城市再生水厂碳排放平衡模型构建及碳中和路径分析

庞洪涛; 侯锋; 朱柯; 张璐晶; 李朋; 江乐勇; 孙事昊

doi:10.13205/j.hjgc.202606005

城市再生水厂碳排放平衡模型构建及碳中和路径分析

doi: 10.13205/j.hjgc.202606005

信开环境投资集团有限公司, 北京 101101

基金项目:

国家重点研发计划“多目标城市污水资源化核心工艺与模式”（2022YFC3203103）

详细信息

作者简介:
庞洪涛,男,博士,教授级高工,主要研究方向为城镇水污染控制与治理。panghongtao@sdic.com.cn

通讯作者:
朱柯,男,博士,主要研究方向为城镇污水处理厂余温热能高效利用、热泵技术优化及双碳研究。zhukebj0306@163.com

计量
- 文章访问数: 15
- HTML全文浏览量: 1
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-08-16
- 录用日期: 2025-09-23
- 修回日期: 2025-09-12
- 网络出版日期: 2026-07-06

Establishment of a carbon emission balance model and analysis of carbon neutrality pathways for urban reclaimed water plants

Xinkai Environment Investment Group Co., Ltd., Beijing 101101, China

摘要

摘要: “双碳”背景下，采取节能降耗、资源、能源利用等措施是城市再生水厂实现“碳中和”的必然路径。鉴于此，研究以降碳、替碳、碳汇的方式，构建城市再生水厂碳排放平衡模型及核算方法，并结合碳排放平衡率评估城市再生水厂“碳中和”的最优路径。选用10万t/d城市再生厂为范例进行模型实用性验证，结果显示：厂区碳排放总量20934 t，再生水源热泵供暖/制冷的碳减排总量为21701 t，碳排放平衡率为103.7%；其他形式的碳减排总量为15424 t，碳排放平衡率为73.7%，再生水源热泵是实现碳中和的关键环节。再生水源热泵若提取27%、36%余温热能，分别耦合再生水回用或污泥厌氧消化-热电联产，这2种路径均能达到 100%的碳排放平衡率。假设再生水源热泵全年不间断提取余温热能，碳排放平衡率为213%，对比污泥厌氧消化-热电联产，利用余温热能与化学能的碳减排比为8.76∶1。研究表明，城市再生水厂可通过以上多种途径实现“碳中和”，其中余温热能回收具有巨大潜力。
- 城市再生水厂 /
- 再生水源热泵 /
- 碳排放平衡 /
- 碳中和 /
- 再生水
Abstract: In the context of carbon peaking and carbon neutrality， it is imperative that urban reclaimed water plants achieve carbon neutrality through measures such as energy conservation， consumption reduction， and enhanced resource and energy utilization. In view of this， this study developed a carbon emission balance model and an accounting method for such plants， incorporating strategies of carbon emission reduction， carbon substitution， and carbon sink. Additionally， the optimal pathway towards carbon neutrality was further evaluated based on the carbon emission balance ratio. To validate the practicality of the model， urban reclaimed water plants （1×10⁵ m³/d） were selected as case studies. The results indicated that their total carbon emissions amounted to 20934 t CO₂e， while the total carbon emission reduction from the reclaimed water source heat pumps for heating and cooling was 21701 t CO₂e， resulting in a carbon emission balance ratio of 103.7%. In contrast， other carbon emission reduction measures contributed a total reduction of 15424 t CO₂e， with a carbon emission balance ratio of 73.7%. These findings highlighted that reclaimed water source heat pumps played a pivotal role in achieving carbon neutrality. When the reclaimed water source heat pump extracted 27% and 36% of residual thermal energy and was respectively coupled with reclaimed water reuse or sludge anaerobic digestion-cogeneration systems， both pathways achieved a 100% carbon emission balance ratio. Assuming continuous year-round extraction of residual thermal energy by the pump， a ratio of 213% was achieved. Compared to sludge anaerobic digestion-cogeneration， the carbon emission reduction ratio between utilizing residual thermal energy and chemical energy was 8.76：1. This study demonstrates that urban reclaimed water plants can achieve carbon neutrality through the above multiple pathways， among which the recovery of residual thermal energy exhibits significant potential.
- urban reclaimed water plant /
- reclaimed water source heat pump /
- carbon emission balance /
- carbon neutrality /
- reclaimed water

HTML全文

参考文献(29)

