新型摆动式超细格栅的运行效果及污染机理

程远韬; 张宗胜; 张杰; 吴志超; 藏莉莉

doi:10.13205/j.hjgc.202606020

新型摆动式超细格栅的运行效果及污染机理

doi: 10.13205/j.hjgc.202606020

1. 同济大学环境科学与工程学院, 上海 200092;
2. 上海子征环保科技有限公司, 上海 200086

详细信息

作者简介:
程远韬(2000-),男,硕士研究生,主要研究方向为预处理技术及MBR工艺优化。EnvECheng@163.com

通讯作者:
张杰(1972-),男,博士,主要研究方向为排水系统及水污染治理。91102@tongji.edu.cn

计量
- 文章访问数: 4
- HTML全文浏览量: 1
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-09-10
- 录用日期: 2025-11-26
- 修回日期: 2025-11-19
- 网络出版日期: 2026-07-06

Operational efficiency and fouling mechanism of a novel swinging ultra-fine screen

1. College of Environmental Science and Engineering, Tongji University, Shanghai 200092, China;
2. Shanghai Zizheng Environmental Protection Technology Co., Ltd., Shanghai 200086, China

摘要

摘要: 针对我国城镇污水处理厂普遍存在的进水泥砂量超设计值、碳源不足问题，以及传统预处理工艺（格栅+沉砂池+初沉池）对细微泥砂去除效率低、碳源保留率低等缺陷，开发了一种新型摆动式超细格栅预处理设备。该设备筛分精度达到0.1 mm。在1000 m³/d中试规模下，系统测试了0.05~0.4 mm等不同孔径筛网摆动式超细格栅的污染物去除效能，并通过粒度分析、COD组分划分及污染层表征探究其作用机理。结果表明：0.1 mm摆动式超细格栅对SS去除率达89.3%（传统预处理工艺为57.4%），COD去除率仅为9.5%（传统预处理工艺为28.6%），碳源保留率达93%，可近乎完全截留粒径>0.1 mm的颗粒，对0.075~0.1 mm颗粒的去除率>98%，在COD、SS波动下性能稳定，并提出了微网污染的三阶段理论。0.1 mm摆动式超细格栅首次将筛分精度提高至0.1 mm，显著提升了细微泥砂的截留效率以及有效碳源的保留率，抗水质波动能力强。
- 摆动式超细格栅 /
- 预处理 /
- 细微泥砂截留 /
- 碳源保留 /
- 筛网污染
Abstract: In response to the widespread challenges faced by municipal wastewater treatment plants in China， such as influent grit loads exceeding design standards and insufficient carbon sources， as well as the limitations of conventional pretreatment processes （including screening， grit chambers， and primary sedimentation tanks）—namely， low removal efficiency of fine grit and poor retention of carbon sources—this study developed a novel pretreatment device known as the swinging ultra-fine screen. With a screening precision of 0.1 mm， the system was tested at a pilot scale of 1000 m³/d to systematically evaluate the pollutant removal efficiency of swinging ultra-fine screens with various aperture sizes ranging from 0.05 mm to 0.4 mm. The mechanisms were further investigated through particle size distribution analysis， COD fractionation， and characterization of the fouling layer. The results demonstrated that the swinging ultra-fine screen with a 0.1 mm aperture achieved an SS removal efficiency of 89.3%， significantly higher than the 57.4% obtained with conventional pretreatment processes. Meanwhile， the COD removal efficiency was only 9.5%， much lower than the 28.6% observed in traditional systems， indicating a carbon source retention efficiency as high as 93%. The device almost completely retained particles larger than 0.1 mm and achieved a removal efficiency exceeding 98% for particles in the 0.075 to 0.1 mm range. It also exhibited stable performance under fluctuating COD and SS conditions. Based on the experimental observations， a three-stage fouling theory for micro-screens was proposed. The 0.1 mm swinging ultra-fine screen represents a breakthrough by increasing the screening precision to 0.1 mm for the first time. It significantly enhances the removal efficiency of fine grit and effectively preserves bioavailable carbon sources， while demonstrating strong resilience to variations in water quality.
- swinging ultra-fine screen /
- pretreatment /
- fine grit retention /
- carbon source retention /
- screen fouling

