基于地表水-地下水耦合模型的大型集水廊道水位动态模拟研究

杨州航; 郝龙; 崔勇; 张恩泽

doi:10.13205/j.hjgc.202605012

基于地表水-地下水耦合模型的大型集水廊道水位动态模拟研究

doi: 10.13205/j.hjgc.202605012

杨州航¹,
郝龙²,
崔勇³,
张恩泽^1, ,

1. 北京工业大学建筑工程学院, 北京 100124;
2. 中铁二十局集团第六工程有限公司, 西安 710032;
3. 河北省水利水电勘测设计研究院集团有限公司, 天津 300220

基金项目:

中铁二十局集团有限公司科研计划项目（YF2306SL19B）

详细信息

作者简介:
杨州航(2000—),男,硕士研究生,主要从事地下水、地表水交互研究。yzh625839@emails.bjut.edu.cn

通讯作者:
张恩泽(1990—),男,助理研究员,主要研究方向为水文水资源。zhangenze@bjut.edu.cn

计量
- 文章访问数: 1
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2026-01-01
- 网络出版日期: 2026-06-06

Dynamic simulation of water level in large-scale infiltration galleries using a surface water-groundwater coupled model

1. College of Architecture and Civil Engineering, Beijing University of Technology, Beijing 100124, China;
2. China Railway 20th Bureau Group Sixth Engineering Co., Ltd., Xi'an 710032, China;
3. Hebei Hydroelectric Investigation, Design and Research Institute Group Co., Ltd., Tianjin 300220, China

摘要

摘要: 大型集水廊道的取水过程会诱发地表水-地下水交换关系的显著演变。然而，现有模型多将廊道作边界简化或松散耦合处理，受限于迭代交换算法，往往无法精确刻画系统间的水量动态交互与瞬态响应。为此，以石家庄大型河床渗滤取水与净水工程为对象，利用HydroGeoSphere的双节点耦合方法，建立了包含地表水、地下水及集水廊道的三域一体化全耦合数值模型。模型分别设置丰水期与枯水期2种上游来水情景，并分别模拟单泵抽水（1000 m³/h）和不抽水2种工况下区域地下水水位演化特征及各域间水量交换过程。模拟结果表明：在抽水条件下，地下水水位整体呈现明显下降，其中，枯水期响应最为显著，最大水位降深约为1.24 m；廊道附近观测井对抽水的水位响应明显提前，其达到最大水位下降速率的时间较远离廊道区域观测井提前2～3 d。进一步分析各情景达到水量平衡后的交换特征发现，各域间水量交换存在显著差异：总体上，丰水期地表水对地下水的补给量高于枯水期，且在抽水条件下，集水廊道与地下水之间的水量交互显著增强。水量交换空间分布主要集中于横向与纵向廊道区域，这与廊道开孔结构对周围地层渗透条件的影响特征相一致。研究结果揭示了大型集水廊道运行条件下地下水动态变化及地表水-地下水-廊道之间的交互规律，可为类似河床渗滤取水工程的规划设计与运行管理提供理论参考。
- 集水廊道 /
- 地表水-地下水交换 /
- 双节点耦合 /
- 数值模型 /
- 渗滤取水
Abstract: The water extraction process of large-scale infiltration galleries can significantly alter the exchange dynamics between surface water and groundwater. However， the existing models often simplify the gallery as a boundary condition or adopt a loosely coupling schemes， and are typically constrained by iterative exchange algorithms， which often fail to accurately capture the dynamic water flux interactions and transient responses among system components. To address this limitation， this study focused on the large riverbed infiltration and purification water supply project in Shijiazhuang， China， and established an integrated three-domain fully coupled numerical model—encompassing surface water， groundwater， and the infiltration gallery—using the dual-node coupling approach in HydroGeoSphere. The model set two upstream inflow scenarios （wet season and dry season conditions） and simulated the characteristics of regional groundwater level evolution and the water exchange processes among various domains under two operational modes： single-pump extraction at 1000 m³/h and no pumping. Simulation results showed that groundwater levels declined markedly under pumping， with the most pronounced response occurring during the dry season， where the maximum drawdown reached approximately 1.24 m. Monitoring wells near the gallery showed an obviously earlier hydraulic response to pumping， reaching peak drawdown rates about 2 to 3 days sooner than wells located farther away. Further analysis of water exchange characteristics at steady-state balance revealed significant differences across scenarios： overall， surface water contributed more recharge to groundwater during the wet season than in the dry season， and the water exchange between the infiltration gallery and the aquifer was substantially enhanced under pumping conditions. Spatially， the water exchange was concentrated primarily around the transverse and longitudinal gallery sections， consistent with the localized enhancement of permeability induced by the perforated structure of the gallery. These findings revealed the groundwater dynamics and multi-domain interaction mechanisms under operational conditions of large-scale infiltration galleries， providing a theoretical basis for the planning， design， and sustainable operation of similar riverbed infiltration water supply systems.
- infiltration gallery /
- surface water-groundwater exchange /
- dual-node coupling /
- numerical model /
- infiltration water extraction