[1]	WANG Q H. Research on carbon emission accounting of new concept sewage treatment plant：Take Suixian No.3 Sewage Treatment Plant as an example[D]. Beijing：North China University of Water Resources and Electric Power，2022. 王庆会. 新概念污水处理厂碳排放量核算研究：以睢县第三污水处理厂为例[D]. 北京：华北水利水电大学，2022.
[2]	Ministry of Housing and Urban-Rural Development of the People's Republic of China. 2022 urban and rural construction statistical yearbook[M]. Beijing：China Statistics Press，2022. 中华人民共和国住房和城乡建设部. 2022 年城乡建设统计年鉴[M]. 北京：中国统计出版社，2022.
[3]	MO W W，ZHANG Q. Can municipal wastewater treatment systems be carbon neutral[J]. Journal of Environmental Management，2012，112：360-367.
[4]	HAO X D，CHENG H Q，HU Y S. International pioneer of carbon-neutral operation of wastewater treatment：a case study at Strass in Austria[J]. China Water& Wastewater，2014，30（22）：1-5. 郝晓地，程慧芹，胡沅胜. 碳中和运行的国际先驱奥地利 Strass 污水处理厂案例剖析[J]. 中国给水排水，2014，30（22）：1-5.
[5]	HAO X D，WEI J，CAO Y L. A successful case of carbon-neutral operation in America：Sheboygan WWTP[J]. China Water& Wastewater，2014，30（24）：1-6. 郝晓地，魏静，曹亚莉. 美国碳中和运行成功案例：Sheboygan 污水处理厂[J]. 中国给水排水，2014，30（24）：1-6.
[6]	JARKKO L. Circular Economy：Tapping the Power of Wastewater[EB/OL].（2021-06-01）. https：//iwa-network.org/learn/circular-economy-tapping-the-power-of-wastewater/.
[7]	LÜ L P，LI H，LI W，et al. Practice approach and application progress of carbon neutrality in wastewater treatment plant[J]. Industrial Water Treatment，2022，42（11）：1-6. 吕利平，李航，李伟，等. 碳中和在污水处理厂的实践途径与应用进展[J]. 工业水处理，2022，42（11）：1-6.
[8]	HAO X D，FANG X M，LI J，et al. Analysis of potential in carbon-neutral operation of WWTPs[J]. China Water& Wastewater，2018，34（10）：11-16. 郝晓地，方晓敏，李季，等. 污水碳中和运行潜能分析[J]. 中国给水排水，2018，34（10）：11-16.
[9]	HAO X D，LI J，et al. Energy recovery from wastewater：Heat over organics[J]. Water Research，2016，161：74-77.
[10]	BAO Z Y. Study on characteristics and mitigation strategies of greenhouse gas emissions from typical domestic wastewater treatment processes[D]. Beijing：Beijing Forestry University，2019. 鲍志远. 典型城市污水处理工艺温室气体排放特征及减排策略研究[D]. 北京：北京林业大学，2019.
[11]	YANG L B，ZENG S Y，CHEN J N，et al. Operational energy performance assessment system of municipal wastewater treatment plants[J]. Water Science and Technology，2010，62（6）：1-10.
[12]	China Urban Water Association. Guidelines for cabon accounting and emission reduction in the urban water sector[M]. Beijing：China Architecture& Building Press，2022. 中国城镇供水排水协会. 城镇水务系统碳核算与减排路径技术指南[M]. 北京：中国建筑工业出版社，2022.
[13]	LI J. Research of accounting the carbon emissions of urban water system：an analysis of Changzhou[D]. Nanjing：Nanjing University，2011. 李健. 城市水系统碳排放量核算研究：以常州市为例[D]. 南京：南京大学，2011.
[14]	HAO X D，RAO Z F，LI S，et al. Potential carbon trading volume of thermal energy contained in wastewater[J]. China Water& Wastewater，2021，37（12）：7-13. 郝晓地，饶志峰，李爽，等. 污水余温热能蕴含着潜在碳交易额[J]. 中国给水排水，2021，37（12）：7-13.
[15]	LIN W C，ZHAO G，LIU W，et al. Study on carbon emission accounting for typical processes of sewage sludge treatment and disposal[J]. Environmental Engineering，2017，35（7）：175-179. 林文聪，赵刚，刘伟，等. 污水厂污泥典型处理处置工艺碳排放核算研究[J]. 环境工程，2017，35（7）：175-179.
