酒糟资源化制备生物炭与有机肥的碳排放核算与技术经济性研究

郝锦瑜; 彭鑫; 王纯; 徐克; 姚小龙; 孙迎雪

doi:10.13205/j.hjgc.202607017

酒糟资源化制备生物炭与有机肥的碳排放核算与技术经济性研究

doi: 10.13205/j.hjgc.202607017

北京工商大学环境科学与工程系, 北京 100048

基金项目:

国家自然科学基金项目（22278007）；国家重点研发计划（2023YFE0104900）

详细信息

作者简介:
郝锦瑜（2001—），女，硕士研究生。hjy147258369@foxmail.com

通讯作者:
孙迎雪（1973—），女，教授，研究方向水污染控制理论与技术。sunyx@th.btbu.edu.cn

计量
- 文章访问数: 7
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2026-05-22
- 网络出版日期: 2026-09-01

Carbon emissions accounting and techno-economic evaluation of biochar and organic fertilizer production from distillers’ grains

School of Light Industry Science and Engineering, Beijing Technology and Business University, Beijing 100048, China

摘要

摘要: 酒糟作为酿酒工业产量最大的典型有机固体废弃物，其高效、低碳资源化利用是推动酿酒行业绿色转型、实现“双碳”目标的关键抓手，对行业可持续发展具有重要现实意义。研究以酒糟制备生物炭与有机肥2种主流资源化路径为研究对象，采用生命周期评价（LCA）方法，以各工艺环节已有文献公开数据为基础，系统核算了2种路径全生命周期内的CO₂排放量及碳减排效益，并从原料供应、设备投入、运行消耗等维度构建技术经济性评价模型，综合评估2种路径的成本、收益及投资可行性。结果显示：理论上1 t酒糟热解制备生物炭路径全流程总CO₂排放量为250.02 kg，碳封存减排量达120.29 kg，其具有低碳排放、固碳持久的核心优势；1 t酒糟发酵制备有机肥路径全流程总CO₂排放量为536.14 kg，碳减排量为86.22 kg，减排效果低于生物炭路径。技术经济性分析表明，酒糟生物炭单位净利润为471.97元/t，酒糟有机肥单位净利润为822.27元/t，相比之下，有机肥工艺的盈利水平更具优势。2种资源化路径均能实现CO₂减排，其中生物炭工艺侧重低碳环保，有机肥工艺在经济效益上表现更好。研究可为酿酒行业有机固废资源化路线选择、低碳技术推广及循环经济模式构建提供数据支撑。
- 酒糟资源化 /
- 生物炭 /
- 有机肥 /
- 二氧化碳排放 /
- 技术经济性
Abstract: Distillers’ grains are a predominant type of organic solid waste with the largest output in the brewing industry. Their efficient and low-carbon resource utilization serves as a core approach to advance the green transformation of the brewing sector and achieve the Dual Carbon Goals. This study took two mainstream resource utilization routes of distillers’ grains， namely biochar preparation and organic fertilizer production， as the research objects. Based on publicly available parameters of each process unit in existing literature， the life cycle assessment （LCA） method was adopted to systematically calculate the carbon dioxide emissions and carbon reduction benefits of the two approaches throughout their full life cycles. Meanwhile， a techno-economic evaluation model was established from the perspectives of raw material supply， equipment investment and operational consumption， so as to comprehensively evaluate the cost， economic benefit and investment feasibility of the two processes. The results showed that theoretically， the total life-cycle CO₂emission of biochar production via pyrolysis of 1 t of distillers’ grains was 250.02 kg， with a carbon sequestration reduction of 120.29 kg， presenting distinct advantages of low carbon emission and long-term carbon fixation. By contrast， the total CO₂emission of organic fertilizer produced by 1 t of distillers’ grains fermentation reached 536.14 kg with a carbon emission reduction of 86.22 kg， whose carbon mitigation performance was inferior to the biochar pathway. Techno-economic analysis indicated that the net profit of distillers’ grain-derived biochar was 471.97 yuan per ton， while that of distillers’ grain organic fertilizer was 822.27 yuan per ton， demonstrating that the organic fertilizer production process delivers superior economic profitability. In conclusion， both resource utilization processes can effectively reduce carbon dioxide emissions. The biochar preparation process features low carbon output and environmental sustainability， whereas the organic fertilizer production process delivers superior economic benefits. This study can provide solid theoretical references and reliable data support for the selection of organic solid waste recycling strategies， the promotion of low-carbon technologies， and the establishment of circular economy models in brewing industry.
- distillers’ grains resource utilization /
- biochar /
- organic fertilizer /
- carbon dioxide emissions /
- techno-economics