HTML全文

参考文献(25)

[1]	YAN X S，GAO N Y. Water supply engineering［M］. 5th. edition. Beijing：China Architecture & Building Press，2022. 严煦世，高乃云. 给水工程［M］. 5版. 北京：中国建筑工业出版社，2022.
[2]	BEKELE E，TOZE S，PATTERSON B，et al. Evaluating two infiltration gallery designs for managed aquifer recharge using secondary treated wastewater［J］. Journal of Environmental Management，2013，117：115- 120.
[3]	DUBUIS R，de CESARE G. The clogging of riverbeds:A review of the physical processes［J］. Earth-Science Reviews，2023，239：104374.
[4]	LIU H Q，WANG T T，FENG Y，et al. Impact assessment of climate change and reservoir operation on hydrological regime in the Yangtze River Basin［J］. Acta Geographica Sinica，2025，80（1）：41- 60. 刘罕奇，王婷婷，冯瑶，等. 气候变化和水库运行对长江流域水文情势的影响预估［J］. 地理学报，2025，80（1）：41- 60.
[5]	KUSUMA M N，HADI W，WIRJODIRDJO B. Preliminary study of infiltration gallery for water treatment towards Universal Access 2019 in Indonesia［J］. Soil & Environment，2018，37（1）：83- 88.
[6]	ZHANG H，SUN B W，GAO X P，et al. Study on numerical simulation strategy of vertical pipe intake/outlet［J］. Journal of Hydroelectric Engineering，2019，38（12）：28- 39. 张翰，孙博闻，高学平，等. 竖井式进/出水口数值模拟策略研究［J］. 水力发电学报，2019，38（12）：28- 39.
[7]	ANDERSON E I. Yield equations for bed-mounted infiltration galleries［J］. Journal of Irrigation and Drainage Engineering，2023，149（10）：06023003.
[8]	LUO Z Y. Establishment and application of numerical model calibration method for groundwater flow near infiltration gallery：a case study of Lin-Bien River［D］. Taipei：Taiwan University，2015. 罗振优. 集水廊道附近地下水流数值模式率定方法建立与应用：以林边溪为例［D］. 台北：台湾大学，2015.
[9]	ROY D K，LESLIE D L，REBA M L，et al. Optimizing the quantity of recharge water into a sedimentary aquifer through infiltration galleries using a surrogate assisted coupled simulation-optimization approach［J］. Journal of Hydrology，2024，635：131183.
[10]	BRUNNER P，SIMMONS C T. HydroGeoSphere：a fully integrated，physically based hydrological model［J］. Ground Water，2012，50（2）：170- 176.
[11]	YANG X Q，RU Z Y，LI Q F，et al. Dynamic of groundwater level and spatiotemporal analysis of suitable groundwater level in the large Hetao Irrigation District based on MODFLOW［J/OL］. Water Resources Protection，1- 13［ 2026-03-17］. https://link.cnki.net/urlid/32.1356.TV.20260224.1610.016. 杨小强，茹泽宇，李琼芳，等. 基于MODFLOW的特大型河套灌区地下水水位动态及适宜地下水位时空分析［J/OL］. 水资源保护，1- 13［ 2026-03-17］. https://link.cnki.net/urlid/32.1356.TV.20260224.1610.016.
[12]	JING M C. Application of water intake method of collecting gallery in rural safe drinking water project［J］. China Water Transport，2015，15（16）：212- 213，216. 经敏川. 集水廊道取水方式在农村安全饮水工程中的应用［J］. 中国水运，2015，15（16）：212- 213，216.