[16]	WANG L，LI D B，LIU Z W，et al. Carbon emission analysis of sludge treatment and disposal pathways[J]. China Environmental Science，2022，42（5）：2404-2412. 王琳，李德彬，刘子为，等. 污泥处理处置路径碳排放分析[J]. 中国环境科学，2022，42（5）：2404-2412.
[17]	ZHANG K H. Application of distributed photovoltaic power generation system in a wastewater treatment plant[J]. China Water& Wastewater，2017，33（22）：81-84. 张开海. 分布式光伏发电系统在某污水处理厂中的应用[J]. 中国给水排水，2017，33（22）：81-84.
[18]	ZHANG Q Y，LV W Y，XU B Q. Study on the calculation of carbon sequestration capacity of urban green space in north China[J]. Environmental Protection Science，2021，47（1）：41-48. 张青云，吕伟娅，徐炳乾. 华北地区城市绿地固碳能力测算研究[J]. 环境保护科学，2021，47（1）：41-48.
[19]	Intergovernmental Panel on Climate Change. 2019 refinement to the 2016 IPCC guidenlines for national greenhouse gas inventories[EB/OL].
[20]	中国环境保护产业协会. 污水处理厂低碳运行评价技术规范：T/CAEPI 49—2022[S]. 北京：中国环境保护产业协会，2022. China Environmental Protection Industry Association. Technical specifications for low-carbon operation evaluation of sewage treatment plant：T/CAEPI 49—2022[S]. Beijing：China Environmental Protection Industry Association，2022.
[21]	天津市市场监督管理委员会. 地源热泵系统节能减排绩效评价方法：DB12/T 905—2019[S]. 天津：天津市市场监督管理委员会，2019. Tianjin Municipal Market Supervision and Administration Commission. Energy saving and emission reduction performance evaluation method for ground source heat pump systems：DB12/T 905—2019[S]. Tianjin：Tianjin Municipal Market Supervision and Administration Commission，2019.
[22]	Department of Ecology and Environment of Hebei Province. Methodology of Carbon Reduction Products for Ground Source Heat Pump Projects in Hebei Province[S]. 2023. 河北省生态环境厅. 河北省地源热泵项目降碳产品方法学[S]. 2023.
[23]	LI Z K，ZHANG L Q，DU Z W，et al. Comparison of carbon emissions in different treatment and disposal routes of municipal sludge[J]. Environmental Science，2023，44（2）：1181-1190. 李哲坤，张立秋，杜子文，等. 城市污泥不同处理处置工艺路线碳排放比较[J]. 环境科学，2023，44（2）：1181-1190.
[24]	ZHANG H. Research on PV energy potential of rooftop in urban area[D]. Tianjin：Tianjin University，2017. 张华. 城市建筑屋顶光伏利用潜力评估研究[D]. 天津：天津大学，2017.
[25]	Ministry of Ecology and Environment of the People’s Republic of China. Baseline emission factors for regional power grids in China for 2019 emission reduction projects[EB/OL]. 中华人民共和国生态环境部. 2019年度减排项目中国区域电网基准线排放因子[EB/OL].
[26]	DU W J，LU J Y，XIAO J，et al. Spatiotemporal pattern of greenhouse gas emissions in China's wastewater sector and pathways towards carbon neutrality[J]. Nature Water，2023，1（2）：166-175.
[27]	WANG Q，LI J W，WANG Z G，et al. Energy consumption analysis of key equipment in urban sewage treatment plants and research on energy saving and consumption reduction methods[J]. Water Supply and Drainage，2018，54（10）：44-47. 王迁，李江伟，王志刚，等. 城市污水处理厂关键设备能耗分析及节能降耗途径研究[J]. 给水排水，2018，54（10）：44-47.
[28]	ZHANG H Y，LI S Q，LI M Y，et al. Carbon emission analysis of municipal wastewater treatment plants and discussion on synergistic path of pollution and carbon reduction[J]. Journal of Environmental Engineering Technology，2023，13（6）：2053-2062. 张海亚，李思琦，黎明月，等. 城镇污水处理厂碳排放现状及减污降碳协同增效路径探讨[J]. 环境工程技术学报，2023，13（6）：2053-2062.
[29]	HAO X D，LI J，van LOOSDRECHT M C M，et al. Energy recovery from wastewater：Heat over organics[J]. Water Research，2019，161（5）：74-77.