HTML全文

参考文献(33)

[1]	HU C. Characteristics and removal technology of the fine grit in sewer system of mountains urban area[D]. Chongqing：Chongqing University，2012. 胡澄. 山地城市污水中细砂特征及其处理技术研究[D]. 重庆：重庆大学，2012.
[2]	ZHENG X C，SUN Y L，SHANG W，et al. Reflections on functional enhancement and technological equipment development in municipal wastewater treatment[J]. Water and Wastewater Engineering，2011，47（9）：1-5. 郑兴灿，孙永利，尚巍，等. 城镇污水处理功能提升和技术设备发展的几点思考[J]. 给水排水，2011，47（9）：1-5.
[3]	LIN J. The effciency and operational optimization of the high concentration suspended substance removal in sewage treatment[D]. Shenzhen：Harbin Institute of Technology，2013. 林杰. 污水处理中沉砂池去除高浓度悬浮物效能与运行优化[D]. 深圳：哈尔滨工业大学，2013.
[4]	HE Q，WANG Q，HU C，et al. Target particle size of ultra-fine grit removal system of moutainous urban[J]. Journal of Environmental Engineering，2014，8（7）：2653-2657. 何强，王琦，胡澄，等. 山地城市污水特细砂除砂系统目标粒径确定[J]. 环境工程学报，2014，8（7）：2653-2657.
[5]	WANG Y. The effect of fine grit particle size on activated sludge MLVSS/MLSS and prediction research[D]. Chongqing：Chongqing University，2016. 王颖. 细微泥沙粒径对活性污泥MLVSS/MLSS的影响及预测研究[D]. 重庆：重庆大学，2016.
[6]	JIANG N. Grit removal ability evaluation of sewage disposal pretreatment plant and removal technique of fine sediment[D]. Chongqing：Chongqing University，2015. 姜宁. 污水处理厂预处理段除砂能力及细微泥砂强化去除技术[D]. 重庆：重庆大学，2015.
[7]	LI T，CUI C Y，HAO F L，et al. Analysis and optimization of sand removal efficiency of aerated grit chamber[J]. Water and Wastewater Engineering，2017，53（2）：45-48. 李佟，崔春玥，郝凤玲，等. 曝气沉砂池除砂效果分析与优化研究[J]. 给水排水，2017，53（2）：45-48.
[8]	ZHENG X C，ZHANG Y，CHEN L. Chemically-biologically combined flocculation for enhanced primary treatment of wastewater[J]. China Water and Wastewater，2000（7）：29-32. 郑兴灿，张悦，陈立. 化学—生物联合絮凝的污水强化一级处理工艺[J]. 中国给水排水，2000（7）：29-32.
[9]	FU G K. Research on activated sludge process-constructed wetland combinative technology treating municipal wastewater[D]. Shanghai：Tongji University，2007. 付国楷. 活性污泥法—人工湿地联合处理城市污水研究[D]. 上海：同济大学，2007.
[10]	FAN J P. Suspension properties of fine grit with different particle sizes in bioreactors and separation of fine grit from bioreactors[D]. Chongqing：Chongqing University，2016. 范剑平. 生化池不同粒径细微泥沙的悬浮特性及其分离技术[D]，重庆：重庆大学，2016.
[11]	Huber. Huber Technology Homepage[EB/OL].[ 2025-10-31]. https：//www.huber-se.com.
[12]	Ovivo. Ovivo Water Treatment Solutions[EB/OL].[ 2025-10-31]. https：//www.ovivowater.com.
[13]	Andritz. Andritz Separation[EB/OL].[ 2025-10-31]. https：//www.andritz.com/separation-en.
[14]	Environment Ryde. Ryde Environment[EB/OL].[ 2025-10-31]. https：//www.yzruide.com.
[15]	Jindi. Jindi[EB/OL].[ 2025-10-31]. http：//www.wxjindi.cn/en.
[16]	Funcor. Funcor[EB/OL].[ 2025-10-31]. http：//www.jsfunkor.com.
[17]	Filter Salsnes. Products[EB/OL].[ 2025-10-31]. https：//www.salsnes-filter.com.
[18]	International Hydro. Products[EB/OL].[ 2025-10-31]. https：//hydro-int.com.