[13]	DONG N，TIAN A M，JIANG F，et al. Study on comprehensive evaluation of water resources based on sustainable development［J］. Environmental Engineering，2010，28（S1）：444- 447. 董宁，田爱民，姜丰，等. 基于可持续发展的水资源综合评价研究［J］. 环境工程，2010，28（增刊1）：444- 447.
[14]	FAN X Q，GUO G L，SUN H G，et al. Experimental verification and analysis of fractal Richards model for horizontal movement of unsaturated soil moisture［J］. Environmental Engineering，2019，37（12）：212- 217. 樊祥旗，郭观林，孙洪广，等. 非饱和土壤水分水平运动分形Richards模型的实验验证和分析［J］. 环境工程，2019，37（12）：212- 217.
[15]	STOKKE J S，MITRA K，STORVIK E，et al. An adaptive solution strategy for Richards' equation［J］. Computers & Mathematics with Applications，2023，152：155- 167.
[16]	PONCE V M，SIMONS D B. Shallow wave propagation in open channel flow［J］. Journal of the Hydraulics Division，1977，103（12）：1461- 1476.
[17]	YARAHMADI M B，PARSAIE A，SHAFAI-BEJESTAN M，et al. Estimation of manning roughness coefficient in alluvial rivers with bed forms using soft computing models［J］. Water Resources Management，2023，37（9）：3563- 3584.
[18]	YAN X，NIU C W，JIA Y W，et al. Ecosystem service value of Fenhe River based on Manning formula［J］. South-to-North Water Transfers and Water Science & Technology，2024，22（5）：927- 936. 燕翔，牛存稳，贾仰文，等. 基于曼宁公式的汾河生态系统服务价值研究［J］. 南水北调与水利科技，2024，22（5）：927- 936.
[19]	HUANG Y H，ZHOU X Q，ZHOU W T，et al. Study on the applicability of Manning formula to flow in rough wall open channel［J］. Journal of Sediment Research，2023，48（3）：22- 29. 黄宇航，周晓泉，周文桐，等. 曼宁公式在粗糙壁面明渠流的适用性研究［J］. 泥沙研究，2023，48（3）：22- 29.
[20]	FIORILLO F，ESPOSITO L，GINOLFI M，et al. New insights into turbulent and laminar flow relationships using darcy-weisbach and poiseuille laws［J］. Water，2024，16（10）：1452.
[21]	LIU Q，NI Y F，CAO Z X. One-dimensional hydrodynamic modelling of river floods with severe infiltration［J］. Engineering Journal of Wuhan University，2019，52（6）：471- 481. 刘晴，倪玉芳，曹志先. 考虑下渗的一维河道水流数学模型［J］. 武汉大学学报（工学版），2019，52（6）：471- 481.
[22]	SCHMID P J，HENNINGSON D S. Optimal energy density growth in Hagen-Poiseuille flow［J］. Journal of Fluid Mechanics，1994，277：197- 225.
[23]	ZHANG M L，SU X H，WU Z Q，et al. Numerical analysis of seepage field of Daigusi concrete face rockfill dam by finite volume method［J］. Hydro-Science and Engineering，2023（6）：205- 212. 张明亮，宿晓辉，吴正桥，等. 代古寺面板堆石坝渗流场有限体积法数值分析［J］. 水利水运工程学报，2023（6）：205- 212.
[24]	MCCUEN R H，KNIGHT Z，CUTTER A G. Evaluation of the nash-sutcliffe efficiency index［J］. Journal of Hydrologic Engineering，2006，11（6）：597- 602.
[25]	JAFARZADEH A，KHASHEI-SIUKI A，POURREZA-BILONDI M. Performance assessment of model averaging techniques to reduce structural uncertainty of groundwater modeling［J］. Water Resources Management，2022，36（1）：353- 377.