HTML全文

参考文献(40)

[1]	DE ISEPPI A，LOMOLINO G，MARANGON M，et al. Current and future strategies for wine yeast lees valorization[J]. Food Research International，2020，137：109352.
[2]	ZENG X，LI X T，JIANG Y F，et al. Preliminary study on the preparation of bio-organic fertilizer from sauce-flavor Baijiu distillers’ grains and its fertilizer efficiency[J]. China Brewing，2024，43（11）：167-172. 曾祥，李秀彤，江友峰，等. 利用酱香型白酒酒糟制备生物有机肥及其肥效的初步研究[J]. 中国酿造，2024，43（11）：167-172.
[3]	LU H，TIAN J P，LÜ Y Z，et al. New progress in resource utilization of solid waste from Baijiu brewing[J]. Environmental Engineering，2022，40（11）：231-236. 卢皓，田金平，吕一铮，等. 白酒酿造固体废弃物资源化利用新进展[J]. 环境工程，2022，40（11）：231-236.
[4]	FU N N，WANG Y M，WANG F Z，et al. Analysis on resource utilization status of Baijiu distillers’ grains[J]. China Brewing，2025，44（8）：9-14. 付娜娜，王亚美，王方正，等. 白酒酒糟资源化利用现状分析[J]. 中国造酒，2025，44（8）：9-14.
[5]	WANG P X，XIAO J B，LIU X J，et al. Present situation and prospect of resource utilization of Baijiu distillers’ grains[J]. Modern Food，2022，28（17）：1-4. 王鹏晓，肖进彬，刘晓杰，等. 白酒酒糟资源化利用现状及展望[J]. 现代食品，2022，28（17）：1-4.
[6]	SARFARAZ Q，SILVA L S D，DRESCHER G L，et al. Characterization and carbon mineralization of biochars produced from different animal manures and plant residues[J]. Scientific Reports，2020，10（1）：955.
[7]	ERIKSSON O，JONSSON D，HILLMAN K. Life cycle assessment of Swedish single malt whisky[J]. Journal of Cleaner Production，2016，112：229-237.
[8]	YE N，LU H，SHI C，et al. Environmental impact of new resource recovery technology for Baijiu distillers’ grains based on life cycle assessment[J]. Environmental Engineering，2024，42（1）：135. 叶宁，卢皓，史晨，等. 基于生命周期的白酒丢糟资源化新工艺技术环境影响研究[J]. 环境工程，2024，42（1）：135.
[9]	DEROSE K，LIU F，DAVIS R W，et al. Conversion of distiller’s grains to renewable fuels and high value protein：integrated techno economic and life cycle assessment[J]. Environmental Science& Technology，2019，53（17）：10525-10533.
[10]	VáZQUEZ-ROWE I，CáCERES A L，TORRES-GARCíA J R，et al. Life cycle assessment of the production of pisco in Peru[J]. Journal of Cleaner Production，2017，142：4369-4383.
[11]	HARING N，DRÁBOVÁ B，CHŇAPEK M. Circular valorization of brewer’s spent grain and brewer’s yeast：pathways，sustainability implications，techno-economic feasibility，and policy perspectives[J]. Sustainability，2026，18（5）：2464.
[12]	YANG W，ZHAO Y，LV J，et al. Life cycle assessment and techno-economic analysis of high-value utilization of carbon dioxide for ethylene glycol and methanol synthesis[J]. Chemical Engineering Journal，2025，514：163365.
[13]	LI P Y，WU L D，LIU B，et al. Life cycle carbon emission inventory and footprint assessment of eucalyptus production and management in China[J]. Acta Ecologica Sinica，2025，45（14）：6985-7001. 李佩玥，吴立东，刘斌，等. 中国桉树生产经营过程生命周期碳排放清单及足迹评估[J]. 生态学报，2025，45（14）：6985-7001.