[19]	METCALF，EDDY. Wastewater engineering：treatment and resource recovery[M]. 5th ed. New York：McGraw-Hill Education，2014.
[20]	国家质检总局. 城镇污水处理厂污染物排放标准：GB 18918—2002[S]. 北京，2002. General Administration of Quality Supervision，Inspection and Quarantine of the People's Republic of China. Discharge standard of pollutants for municipal wastewater treatment plant：GB 18918—2002[S]. Beijing，2002.
[21]	State Environmental Protection Administration of China. Monitoring and analysis methods of water and wastewater[M]. Beijing：China Environmental Science Press，2002. 国家环境保护总局. 水和废水监测分析方法[M]. 北京：中国环境科学出版社，2002.
[22]	TARNACKI K，LYKO S，WINTGENS T，et al. Impact of extra-cellular polymeric substances on the filterability of activated sludge in membrane bioreactors for landfill leachate treatment[J]. Desalination，2005，179（1-3）：181-190.
[23]	WINTERS A L，MINCHIN F R，Modification of the Lowry assay to measure proteins and phenols in covalently bound complexes[J]. Anal Biochem，2005，346（1）：43-48.
[24]	HENZE M，GUJER W，MINO T，et al. Activated sludge models ASM1，ASM2，ASM2d and ASM3[R]. London：IAW Publishing，2000.
[25]	ZHOU Z，WU Z C，WANG Z W，et al. Activated sludge model based COD fractionation in wastewater characterization[J]. Environmental Science，2010，31（6）：1478-1482. 周振，吴志超，王志伟，等. 基于活性污泥模型的污水COD组分划分方案研究[J]. 环境科学，2010，31（6）：1478-1482.
[26]	LU Y Y. Study on intensified removal of fine silt in primary sludge in WWTP[D]. Chongqing：Chongqing University，2018. 路莹莹. 污水厂初沉污泥中细微泥砂的强化去除研究[D]. 重庆：重庆大学，2018.
[27]	REVSBECH N P. An oxygen microsensor with a guard cathode[J]. Limnology and Oceanography，1989，34（2）：474-478.
[28]	中华人民共和国住房和城乡建设部. 室外排水设计标准：GB 50014—2021[S]. 北京：中国计划出版社，2021. Ministry of Housing and Urban-Rural Development of the People’s Republic of China. Standard for design of outdoor wastewater engineering：GB 50014—2021[S]. Beijing：China Planning Press，2021.
[29]	ZHAO Y C，NIU D J，ZHOU T. Treatment and recycling of solid waste[M]. Beijing：Chemical Industry Press，2023. 赵由才，牛冬杰，周涛. 固体废物处理与资源化[M]. 北京：化学工业出版社，2023.
[30]	北京市市政工程设计研究总院有限公司. 给水排水设计手册第五册[M]. 北京：中国建筑工业出版社，2017. Beijing General Municipal Engineering Design& Research Institute Co.，Ltd. Water supply and drainage design manual. volume 5[M]. Beijing：China Architecture& Building Press，2017.
[31]	INC E M. Wastewater engineering：treatment and reuse[M]. McGraw-Hill Science/Engineering/Math，2002.
[32]	AO L G，YANG K，JI X P，et al. Analysis of the reduction characteristics of inorganic sand by the grit chamber-primary sedimentation tank system[J]. Applied Chemical Industry，2025，54（5）：1355-1359，1364. 敖良根，阳康，吉晓鹏，等. 污水厂沉砂-初沉系统对无机砂的削减特征分析[J]. 应用化工，2025，54（5）：1355-1359，1364.
[33]	SUN C，LUX S F，MÜLLER E，et al. Versatile application of a modern scanning electron microscope for materials characterization[J]. Journal of Materials Science，2020（55）：13824-13835.
