高加热速率下多源生物质/气化渣配伍燃料燃烧及排放特性研究

郭胜军; 雷梦莺; 林浩; 姚浩; 李睿; 史兆臣; 李展; 张效攀; 蒲京; 邓双辉; 王学斌

doi:10.13205/j.hjgc.202607004

高加热速率下多源生物质/气化渣配伍燃料燃烧及排放特性研究

doi: 10.13205/j.hjgc.202607004

1. 中科(广东)炼化有限公司, 广东湛江 524000;
2. 西安交通大学能源与动力工程学院, 西安 710049

详细信息

作者简介:
郭胜军（1971—），高级工程师。guoshj.zklh@sinopec.com

通讯作者:
王学斌（1984—），教授，博导。wxb005@mail.xjtu.edu.cn

计量
- 文章访问数: 8
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-11-20
- 网络出版日期: 2026-09-01

Combustion and emission characteristics of multi-source biomass/coal gasification fine slag composite pelletized fuels at high heating rates

1. Zhongke (Guandong) Refinery & Petrochemical Company Limited, Zhanjiang 524000, China;
2. School of Energy and Engineering, Xi'an Jiaotong University, Xi'an 710049, China

摘要

摘要: 压块成型技术常用于生物质和煤炭燃料领域，成型后的燃料具有易于运输和储存、能量密度高的特点。煤气化细渣作为一种含碳量高的煤基固体废弃物，具有可观的应用潜力。研究将煤气化细渣与生物质耦合，制备厘米级压块燃料。压块燃料为在6 MPa下室温环境中，经过2 min压制而成。利用自主研发的平焰宏观热重燃烧反应器，以高加热速率的高温烟气模拟实际燃烧工况，主要关注不同生物质种类及生物质掺混比例（0%~100%）对压块燃料燃烧及排放的影响。实验结果表明：不同生物质因化学组分差异，显著影响燃烧过程。引入生物质这一过程通过改变燃料颗粒组分，可以显著提升单一原料种类颗粒的燃烧速率，挥发分燃烧速率相差可达3~5倍；并可以降低混合燃料燃烧过程中NO _x和CO的生成量，污染物生成量可降低50%以上。该研究成果为煤气化细渣与生物质耦合制备清洁高效固体燃料的工艺优化提供了关键实验支撑。
- 煤气化细渣 /
- 生物质 /
- 成型燃料颗粒 /
- 宏热重 /
- 烟气排放
Abstract: Pelletizing technology has been widely used in the field of biomass and coal fuel processing. Pelletized fuel offers advantages such as easy transportation and storage， as well as high energy density. Coal gasification fine slag， a carbon-rich coal-based solid waste， holds considerable application potential. In this study， gasification fine slag was blended with biomass to prepare centimeter-scale composite pellets. The pelletized fuels were formed under a pressing pressure of 6 MPa at room temperature for 2 minutes. A self-developed flat-flame macro-thermogravimetric combustion reactor was employed to simulate practical combustion conditions using high-temperature flue gas at high heating rates. This study focused on the effects of different biomass types and blending ratios （0 to 100%） on the combustion characteristics and emission behavior of the pelletized fuel. The experimental results demonstrated that differences in the chemical composition of biomass types significantly influenced the combustion process. Furthermore， the introduction of biomass modified the fuel particle composition， which markedly enhanced the combustion rate of single-component fuel particles and reduced NO _x and CO emissions during co-combustion of the blended fuel. These findings provide critical experimental support for the optimization of clean and efficient solid fuel production through the coupling of gasification fine slag and biomass.
- coal gasification fine slag /
- biomass /
- pelletized fuel /
- macro-thermogravimetric /
- flue gas emission

HTML全文

参考文献(21)