[14]	INGRAM D L，FERNANDEZ R T. Life cycle assessment：a tool for determining the environmental impact of horticultural crop production[J]. Hort Technology，2012，22（3）：275-279.
[15]	State Administration for Market Regulation，Standardization Administration of China. Requirements for greenhouse gas emission accounting and reporting Part 25：Enterprises of food，tobacco，alcohol，beverage and refined tea：（GB/T 32151.25—2024）[S]. Beijing：China Standards Press，2024. 国家市场监督管理总局，国家标准化管理委员会. 温室气体排放核算和报告要求第25部分：食品、烟酒、饮料、精茶企业：（GB/T 32151.25—2024）[S]. 北京：中国标准出版社，2024.
[16]	IPCC. 2019 Refinement to the 2006 IPCC Guidelines for National Greenhouse Gas Inventories[S]. Switzerland：IPCC，2019.
[17]	HARSONO S S，GRUNDMAN P，LAU L H，et al. Energy balances，greenhouse gas emissions and economics of biochar production from palm oil empty fruit bunches[J]. Resources，Conservation and Recycling，2013，77：108-115.
[18]	HU Y P，XIAO C，LI Z M. Pilot-scale application of treatment process for oily sludge pyrolysis wastewater[J]. Environmental Protection of Oil& Gas Fields，2024，34（4）：29-33. 胡以朋，肖超，李子鸣. 油泥热解废水处理工艺中试应用[J]. 油气田环境保护，2024，34（4）：29-33.
[19]	Ministry of Ecology and Environment，National Bureau of Statistics，National Energy Administration. Announcement on issuing the 2024 Power Carbon Footprint Factor Data[EB/OL].（2025-10-24）[ 2026-04-07]. 生态环境部，国家统计局，国家能源局. 关于发布2024年电力碳足迹因子数据的公告[EB/OL].（2025-10-24）[ 2026-04-07].
[20]	CHEN J. Study on carbon sequestration benefit and economic efficiency of straw biomass converted into biochar returning to field[D]. Shanghai：Shanghai Jiao Tong University，2020. 陈键. 秸秆生物质转化为生物炭还田的固碳效益及其经济性研究[D]. 上海：上海交通大学，2020.
[21]	GAUNT J L，LEHMANN J. Energy balance and emissions associated with biochar sequestration and pyrolysis bioenergy production[J]. Environmental Science& Technology，2008，42（11）：4152-4158.
[22]	LI Z. Study on production and fertilizer efficiency of distillers’ grains organic fertilizer and effect of distillers’ grains derived biochar[D]. Chongqing：Southwest University，2021. 李哲. 酒糟有机肥生产，肥效以及酒糟生物质炭的效应研究[D]. 重庆：西南大学，2021.
[23]	LI H Y，WANG T，LI Y F，et al. Research on turning power consumption model of drum-type compost turner based on ANSYS/LS-DYNA[J]. Journal of Chinese Agricultural Mechanization，2019，40（6）：26-30. 李海漪，王涛，李云飞，等. 基于ANSYS/LS-DYNA的滚筒式翻堆机翻抛功耗模型研究[J]. 中国农机化学报，2019，40（6）：26-30.
[24]	SHI Y，LI Y，FENG L，et al. Whole life cycle carbon emission accounting and carbon emission reduction measures of straw organic fertilizer[J]. Tianjin Agricultural Sciences，2024，30（1）：79-83. 石岩，李妍，冯磊，等. 秸秆有机肥全生命周期碳排放核算及碳减排措施[J]. 天津农业科学，2024，30（1）：79-83.
[25]	GRANATSTEIN D，KRUGER C E，COLLINS H P，et al. Use of biochar from the pyrolysis of waste organic material as a soil amendment[R]. Wenatchee：Center for Sustaining Agriculture and Natural Resources，Washington State University，2009：168.
