 壳聚糖修饰电极的研究及应用［D］. 武汉：华中师范大学，2001.
[26]	AN F，ZHOU Z，SUN D. Micron zero-valent iron chitosan hydrogel balls boosts nitrate removal in constructed wetlands for secondary effluent treatment［J］. Bioresource Technology，2024，391：129971.
[27]	State Environmental Protection Administration. Water quality-determination of nitrate-nitrogen-ultraviolet spectrophotometry：HJ/T 346—2007［S］. Beijing：China Environmental Science Press，2007. 国家环境保护总局. 水质硝酸盐氮的测定紫外分光光度法（试行）：HJ/T 346—2007［S］. 北京：中国环境科学出版社，2007.
[28]	State Environmental Protection Administration，State Bureau of Technical Supervision. Determination of nitrite in the wet precipitation-N-（1-naphthyl）-1，2-diaminoethane dihydrochloride spectrophotometry：GB/T 13580.7—1992［S］. Beijing：Standards Press of China，1992. 国家环境保护局，国家技术监督局. 大气降水中亚硝酸盐测定 N-（1-萘基）-乙二胺光度法：GB/T 13580.7—1992［S］. 北京：中国标准出版社，1992.
[29]	Ministry of Environmental Protection. Water quality-determination of ammonia nitrogen-Nessler's reagent spectrophotometry：HJ 535—2009［S］. Beijing：China Environmental Science Press，2009. 环境保护部. 水质氨氮的测定纳氏试剂分光光度法：HJ 535—2009［S］. 北京：中国环境科学出版社，2009.
[30]	Ministry of Environmental Protection. Water quality-Determination of total nitrogen-Alkaline potassium persulfate digestion UV spectrophotometric method：HJ 636—2012［S］. Beijing：China Environmental Science Press，2012. 环境保护部. 水质总氮的测定碱性过硫酸钾消解紫外分光光度法：HJ 636—2012［S］. 北京：中国环境科学出版社，2012.
[31]	State Environmental Protection Administration. Water quality-Determination of the chemical oxygen demand-Fast digestion-Spectrophotometric method：HJ/T 399—2007［S］. Beijing：China Environmental Science Press，2007. 国家环境保护总局. 水质化学需氧量的测定快速消解分光光度法：HJ/T 399—2007［S］. 北京：中国环境科学出版社，2007.
[32]	KONDAVEETI S，KANG E，LIU H，et al. Continuous autotrophic denitrification process for treating ammonium-rich leachate wastewater in bioelectrochemical denitrification system（BEDS）［J］. Bioelectrochemistry，2019，130：107340.
[33]	WANG Z Q. Mechanism of EAM-MFC biocathode denitrification and performance optimization of SND nitrogen removal［D］. Tianjin：Tiangong University，2019. 王珍琼. EAM-MFC生物阴极反硝化机理及SND脱氮性能优化研究［D］. 天津：天津工业大学，2019.
[34]	LING F，LU Y，WANG C，et al. Electron transfer pathways and kinetic analysis of cathodic simultaneous nitrification and denitrification process in microbial fuel cell system［J］. Environmental Research，2020，186：109505.
[35]	ZHU L Y. Nickel cathode self-activation to promote nitrate reduction to ammonia in wastewater：from fundamental research to pilot test［D］. Guangzhou：South China University of Technology，2021. 朱柳依. 镍阴极自活化促进废水中硝酸盐还原至氨：从基础研究到中试试验［D］. 广州：华南理工大学，2021.
[36]	XIE M，DAI F，GUO H，et al. Improving electrocatalytic nitrogen reduction selectivity and yield by suppressing hydrogen evolution reaction via electronic metal-support interaction［J］. Advanced Energy Materials，2023，13（21）：2203032.
[37]	MAGAR H S，HASSAN R Y A，MULCHANDANI A. Electrochemical impedance spectroscopy（EIS）：principles，construction，and biosensing applications［J］. Sensors，2021，21（19）：6578.
[38]	LIANG P，DUAN R，JIANG Y，et al. One-year operation of 1000-L modularized microbial fuel cell for municipal wastewater treatment［J］. Water Research，2018，141：1- 8.
[39]	WANG X P. Enhanced wastewater denitrification by exogenous Fe²⁺ cooperating with nitrate-dependent anaerobic Iron oxidizing bacteria［D］. Hefei：Anhui Jianzhu University，2019. 王先鹏. 外加Fe²⁺协同硝酸盐型厌氧铁氧化菌促进废水反硝化脱氮研究［D］. 合肥：安徽建筑大学，2019.
[40]	HOOVER R L，KEFFER J L，POLSON S W，et al. Gallionellaceae pangenomic analysis reveals insight into phylogeny，metabolic flexibility，and iron oxidation mechanisms［J］. mSystems，2023，8（6）：e0003823.
[41]	ZHOU X，ZHANG Y，SUN C Y，et al. Autotrophic denitrification process using FeS by thiobacillus denitrificans［J］. Journal of Dalian University of Technology，2019，59（5）：455- 461. 周翔，张玉，孙超越，等. 脱氮硫杆菌利用FeS自养反硝化过程研究［J］. 大连理工大学学报，2019，59（5）：455- 461.
[42]	CHEN C，HU Y，XIE L. The treatment of black odorous water in the river with iron-carbon microelectrolysis coupled with Vallisneria natans［J］. Journal of South China Normal University（Natural Science Edition），2019，51（4）：39- 46.
[43]	ZHOU L，LAI Y，SHAO Z，et al. Keystone bacteria in a thiosulfate-driven autotrophic denitrification microbial community［J］. Chemical Engineering Journal，2023，470：144321.
