改良型Bardenpho工艺在污水处理厂中的设计与运行效果

林莉峰; 王珑; 蒋路漫

doi:10.13205/j.hjgc.202604012

改良型Bardenpho工艺在污水处理厂中的设计与运行效果

doi: 10.13205/j.hjgc.202604012

1. 上海市政工程设计研究总院(集团)有限公司, 上海 200092;
2. 上海电力大学环境与化学工程学院, 上海 200090

基金项目:

上海市住建委科研项目（沪建科2023-002-030）

详细信息

作者简介:
林莉峰(1981—),男,高级工程师,硕士,主要从事污水、污泥处理方向相关研究。linlifeng@smedi.com

通讯作者:
蒋路漫(1985—),女,副教授,博士研究生,主要从事污水处理与资源化技术研究。jiangluman@shiep.edu.cn

计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-09-12
- 网络出版日期: 2026-06-06
- 刊出日期: 2026-04-01

Design and operational performance of a modified Bardenpho process in a wastewater treatment plant

1. Shanghai Municipal Engineering Design and Research Institute (Group) Co., Ltd., Shanghai 200092, China;
2. School of Environmental and Chemical Engineering, Shanghai University of Electric Power, Shanghai 200090, China

摘要

摘要: 某新建污水处理厂设计日处理规模为10万m³/d，进水约含工业废水15%，导致水质水量波动系数达1.2~1.5，难降解有机物（以COD计）占比>35%以及TN浓度高达55 mg/L。为保证出水稳定达标并提升系统的抗冲击能力，工程采用改良型Bardenpho工艺，结合“多点进水+后缺氧+后好氧”工艺构型，并配套事故调节池、高效沉淀池及反硝化深床滤池等深度处理单元，以强化脱氮除磷效果和系统灵活性。在调试运行期间，该工艺表现出优异的污染物去除性能：COD、NH₃-N、TN和TP的平均去除率分别达到96.10%、98.24%、83.89%和98.29%，出水浓度稳定在15.4，0.57，7.94，0.12 mg/L，明显优于GB 18918—2002《城镇污水处理厂污染物排放标准》一级A标准。结果表明，改良型Bardenpho工艺在处理高氮、难降解有机物污水方面具有较强的适应性和稳定性，可有效提升碳源利用效率并降低运行能耗。试验设计参数和运行经验可为类似地区城镇污水厂，尤其是处理含一定比例工业废水的实际工程提供有价值的参考。
- 污水处理厂 /
- 改良型Bardenpho工艺 /
- 工业废水 /
- 脱氮除磷 /
- 运行效果
Abstract: The design daily treatment capacity of the newly built sewage treatment plant is 100000 m³/d. The inflow contains about 15% industrial wastewater， resulting in fluctuation coefficients in both water quality and quantity ranging from 1.2 to 1.5， with a proportion of difficulty degrading organic matter （measured as COD） greater than 35%， and a TN concentration of up to 55 mg/L. To ensure stable effluent quality and enhance the system’s resistance to shock loads， a modified Bardenpho process was adopted. This process integrates multi-point influent distribution and an additional post-anoxic and post-aerobic configuration， in combination with auxiliary units such as an equalization basin， a high-efficiency sedimentation tank， and a denitrifying deep-bed filter. These design features collectively aim to strengthen nitrogen and phosphorus removal efficiency as well as operational flexibility. During the commissioning and operational period， the process demonstrated excellent pollutant removal performance： the average removal efficiencies of COD， NH₃-N， TN， and TP were 96.10%， 98.24%， 83.89%， and 98.29%， respectively. The corresponding effluent concentrations stabilized at 15.4 mg/L， 0.57 mg/L， 7.94 mg/L， and 0.12 mg/L， all of which consistently outperformed the Class 1A standard specified in the Discharge Standard of Pollutants for Municipal Wastewater Treatment Plants （GB 18918—2002）. These findings confirm that the modified Bardenpho process is highly effective in treating wastewater with high nitrogen loads and refractory organic components， showing strong adaptability and system stability. Moreover， its configuration enhances carbon source utilization efficiency while reducing operational energy consumption. The design parameters and operational experiences from this project can serve as practical references for the planning， design， and optimization of large-scale municipal wastewater treatment plants， particularly those receiving a significant fraction of industrial wastewater.
- wastewater treatment plant /
- modified Bardenpho process /
- industrial wastewater /
- nitrogen and phosphorus removal /
- operational performance

HTML全文

参考文献(19)