[26]	National Development and Reform Commission. List of transmission and distribution electricity prices in various regions in the Third Supervision Cycle[EB/OL]. Beijing：National Development and Reform Commission，2023. 国家发展和改革委员会. 第三监管周期各地区电网输配电价表[EB/OL]. 北京：国家发展改革委，2023.
[27]	CAPUTO A C，PALUMBO M，PELAGAGGE P M，et al. Economics of biomass energy utilization in combustion and gasification plants：effects of logistic variables[J]. Biomass and Bioenergy，2005，28（1）：35-51.
[28]	BRIDGWATER A V，TOFT A J，BRAMMER J G. A techno-economic comparison of power production by biomass fast pyrolysis with gasification and combustion[J]. Renewable and Sustainable Energy Reviews，2002，6（3）：181-246.
[29]	TRAPERO J R，ALCAZAR-RUIZ A，DORADO F，et al. Biochar price forecasting：A novel methodology for enhancing market stability and economic viability[J]. Journal of Environmental Management，2025，377：124681.
[30]	ZILBERMAN D，LAIRD D，RAINEY C，et al. Biochar supply-chain and challenges to commercialization[J]. GCB Bioenergy，2023，15（1）：7-23.
[31]	Ministry of Science and Technology，Ministry of Agriculture. Compilation of technical achievements on comprehensive utilization of agricultural wastes（straw，manure）[G]. Beijing：Ministry of Science and Technology，2015. 科学技术部，农业部. 农业废弃物（秸秆/粪便）综合利用技术成果汇编[G]. 北京：科学技术部，2015.
[32]	BOARDMAN A，GREENBERG D，VINING A，et al. Cost-benefit analysis：concepts and practice[M]. 4th ed. Cambridge：Cambridge University Press，2017.
[33]	利乐公司. 选择酒糟的三个理由[EB/OL]. 2026-01-25[ 2026-06-02]. Pak Tetra. Three reasons to select spent grain[EB/OL]. 2026-01-25[ 2026-06-02].
[34]	BUFFI M，HURTIG O，PRUSSI M，et al. Energy and GHG emissions assessment for biochar-enhanced advanced biofuels value chains[J]. Energy Conversion and Management，2024，309：118450.
[35]	YASMIN N，JAMUDA M，PANDA A K，et al. Emission of greenhouse gases（GHGs）during composting and vermicomposting：Measurement，mitigation，and perspectives[J]. Energy Nexus，2022（7）：100092.
[36]	LU H，BIAN R，XIA X，et al. Legacy of soil health improvement with carbon increase following one time amendment of biochar in a paddy soil：a rice farm trial[J]. Geoderma，2020，376：114567.
[37]	Ministry of Agriculture and Rural Affairs，National Development and Reform Commission，Ministry of Science and Technology，et al. The 14th Five-Year National Agricultural Green Development Plan[R]. 2021. 农业农村部，国家发展改革委，科技部，等.“十四五”全国农业绿色发展规划[R]. 2021.
[38]	农业农村部. 农业农村部关于加快农业发展全面绿色转型促进乡村生态振兴的指导意见：农规发〔2024〕27号[S]. 2024. Ministry of Agriculture and Rural Affairs. Guiding opinions on accelerating the all-round green transformation of agricultural development and promoting rural ecological revitalization，No. Nonguifa〔2024〕27[S]. 2024.
[39]	MENG F，WANG D. New strategies for sustainable biofuel production：pyrolytic poly-generation of biomass[J]. Sustainability，2025，17（5）：1945.
[40]	NEMATIAN M，KESKE C，NG’OMBE J N. A techno-economic analysis of biochar production and the bioeconomy for orchard biomass[J]. Waste Management，2021，135：467-477.