[1]	JIN H G，GUO L J，XUAN Y M，et al. The energy conversion and utilization scientific problems for achieving“Dual Carbon” Goal[J]. Bulletin of National Natural Science Foundation of China，2025，39（3）：474-488. 金红光，郭烈锦，宣益民，等.“双碳” 目标下能源转化与利用科学问题[J]. 中国科学基金，2025，39（3）：474-488.
[2]	YUAN G，SUN Y，SU Z H，et al. Research progress，challenges，and innovations in the resource utilization of coal gasification slag[J]. Chemical Industry and Engineering Progress，2026，45（3）：1769-1787. 袁刚，孙宇，苏梓慧，等. 煤气化渣资源化利用研究进展、挑战与创新[J]. 化工进展，2026，45（3）：1769-1787.
[3]	ZHANG R M，LIU D H，HE H，et al. Comprehensive utilization of coal gasification fine slag and carbon ash separation technology[J]. Coal Engineering，2023，55（5）：175-182. 张瑞梅，刘定桦，何浩，等. 煤气化细渣综合利用与碳灰分离技术现状[J]. 煤炭工程，2023，55（5）：175-182.
[4]	SHI Z C，DAI G F，WANG X B，et al. Review on the comprehensive resources utilization technology of coal gasification fine slag[J]. Integrated Intelligent Energy，2020，42（7）：63-73. 史兆臣，戴高峰，王学斌，等. 煤气化细渣的资源化综合利用技术研究进展[J]. 华电技术，2020，42（7）：63-73.
[5]	DAI G F，ZHENG S J，WANG X B，et al. Combustibility analysis of high-carbon fine slags from an entrained flow gasifier[J]. Journal of Environmental Management，2020，271：111009.
[6]	LI Y，ZHOU T，WANG Y，et al. LFFF-CFB combustion technology for pure fine slag from entrained-flow bed gasification[J]. Journal of Electric Power，2025，40（3）：161-170. 李雨，周托，王瑀，等. 纯燃气流床煤气化细渣的快速流态化循环流化床（LFFF-CFB）燃烧技术[J]. 电力学报，2025，40（3）：161-170.
[7]	YU X H，LIU Q，ZHANG J，et al. Simple preparation of adsorbent from coal gasification fine slag for methylene blue adsorption and its combustion characteristics for recycling[J]. Industrial Water Treatment，2025，45（10）：130-140. 于希豪，刘祺，张杰，等. 煤气化细渣简单制备吸附剂用于亚甲基蓝吸附及其回收燃烧性研究[J]. 2025，45（10）：130-140.
[8]	SHI Z C，SHU Y X，WANG Z Y，et al. Emission characteristics of coal gasification fine slag direct combustion and co-firing with coal[J]. Journal of Environmental Management，2023，344：118498.
[9]	GUO Y，MA C F，ZHANG Y X，et al. Comparative study on the structure characteristics，combustion reactivity，and potential environmental impacts of coal gasification fine slag with different particle size fractions[J]. Fuel，2022，311：122493.
[10]	GUO M H，LI J X，TANG K Y，et al. Research progress on biomass solid briquettes[J]. China Forest Products Industry，2023，60（10）：40-44. 郭明辉，李嘉兴，唐宽勇，等. 生物质固体成型燃料研究进展[J]. 林产工业，2023，60（10）：40-44.
[11]	ZHANG N X，ZHU H Y，LANG L，et al. Co-pyrolysis characteristics and kinetics analysis of pellets made from semi-coke powder and biomass[J]. Acta Energiae Solaris Sinica，2025，46（5）：678-689. 张乃心，朱虹宇，郎林，等. 兰炭末与生物质混配成型颗粒的共热解特性与动力学分析[J]. 太阳能学报，2025，46（5）：678-689.
[12]	FENG J W，WANG Y B，LI L Y，et al. Effect of kaolin and halloysite on ash fusion characteristics of biomass pellets[J]. Renewable Energy Resources，2025，43（6）：711-718. 冯敬武，王毅斌，李良钰，等. 高岭土与埃洛石对生物质成型颗粒灰熔融特性的影响[J]. 可再生能源，2025，43（6）：711-718.
[13]	KIJO-KLECZKOWSKA A，ŚRODA K，KOSOWSKA-GOLACHOWSKA M，et al. Experimental research of sewage sludge with coal and biomass co-combustion，in pellet form[J]. Waste Management，2016，53：165-181.
[14]	YAN W J，LI K Y，YU T Z，et al. Determination of flame temperatures and soot volume fractions during combustion of biomass pellets[J]. Energy& Fuels，2021，35（3）：2313-2325.
[15]	MOCK C，LEE H Y，CHOI S C，et al. Combustion behavior of single pellets of coal-wood mixtures in a hot gas flow field[J]. Energy& Fuels，2018，32（11）：11913-11923.
[16]	LI R，GAO C L，SHI Z C，et al. Visualized combustion of coal-gasifier waste and biomass pellets in a high heating rate flat-flame burner[J/OL]. Combustion Science and Technology，2025：1-15.
[17]	ZHAO C X，JIANG E C，CHEN A H. Volatile production from pyrolysis of cellulose，hemicellulose and lignin[J]. Journal of the Energy Institute，2017，90（6）：902-913.
[18]	MIN F F，ZHANG M X. Study on combustion model and combustibility of biomass[J]. Journal of China Coal Society，2005，30（1）：104-108. 闵凡飞，张明旭. 生物质燃烧模式及燃烧特性的研究[J]. 煤炭学报，2005，30（1）：104-108.
[19]	LU Q，GUO R，ZHANG H，et al. To stimulate，and to inhibit：A theoretical understanding of the sodium-catalytic mechanism of coke gasification[J]. Chemical Engineering Journal，2022，435：135091.
[20]	ZHOU L X. Chapter 3-fundamentals of combustion theory[M]// Theory and Modeling of Dispersed Multiphase Turbulent Reacting Flows. Butterworth-Heinemann，2018：15-70.
[21]	WANG P Q，BAI B，WANG C A，et al. Experimental and kinetics study of NO heterogeneous reduction on semi-coke and its chars：effects of high-temperature rapid pyrolysis and atmosphere[J]. Energy，2023，264：126300.