[1]	LIU J W，MA W L，HUANG L H. Performance of biofilter for odor treatment and the influence factors in municipal wastewater treatment［J］. Environmental Pollution& Control. 2010，32（12）：4- 8. 刘建伟，马文林，黄力华. 城市污水处理厂除臭生物滤池运行效果及影响因素研究［J］. 环境污染与防治，2010，32（12）：4- 8.
[2]	WANG R，XIA W H，LAI C S. Four-stage Bardenpho/MBBR-O₃ for the design of upgrading and reconstruction in wastewater treatment plant［J］. Water& Wastewater Engineering. 2021，57（S2）：175- 178. 王瑞，夏文辉，赖参森. 四段Bardenpho/MBBR-O₃在污水处理厂提标改造中的工程设计［J］. 给水排水，2021，57（S2）：175- 178.
[3]	BAO R B，LIU S，XU J，et al. Experimental study on the optimization of modified bardenpho process based on multipoint inflow distribution and micro oxygen control［J］. Technology of Water Treatment. 2024，50（8）：115- 121. 鲍任兵，刘赛，徐健，等. 基于多点进水和微氧控制的改良Bardenpho工艺优化试验研究［J］. 水处理技术，2024，50（8）：115- 121.
[4]	CHEN Y S，ZHAO Z. Diagnosis of nitrogen removal in modified A₂/O+A/O process and its optimization strategy［J］. China Water& Wastewater. 2022，38（21）：64- 71. 陈亚松，赵铮. 改良型A2/O+A/O工艺的脱氮诊断和优化调控策略［J］. 中国给水排水，2022，38（21）：64- 71.
[5]	YANG H J，MA X L，LI Y H，et al. Design and operation of bardenpho process in a wastewater treatment plant in an industrial park［J］. China Water& Wastewater. 2024，40（18）：80- 84. 杨海娇，马晓龙，李雨航，等. 某工业园区污水处理厂Bardenpho工艺设计与运行［J］. 中国给水排水，2024，40（18）：80- 84.
[6]	WANG K，ZHOU C T，ZHOU H，et al. Comparison on biological nutrient removal and microbial community between full-scale anaerobic/anoxic/aerobic process and its upgrading processes［J］. Bioresource Technology，2023，374：128757.
[7]	SHI H C，WANG Q W，ZHANG M K，et al. Precise aeration for the energy conservation and carbon reduction of wastewater treatment plant：optimization algorithm and control strategy［J］. China Water& Wastewater. 2024，40（20）：1- 6. 施汉昌，汪秋婉，张明凯，等. 精确曝气实现污水处理厂节能减排：计算方法与控制策略［J］. 中国给水排水，2024，40（20）：1- 6.
[8]	ZHANG L C，WEN Y K，DENG J W，et al. Research and development of precise sludge discharge control system for flocculation sedimentation in waterworks［J］. China Water& Wastewater，2023，39（22）：98- 104. 张良纯，文玉坤，邓家伟，等. 水厂絮凝沉淀池精准排泥控制系统的研发［J］. 中国给水排水，2023，39（22）：98- 104.
[9]	CHEN J F，LIU F Q，YAO H Z，et al. Treatment of antibiotic pharmaceutical wastewater by A2O+biofilter+flocculation and sedimentation process［J］. Industrial Water Treatment. 2014，34（5）：21- 24. 陈建发，刘福权，姚红照，等.“A²O+生物滤池+絮凝沉淀”法处理抗生素类制药废水［J］. 工业水处理，2014，34（5）：21- 24.
[10]	ASHRAFI E，ARJOMAND MEHRABANI Z，BORGHEI S M，et al. Optimising nutrient removal of a hybrid five-stage Bardenpho and moving bed biofilm reactor process using response surface methodology［J］. Journal of Environmental Chemical Engineering，2019，7（1）：102861.
[11]	ZHANG J L，REN Y，LUO C，et al. Treatment of comprehensive printing and dyeing wastewater using a combined process of coagulation-AO/AO-denitrification-magnetic coagulation-three phase catalytic oxidation［J］. Water& Wastewater Engineering. 2025，61（2）：83- 86. 张建良，任烨，罗灿，等. 混凝-两段式AO生化-反硝化-磁混凝-三相催化氧化组合工艺处理综合印染废水［J］. 给水排水，2025，61（2）：83- 86.
[12]	LI J Z，JIN Y，GUO Y Q，et al. Enhancement of phosphorus removal in a low temperature A²/O process by anaerobic phosphorus release of activated sludge［J］. Water Science and Technology，2013，67（11）：2437- 2443.
[13]	SERAFIM LUISA S，LEMOS PAULO C，Caterina Levantesi，et al. Methods for detection and visualization of intracellular polymers stored by polyphosphate-accumulating microorganisms［J］. Journal of Microbiological Methods，2002，51（1）：1- 18.
[14]	ZHANG H，ZHANG S S，ZHU L，et al. Phosphorus recovery in the alternating aerobic/anaerobic biofilm system：performance and mechanism［J］. Science of the Total Environment，2022，810：152297.
[15]	ZHOU Z，SHEN X L，JIANG L M，et al. Modeling of multimode anaerobic/anoxic/aerobic wastewater treatment process at low temperature for process optimization［J］. Chemical Engineering Journal，2015，281：644- 650.
[16]	GE Z，LI B X，HAN X Y，et al. Research advances of ANAMMOX process for livestock and poultry farming wastewater treatment［J］. Journal of Beijing University of Technology，2025，51（7）：883- 896. 戈拯，李冰鑫，韩晓宇，等. 基于厌氧氨氧化工艺的畜禽养殖废水处理技术研究进展［J］. 北京工业大学学报，2025，51（7）：883- 896.
[17]	ZHANG W S，WANG L Q，MA Q Y，et al. Design and operation effect of Yindingzhuang WWTP upgrading and reconstruction project［J］. China Water& Wastewater，2019，35（16）：82- 85. 张文生，王立群，马秋莹，等. 银定庄污水处理厂提标改造工程设计及运行效果［J］. 中国给水排水，2019，35（16）：82- 85.
[18]	ZHU D Y，SHI E Y，WANG W N. Application of bardenpho+MBR+ozone catalytic oxidation process in liquid egg processing wastewater［J］. Industrial Water Treatment，2023，43（11）：201- 207. 诸大宇，师恩耀，王文娜. Bardenpho+MBR+臭氧催化氧化工艺在液蛋加工废水中的应用［J］. 工业水处理，2023，43（11）：201- 207.
[19]	CUI T H，CHENG J，YANG K. Design of a wastewater treatment plant expanded and reconstructed from CASS process to Bardenpho process without shutdown［J］. China Water& Wastewater，2023，39（12）：85- 89. 崔天怀，程军，杨坤. 污水厂CASS工艺改为Bardenpho工艺不停水扩容改造［J］. 中国给水排水，2023，39（12）：85- 89.
